Desa C21TP Assembly And Installation Instructions

ASSEMBLY AND INSTALLATION INSTRUCTIONS
IMPORTANT: Read entire instruction sheet before
assembling or installing mantel kit.
these mantels are only approved for use with any
DesA Heating, llC 21" or 23" electric and gas
fireplace system. Do not use mantel with any other
product.
This mantel kit contains the following:
• Mantel pieces - unassembled and numbered as follows:
#1 Base
#2 Right Side Assembly
#3 Left Side Assembly
#4 Header
#5 Top
#6 Base Support
#7 Vertical Support
Right Top Trim Strip
Left Top Trim Strip
• Hardware Package
22 - 1 / " Wood Screws
1
4
8 - 1" Finishing Nails
* Extra hardware may be included
Tools required:
• Power Screwdriver with #2 Phillips Bit
• Hammer
• Nail Set
Smoky Mountain Fireplace
828-670-1970
www.smfireplace.com
C21TP and C21TO
Corner Mantel and Base
114325-01
114295-04
www.desatech.com
If any wood pieces are missing or damaged, contact the
dealer where you purchased this mantel for replacement. If
hardware is missing or damaged, contact DESA Heating, LLC
at 1-866-672-6040 for referral information. You can also visit
DESA Heating, LLC's web site at www.desatech.com.
Note: Gather all mantel pieces together before assembling
mantel.
WARNING: Only use 1
mantel. Damage to mantel will result if other screws
are used for this purpose.
IMPORTANT: A serial number label is located inside of right
side panel and on outside package. When calling to request
technical assistance or for replacement parts please have
serial number ready.
AssemblING mANtel
IMPORTANT: more than one person is required to lift
assembled mantel. lift mantel by leg assemblies. lifting
by header or mantel top could damage mantel.
Use the following illustrations to assemble mantel. Use only
screws provided.
/ " screws to assemble
1
4
