R E A R S
Pulblast with AR pump
PULBLAST
A/R PUMP
READ THIS MANUAL BEFORE OPERATING
06.20.18
800 547 8925
Rears Manufacturing Company Inc.
www.rearsmfg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PULBLAST A/R PUMP and is the answer not in the manual?

Questions and answers

Summary of Contents for Rears PULBLAST A/R PUMP

  • Page 1 R E A R S Pulblast with AR pump PULBLAST A/R PUMP READ THIS MANUAL BEFORE OPERATING 06.20.18 800 547 8925 Rears Manufacturing Company Inc. www.rearsmfg.com...
  • Page 2 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 3 Sprayer Safety: Operator Tranng Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be wiped out by a single careless act of an operator. READ THE OPERATOR’S MANUAL In addition to the design and configuration of equipment, hazard control and ac- cident prevention are dependent upon the awareness, concern, prudence and proper training of personnel involved in the operation, transport, maintenance and storage...
  • Page 4 Sprayer Safety: Preparaton Never operate the tractor and implement until you read and completely understand this manual, the tractor operator’s manual, and each of the safety messages found on the safety decals on the tractor and the implement. Personal protection equipment, including a hard hat, safety glasses, safety shoes, and gloves are recommended during assembly, installation, operation, adjustment, maintenance, repair, removal, or transport of this implement.
  • Page 5 Sprayer Safety: Startng & Stoppng Implement operating power is supplied from the tractor’s PTO. Refer to your tractor manual for PTO engagement and disengagement instructions. Always operate the implement at its required PTO speed: either 540 or 1000 rpm. Know how to stop the tractor and implement quickly in case of an emergency.
  • Page 6 Sprayer Safety: Chemcals Never provide agricultural chemicals to anyone unless that person has been properly trained or licensed. Make certain the entire manufacturer’s label appears on the chemical container. Always follow the manufacturer’s instructions for storage, handling, and application. Before a spraying operation is started the spray system should be rinsed and all nozzles, screens, and strainers cleaned.
  • Page 7 The skin on various body parts does not absorb pesticides at the same rate. The figure, right, illustrates skin absorption rates based on a numerical scale in which the value of 1 for the forearm represents the lowest dermal absorption rate. That value forms the basis for the assignment of values to the other body parts.
  • Page 8 Sprayer Safety: Pre-operaton Install and secure all guards and shields before starting or operating. Frequently check fan blades. They should be free of nicks and cracks. The fan guard must be kept clean and in good repair. The mechanical cabinet access guards, fan guard, sag chains, driveline shields, and gearbox shields should be used and maintained in good working condition.
  • Page 9 Be aware of the meteorological conditions and plan spray applications during op- portune times. High winds and low humidity will increase drift and adversely affect your spray program. Avoid spraying near lakes, streams, pastures, population areas (houses, schools, playgrounds, hospitals) beehives or sensitive non-target crops. Always spray downwind from these sensitive areas and do not spray during adverse wind or low humidity conditions.
  • Page 10 v Sprayer Safety: Operaton The use of this equipment is subject to certain hazards which cannot be protected against by mechanical means or product design. All operators of this equipment must read and understand this entire manual, paying particular attention to safety and operating instructions, prior to use.
  • Page 11 Do not allow riders on the implement or tractor at any time. There is no safe place for any riders. Disengage PTO and place transmission into neutral before attempting to start the engine. Do not operate unless all personnel, livestock, and pets are out of your application area.
  • Page 12 Never try to unclog a nozzle by blowing through it. Always carry extra spray tips. Never operate tractor and implement under trees with low hanging limbs: the op- erator can be knocked off the tractor and run-over. Stay alert for holes, rocks and roots in the terrain and other hidden hazards. Keep away from drop-offs.
  • Page 13 Sprayer Safety: Tres Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion which may result in serious injury or death. Do not attempt to mount a tire unless you have the proper equipment and experi- ence to do the job.
  • Page 14 Sprayer Safety: Mantenance Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Follow good shop practice. Keep service area clean and dry. Be sure electrical out- lets and tools are properly grounded. Use adequate light for the job at hand. Make sure there is plenty of ventilation.
  • Page 15 x When completing a maintenance or service function, make sure all safety shields and devices are installed before placing the unit back in service. Remove hydraulic pressure prior to doing any maintenance. Block the implement securely, disengage the PTO, and turn off the engine. Never use your hands or any part of your body to locate a hydraulic leak.
  • Page 16 Sprayer Safety: Transport Comply with state and local laws governing highway safety and movement of farm machinery on public roads. reflective red border fluorescent yellow/orange The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements.
  • Page 17 Sprayer Safety: Storage With pull-type units, never unhitch the implement without using the tongue jack. The tongue is very heavy. Attempting to lift the tongue without using the tongue jack could cause personal injury. Overloading the jack can cause failure with pos- sible serious injury or even death.
  • Page 18 Sprayer Safety: Safety Decals This is the SAFETY-ALERT symbol. This symbol is used to visibly mark operating hazards. YOU MUST FOLLOW THE DIRECTIONS POSTED BESIDE THE SAFETY-ALERT SYMBOL TO AVOID BODILY INJURY OR DEATH. Before you operate any machinery, read the operator’s manual. A copy of every SAFETY-ALERT decal on your implement is included in your operator’s manual with a map of each decal on your implement.
  • Page 19 xv Read ths manual completely before operatng: follow all safety nstructons.
  • Page 20 Pul-Blast AR pump system ATTENTION! WHEN DRAINING MANIFOLD, REMOVE CHECK VALVE CAP FROM THE TOP MANIFOLD NOZZLE ASSEMBLY. DANGER NO RIDERS NO PASAJEROS 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 21 Decal 91 is only present on units with hydraulic controls. Make certain all decals listed here are present on the sprayer and in good condition. Replacement decals are available from your dealer or direct from Rears. Read this manual completely before operating: follow all safety instructions.
  • Page 22 Pul-Blast AR pump system Hook-up instructions Modular Tongue 1. Read and understand all instructions before beginning. 2. Adjust tractor drawbar fig.1. For drivetrain longev- TRACTOR PTO ity, it is important that these alignments be within specified tolerances. + – 3. Connect implement hitch pin to tractor. DO NOT install + –...
  • Page 23 Pul-Blast AR pump system Hook-up instructions Tongue Mounted Pump 1. Read and understand all instructions before beginning. 3 max. shaft height offset PUMP TRACTOR PTO 2. Adjust tractor drawbar fig.1. Measure the horizontal distance between the pump min. shaft spline lock groove and the hitch pin as illustrated max.
  • Page 24 Quick hitch systems 10. Attach hydraulics- keep hoses clear of driveline. may require a longer mount pin, provided by Rears. 11. Rotate lift-jack or remove to storage point. 7. Attach check chains to their respective keyhole brack- ets and adjust as illustrated in fig i &...
  • Page 25 Pul-Blast AR pump system Read this manual completely before operating: follow all safety instructions.
  • Page 26 Pul-Blast AR pump system Pre-operation check list 1. Be certain operators have read and understand the 8. Check all plumbing lines and connections. operators manual. DO NOT skip the safety instruc- Fill tank with water above the level of the pump. tions at the beginning of this manual.
  • Page 27 Use the Calibration 6. Check pump belt tension. Instructions for Rears Airblast Sprayers to select an operating gear and speed for your application. 7. Inspect belts and fan blades- keep clean.
  • Page 28 Pul-Blast AR pump system fan gearbox fl.oz 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 29 Pul-Blast AR pump system Lubrication and maintenance All lube points have been made accessible. Lubrication does not require disassembly. Always use a Lithium base NLGI Grade 2 grease. We recommend Texaco Multifak Shell Alvania 2 , and Mobil Mobilux Use an oil compatible with your pump or gearbox- listed on the schedule, below.
  • Page 30 Pul-Blast AR pump system Parts list: modular tongue assembly No. Part # Description FL5131 1”3/8, 6 spline shaft 13621 bearing cup 13600LA bearing cone FL5132 bearing block only FL5133 bearing block with shaft and bearings rear plate with guard mount VMIN432 spacer BH1-07...
  • Page 31 Pul-Blast AR pump system PTO driveline for Tongue Mount Pump system supplied yokes may not be as illustrated female half A telescoping implement driveline is shipped with your male half sprayer to mount between your tractor and implement. See previous section Hook-up instructions Tongue Mounted Pump for driveline installation instructions.
  • Page 32 A telescoping implement driveline is shipped with your sprayer to mount between your tractor and implement. Rears has a wide selection of implement drivelines to accomodate your tractor. To determine the right tele- scoping driveline for your tractor, you need to have the...
  • Page 33 Pul-Blast AR pump system Implement driveline whole driveline part # ptospeed cross kit collar kit female DLF511S6 Y585 Y501 DLS510M CPL55E SSLK0621 1.375” 6 spline order by halves see column a male DLM515T17 Y586 Y514 DLS510F CPL55E – 1.5” 17 spline female DLF517S6 Y582...
  • Page 34 Pul-Blast AR pump system center link box has greasable bearings has sealed bearings Parts list: 51 series constant velocity hitch No. Part # Description No. Part # Description CVH71-TRN1 CAT I width trunion, no pins included 18A HS43CH3 check chain for trunion 1A CVH71-TRN2 CAT II width trunion, no pins included...
  • Page 35 Pul-Blast AR pump system 77 series hitch pin removal The hitch pin is a tapered fit in bushing. 1. Apply lube to threads. 2. Using the supplied crowfoot wrench* (bolted to the hitch trunion) loosen nut A and thread to inside plate B.
  • Page 36 Pul-Blast AR pump system pulblast plumbing pulblast electric spray controls Tank return line Lid basket strainer Manual controls Dump valve Discharge strainer Tank return line Line to handgun and pressure gauge Motor actuated Right Manifold valve HUV500 operator block Left Manifold Hu-valve see below Centrifugal pump...
  • Page 37 Pul-Blast AR pump system troubleshooting: excessive pressure drop Check the dump valve. When spraying, the dump valve must be completely closed. Using the dump valve to con- trol spray pressure will result in early belt failure. Check the tension of the pump drive belt: see the pump maintenance section of this manual.
  • Page 38 Pul-Blast AR pump system Hu-Valve Parts, Strainer Parts qty listed for one assembly No. Part # Description No. Part # Description HUV2100 complete hu-valve assembly STHP2100 Inlet adapter, 1” HUV100C hu-valve cap STHP2150 Inlet adapter, 1-1/2” HUV101B hu-valve body STHP2-140 o-ring HUV102G plunger...
  • Page 39 Pul-Blast AR pump system Strainer screen options, SPST7 strainers Screen Mesh Frame Color Frame Material Part # standard for centrifugal Orange Poly SPST7D6 pump suction strainer Green Poly SPST7D10 standard for diaphragm Black Poly SPST7D16 pump suction strainer Yellow Poly SPST7D24 Stainless Stainless Steel...
  • Page 40 Pul-Blast AR pump system Suction plumbing No. Part # Description B150FP 1-1/2” ball valve SSN150CLOSE 1-1/2” stainless steel close nipple ETC150KNPOLY 1-1/2” king nipple WC6825 worm clamp 1-1/2” Armorvin hose, provide length 126 Line Strainer Assembly 1” inlet 1-1/4” inlet 1-1/2”...
  • Page 41 Pul-Blast AR pump system Parts list: spray pressure cluster assembly No. Part # Description NYEL100100HB elbow, 1”MPT x 1”HB nylon HNP100 1” armorvin hose, give length LFG600 600psi liquid filled gauge BR411-1510 pressure relief valve MBW106 cross (3x)3/4”MPT x 3/4”MGHT brass ball valve 3/4”MGHT x 3/4”FPT 5PVC075 3/4”...
  • Page 42 Pul-Blast AR pump system BR411-1510 870psi valve BR411-1510.3 360psi valve 360psi 410.214.6 orange 870psi 170.214.1 black 360psi 410.1003.22 870psi 170.1003.10 360psi 411.1617.18 870psi 170.1617.17 AVAILABLE SPARE PARTS KITS individual components PART NUMBER subassembly order number 410.302.36 spare parts kit PART NUMBER basic assembly order number PART NUMBER component included in a spare parts kit...
  • Page 43 Pul-Blast AR pump system 689060 Volume operating range All spring weights up to 40 gpm. Working pressure range Hi-pressure spring up to 600 psi. Lo-pressure spring 200-400 psi. Parts list 689060 relief valve, operating instruction No. Part # Description 689060 complete relief valve When starting the pump and during chemical refill and mix KIT68...
  • Page 44 Pul-Blast AR pump system electric hu-valve control- wiring 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 45 Pul-Blast AR pump system electric hu-valve control- daily maintenance fig. i When flushing the plumbing at day’s end, cycle fresh water through the spray lines, turning the spray ON and OFF several times. electric hu-valve control- seasonal storage TOP VIEW CUT-AWAY Perform the line flush, as above.
  • Page 46 Pul-Blast AR pump system KZ electric ball valve DC 12 volt, 1.5A No. Part # Description KZ075 complete 3/4” ball valve KZ100 complete 1” ball valve KZ114 dome EH3-115Y yellow flag EH-130 o-ring, silicone, #027 screw #5 x 9/16”SS EH2-1201 upper case half with dome EH-104 retainer...
  • Page 47 Pul-Blast AR pump system 3/4”-14 NPT 1” NPT R7 hydraulic spray valve No. Part # Description DAH2W075 R7 hydraulic actuated valve, complete DAHV2WKIT repair kit includes all • items DAH2WV13 valve body inlet 759051 valve assembly V75-026 • o-ring, viton V75-131 •...
  • Page 48 Pul-Blast AR pump system braglia dump valve or spray control valve brown blue braglia dump valve and pressure regulating valve CHEMICAL CONTAINERS INC. 800 346 7867...
  • Page 49 Pul-Blast AR pump system Braglia valve assemblies No. Part # Description 180.1910.9HS Dump valve, 1” port, black cap 180.1910.9 Dump valve, 1” port, orange cap, obsolete 180.1910.19HS Dump valve, 3/4” port, black cap 180.1910.19 Dump valve, 3/4” port, orange cap, obsolete 180.232.6 valve signal control cable call...
  • Page 50 right left...
  • Page 51 braglia metered bypass set-up Before calibrating your metered bypass valves be sure you have water in your spray tank. The tank should be at least 1/4 full before engaging the PTO. Make sure the dump valve and handgun valve are closed. The spray tips installed should match your desired application rate.
  • Page 52 Pul-Blast AR pump system 180.601.2 BLACK CAP ORANGE CAP OBSOLETE SEE MOTOR/BODY COMPATIBILITY CHART 141.602.17 142.602.18 180.602.49 180.232.5 180.602.49 MOTOR/BODY 180.620.35 22RPM 180.620.4 8.5RPM MOTOR COMPATIBILITY 180.507.12 180.620.35 180.620.6* CHART DISCARD WHEN BLACK CAP ORANGE CAP UPGRADE TO 180.620.35 180.218.153 180.1910.9HS BLACK MOTOR 180.218.4*...
  • Page 53 Pul-Blast AR pump system 180.601.2 GREEN CAP GREEN CAP OBSOLETE SEE MOTOR/BODY SEE MOTOR/BODY COMPATIBILITY COMPATIBILITY CHART CHART 141.602.17 142.602.18 180.232.5 180.602.49 180.602.49 180.620.6.25 180.620.6 MOTOR/BODY MOTOR COMPATIBILITY 180.1910.10 180.620.6.25* CHART 180.620.6 pressure regulating valve parts OBSOLETE 180.218.153 180.218.4* OBSOLETE *LIMITED AVAILABILITY 180.4.8 180.614.7...
  • Page 54 Pul-Blast AR pump system 180.1910.9HS 180.1910.19HS 180.1910.9/180.1910.19 valve repair LOCK ONLY USED WITH ORANGE CAP MOTOR ASSY valve troubleshooting Valve doesn’t activate. Check cable connections- look for oxidation and clean. Check fuse. ONLY USE 1.25A time delay fuse. Repeated fuse blow out. Disconnect power cable and remove lock 29 with screwdriver.
  • Page 55 Pul-Blast AR pump system fig. i important To install ball 23 align notch on stud 18 opposite valve disassembly the discharge port Disconnect power supply and remove all lines from valve ports. Insert ball as shown. Hold the valve firmly, gripping the side ports, and remove nipple 25 from valve using a CH32 wrench.
  • Page 56 PUMP OPERATION Do not over-speed your pump Refer to the performance chart for your specific pump to Maintain proper oil level find the maximum operating speed. Your pump is de- signed to operate at or below this speed. Over-speeding The crankcase oil serves two important functions. The oil lu- will cause valves to prematurely fail and could cause bricates all moving parts in the pump and affects the hydraulic other internal damage.
  • Page 57 PUMP MAINTENANCE HANDLE AGRICULTURAL CHEMICALS WITH CARE USE THE PERSONAL PROTECTIVE EQUIPMENT After each use RECOMMENDED BY THE CHEMICAL MANUFACTURER Run pump for five minutes with clean water. These few minutes WHEN MAINTAINING SPRAY EQUIPMENT! of flushing are well spent: extend diaphragm life, minimize chemical buildup throughout your spray system.
  • Page 58 Pul-Blast AR pump system TROUBLESHOOTING The AR diaphragm pump delivers volume determined by pump speed. Set pressure with your adjustable relief valve. Problem Source No pressure Plugged strainer Clean screen- see suction care on pump operation page. Suction hose obstruction Clear obstruction Very little pressure Collapsed suction hose outside or inside tank...
  • Page 59 Mechanical agitation Part # Description 5/8” shaft 3/4” shaft AG06210ASSY AG07510ASSY complete rear bearing AG06203ASSY AG07503ASSY complete front bearing AG062ESS AG075ESS packing nut w/packing AG025 (6”) AG025 (11”) packing AG062C AG075C locking ring AGBSH062 AGBSH075112 bushing AG06210 AG07510 rear housing w/busings AG06203 AG07503 front housing w/busings...
  • Page 60 Pul-Blast AR pump system KBPA100 Y361 AR50 PUMP pump and gearbox adapters GEARBOX Input: 1” M keyed shaft 1-3/8” 6 spline Output: male shaft 3 bolt flange S-BB AGITATOR KB1524 BELT S-BB MBPA102 Y361 AR160 PUMP GEARBOX Input: 1-3/8” M 6 spline 1-3/8”...
  • Page 61 * 35 series thru-tank driveline. Select the driveline that matches your yokes and collapsed cross-to- cross measurement OR provide your Thru-Tank Driveline Selection serial number to a Rears dealer for driveline identification. Complete Driveline Part Number* splinelock kit or rollpin Hitch End...
  • Page 62 Pul-Blast AR pump system universal joint disassembly Remove all (4) snap rings in cross assembly 1. Note: Yoke arms must be true. If a yoke arm is sprung by striking with excessive force, the cross will bind in operation. Position joint in loose vice 2. Strike top arm of unsupported yoke to drive the top cup up.
  • Page 63 Pul-Blast AR pump system CPLG102 flex coupling No. Part # Description CPLG1000 repair kit CPLG1025 spider, 1-3/8” 6-spline CPLG1022 beaded washer CPLG1024 shock absorbing disc CPLG1021 1/2”-20 X 2-11/16” Gr.5 bolt CPLG1023 1/2”-20 slotted nut Flex coupling assembly 1. Always rotate bolt head. LARGE DIAMETER SHEAR 2.
  • Page 64 Pul-Blast AR pump system Shift kit MGB0105KIT Always use an AGMA No.2 EP rated gear lubricant, such as Mobilgear 626. Gearbox Parts MGB242SPCM9P for 24” fan No. Part # Description No. Part # Description MGB0456510 seal 45 x 65 x 10 MGB01040 pin 6 x 45 6209...
  • Page 65 Always use an AGMA No.2 EP rated gear lubricant, such as Mobilgear 626. Shift kit MGB02SHIFT Check the oil level (sight gauges indicated on diagram). Always use an AGMA 2EP grade ISO 68 gear lubricant. See lubricant list at right. Gearbox oil change: Drain the gearbox while warm.
  • Page 66 Pul-Blast AR pump system 800 346 7867 CHEMICAL CONTAINERS INC.
  • Page 67 Pul-Blast AR pump system see fan page see gearbox page SEE FAN INSTALLATION INSTRUCTIONS FOR PARTS AND SAFETY INFORMATION! Fan Housing No. Part # Description one complete lower deflector DEF-2 one complete upper deflector obsolete part, call for information 0310200CH2 5/16”-18 x 2”...
  • Page 68 Pul-Blast AR pump system Fan: 28” , 32” , 36” for 24” fan, see parts page Complete Fan Assembly: No. Part # Description 28” Fan MF288VAU-A MF821 cover, aluminum, 28”/8 blade fan 32” Fan MF32VP MF822 cover, aluminum, 32”-36” fan 36”...
  • Page 69 Pul-Blast AR pump system Fan position bolt M8X50SHC socket head cap screw FAN PITCH flat washer 35° 2-142 45° MAXIMUM o-ring 25° MINIMUM* Fan Cover Cover O-ring Snap Ring *not available all models. Fan Shaft Thrust Washer Snap Ring Install: Clutch Fan Hub Be sure snap ring...
  • Page 70 Pul-Blast AR pump system Injector hopper operation The injection hopper is a standard component of 1000 gallon Powerblast sprayers and is available as an option for other models. To use the injector, make certain the dump line valve at is open. With the lid closed open the supply valve You should hear the flow through the venturi nozzle.
  • Page 71 Pul-Blast AR pump system BR123W Standard BR2/BR2DC nozzle configuration: A side- ceramic orifice/core, nylon strainer B side- steel orifice, brass core, brass strainer Specify sizes for orifice/core/strainer. Complete Spraying Systems selection. BR0505F BR0807 heavy spring BR0807H BR0209 BR0508 BR05042 BR0509 BR0503 BR0880 BR0506...
  • Page 72 Pul-Blast AR pump system Hub Removal 1. Remove wheel. 2. Remove grease cap or bearing buddy. Bearing adjustment- reinstall hub 3. Remove cotter pin. 1. Before reinstalling the hub, inspect the spindle sur- 4. Unscrew the spindle nut counter-clockwise. face. The surface should be smooth and free of burrs 5.
  • Page 73 Pul-Blast AR pump system spindle spindle dimensions dimensions Q778 8 wheel bolts 8 stud bolts spindle spindle dimensions dimensions Q888 Q803 6 wheel bolts 6 wheel bolts Q778 Q803 Q888 No. Part # Qty Part # Qty Part # Qty Part # Qty Description HA-758400-8 HA-Q778...
  • Page 74 Pul-Blast AR pump system Lid options No. Part # Description No. Part # Description LD160 round lid 0310100CH5 5/16”-18 x1” bolt LDVENT lid vent, flat top ARAG 031NF 5/16”-18 nut LDVENTM lid vent, mushroom shape 0250075CHSS 1/4”-20 x 3/4” bolt, stainless steel LD160H hinge 025WSS...
  • Page 75 Pul-Blast AR pump system Read this manual completely before operating: follow all safety instructions.
  • Page 76 Rears does hereby warrant to the original purchaser of each product manufactured by Rears for a period of ninety (90) days from the date of purchase or five hundred (500) hours of operation, which-ever occurs first, that such product will be free from defects in material and workmanship under normal use with normal maintenance service.
