Allegheny GeoVISION User Manual

Deluxe borehole video system
Hide thumbs
Table of Contents

Advertisement

Quick Links

GeoVISION
TM
Deluxe Borehole Video System
User's Manual
1/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GeoVISION and is the answer not in the manual?

Questions and answers

Summary of Contents for Allegheny GeoVISION

  • Page 1 GeoVISION Deluxe Borehole Video System User’s Manual 1/15...

  • Page 3: Table Of Contents

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Introduction ......................................4 Quick Setup Guide .................................... 7 System Setup ..................................... 15 System Operation..................................... 17 Maintenance ...................................... 19 Troubleshooting ....................................21 Appendix A Deluxe Winch ................................23 Appendix B Standard Stainless Steel Cameras ........................... 29 Appendix C Standard Plastic Cameras ............................37 Appendix D Nano Camera ................................

  • Page 4: Introduction

    Borehole Video System. Allegheny Instruments is committed to providing the world’s highest quality borehole video systems along with the industry’s best warranty and technical support. If you have any questions regarding your GeoVISION system, please contact us. Our office hours are Monday through Friday, 8:00 am to 5:00 pm Eastern Time and our contact information is as...
  • Page 5 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Important Precautionary Information The information contained on this page appears throughout this manual. Be sure to read and understand these precautions prior to using the system. DANGER will come in contact with solvents, oils, or fuels.
  • Page 6 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 7: Quick Setup Guide

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Quick Setup Guide Camera Configuration The following image illustrates some common ways to configure various cameras based on the type of camera, bore diameter and intended use. For a detailed description on how to configure each camera, see the appendix for the camera.
  • Page 8 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Winch Setup Set the switches on the top of the Control Panel. Turn on all three light switches. Set the Exposure Control switch to “ ” Normal. Rotate the Winch Control knob straight up to Turn off the Winch Motor switch.
  • Page 9 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Insert the winch legs. Clamp the Depth Encoder to the well casing or a tripod placed over the bore.
  • Page 10 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Place the winch on level ground approximately 10 feet (3 meters) from the Depth Encoder. Connect the Encoder Cable between the winch and the Depth Encoder. If the borehole is deeper than 600 feet (200 meters), we recommend placing a spacer pipe between the winch and the Depth Encoder.
  • Page 11 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Set the Camera switch for the camera you are using and attach the camera to the winch cable. Mount the monitor on the winch.
  • Page 12 Allegheny Instruments, Inc. www.AlleghenyInstruments.com If glare makes viewing the monitor difficult, attach the Sunshade to the top of the monitor. A microphone can also be attached to the hole in the Sunshade. Lower the camera into the bore, place the winch cable over the Depth Encoder pulley, and secure it in place with the...
  • Page 13 Allegheny Instruments, Inc. www.AlleghenyInstruments.com If desired, connect a video recorder. If desired, connect a true sine wave inverter to a battery or a vehicle and plug the winch into the inverter.
  • Page 14 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 15: System Setup

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com System Setup Install the Tripod Legs Install the Depth Encoder  This step is easier if the winch is placed on an elevated  Attach the Depth Encoder to either the well head or surface with the rear leg sockets hanging over the to a tripod positioned over the well.
  • Page 16 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Place the Camera in the Bore  Remove the retaining pin from the top of the Depth Encoder.  Place the camera in the bore and lay the winch cable over the Depth Encoder pulley. Make sure there is no twist in the cable between the winch and the Depth Encoder.

  • Page 17: System Operation

    Turn the knob back to “ ” or turn off the Winch The GeoVISION Deluxe Winch and Control Motor switch to stop the winch. Panel are not waterproof and should be  When the camera reaches the depth that will serve as protected from water and moisture.
  • Page 18 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 19: Maintenance

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Maintenance Camera  After each use, flush the 3-pin connector on the rear of the camera with clean, fresh water. When the connector is dry, lightly coat the pins with silicone grease and cover the connector with one of the yellow nylon caps to protect it from dirt.
  • Page 20 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 21: Troubleshooting

    Control Panel’s monitor cable plug and then ensure that the monitor is firmly plugged into this cable. If you are not using a GeoVISION monitor, consult the manual for the monitor to ensure that the monitor is correctly configured for composite video input.
  • Page 22 11.5 VDC ± 0.2 volts. Adjust the voltage if necessary. If the solutions given above do not resolve your issue, please contact Allegheny Instruments in one of the following ways.

  • Page 23: Appendix A Deluxe Winch

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix A Deluxe Winch...
  • Page 24 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Deluxe Winch Control Panel 4 Camera Lights Switches 1 5-Pin Monitor Cable 5 Exposure Control Switch 2 Joystick 6 Winch Control Knob 3 Winch Motor Switch 13 OSD Buttons 11 Microphone 12 Power LED 14 Control Panel...
  • Page 25 1. 5-Pin Monitor Cable This cable is proprietary and provides power and video to a GeoVISION monitor. This cable looks similar to an S-Video cable but it is not. Plugging an S-Video cable into this cable could cause damage to the Control Panel, as well as to the device attached to the S-Video cable.
  • Page 26 The Power LED simply lights when the Control Panel is turned on. If the LED does not light, turn the system off, unplug it, check and replace the fuse if necessary. If the Power LED still does not light, contact Allegheny Instruments.
  • Page 27 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The “ ” button increments the count by 1/10 of a foot or meter. Hold the button down for 10 COUNT UP seconds to increase the speed at which the count is incremented. The “ ” button decreases the count by 1/10 of a foot or meter. Hold the button down for 10 COUNT DOWN seconds to increase the speed at which the count is decreased.
  • Page 28 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 29: Appendix B Standard Stainless Steel Cameras

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix B Standard Stainless Steel Cameras...
  • Page 30 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Standard Stainless Steel Camera Exploded View 1) MP-0145 #4-40 x 3/16 Stainless Steel Screw...
  • Page 31 Overview The Standard Stainless Steel camera is the workhorse of the GeoVISION line of cameras. Standard Stainless Steel cameras come in both color and black & white; they are extremely rugged and are designed for use in two-inch (5 cm) and larger diameter bores, up to 2,000 feet (600 meters) deep.
  • Page 32 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 3. The camera is connected to the Tilting Camera Mount which is then screwed to a Pipe-String Centralizer which is then screwed to a pipe-string. Here a pipe-string refers to multiple 10-foot lengths of ½-inch or ¾- inch pipe, fitted with a ¾-inch female pipe thread adapter on one end and a ¾-inch male pipe thread adapter...
  • Page 33 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Lightly coat the pins in the connector on the rear of the camera with silicone grease. Pass the winch cable between the open halves of the clamp, through the Cable Support Clamp body and up to the camera. Align the holes in the connector on the end of the winch cable with the pins in the camera and connect the two by rotating the knurled metal nut on the cable connector.
  • Page 34 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Slide the Centralizer Strap Clamp nearest the Cable Support Clamp towards the camera until the Centralizer Straps expand enough to easily pass through the smallest section of the bore. Configuration 3 Build as many sections of pipe-string as are needed to reach the part of the bore you wish to video but do not connect the sections together at this point.
  • Page 35 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Standard Stainless Steel Color Camera Specifications Weight 12 Ounces (340 g) Dimensions 2-7/8” long x 1-5/8” diameter (7.3 cm x 4.1 cm) Standard Lens 2.45 mm Angle of View (in air) ~150° Aperture F2.0 1/3” Sony Super HAD CCD II...
  • Page 36 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 37: Appendix C Standard Plastic Cameras

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix C Standard Plastic Cameras...
  • Page 38 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Plastic Camera Exploded View 1) MP-0145 #4-40 x 3/16 Stainless Steel Screw...
  • Page 39 Allegheny Instruments, Inc. www.AlleghenyInstruments.com NOTE: The two stainless steel #8 screws in the rear of the camera must never be removed. They are used during assembly and then the holes in the screw heads are filled with epoxy. If these screws are removed or loosened, the camera will leak.
  • Page 40 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 3. The camera is connected to the Tilting Camera Mount which is then screwed to a Pipe-String Centralizer which is then screwed to a pipe-string. Here a pipe-string refers to multiple 10-foot lengths of ½-inch or ¾- inch pipe, fitted with a ¾-inch female pipe thread adapter on one end and a ¾-inch male pipe thread adapter...
  • Page 41 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Lightly coat the pins in the connector on the rear of the camera with silicone grease. Pass the winch cable between the open halves of the clamp, through the Cable Support Clamp body and up to the camera. Align the holes in the connector on the end of the winch cable with the pins in the camera and connect the two by rotating the knurled metal nut on the cable connector.
  • Page 42 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Slide the Centralizer Strap Clamp nearest the Cable Support Clamp towards the camera until the Centralizer Straps expand enough to easily pass through the smallest section of the bore. Configuration 3 Build as many sections of pipe-string as are needed to reach the part of the bore you wish to video but do not connect the sections together at this point.
  • Page 43 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Plastic Color Camera Specifications Weight 4.5 Ounces Dimensions 3-3/8” long x 1-5/8” diameter (8.6 cm x 4.1 cm) Standard Lens 2.97 mm Angle of View (in air) ~130° Aperture F2.0 1/3” Sony Super HAD CCD II...
  • Page 44 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 45: Appendix D Nano Camera

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix D Nano Camera...
  • Page 46 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Nano Camera Exploded View 1) MP-0502 #4-40 x 3/8 Stainless Steel Screw 2) MP-1633 Buna-N #003 O-Ring 3) GVJR-1035 Nano Clamp Unthreaded Half 4) GVJR-1034 Nano Clamp Threaded Half...
  • Page 47 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Configuring the camera for use There are two primary ways to configure a Nano camera for use in a bore hole, each is listed below. A detailed description of how to assemble each of these configurations is given in the following pages unless otherwise noted.
  • Page 48 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Configuration 2 Screw the Nano Camera Adapter to the end of the centralizer. Loosen the two screws that hold the clamp together and slide the two halves apart. Pass the winch cable through the clamp and the centralizer and out through the adapter.
  • Page 49 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Slide the centralizer down to the Nano camera so that the Nano Camera Adapter slides over the end of the camera. Tighten the Cable Support clamp so that the Nano Camera is now firmly connected to the centralizer assembly.
  • Page 50 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Nano Camera Specifications Weight 10.1 Ounces (286 g) Dimensions 10-1/4” long x 3/4” diameter (26 cm x 2 cm) Standard Lens 2.97 mm Angle of View (in air) ~130° Aperture F2.0 1/3” Sony Super HAD CCD II...

  • Page 51: Appendix E Nano Rotating Mirror

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix E Nano Rotating Mirror...
  • Page 52 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Nano Rotating Mirror Exploded View 1) MP-1480 #4-40 x 1/8 Stainless Steel Set Screws 2) MP-1589 Buna-N #014 O-Rings 3) GVJR-1097 Nano Rotating Mirror Rear End Cap...
  • Page 53 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Battery Installation Install the batteries in the mirror in one of two ways depending on the desired results. Once the batteries are installed, tighten the knurled rear end cap to turn on the motor and loosen it to turn the motor off.
  • Page 54 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Nano Rotating Mirror Specifications Weight 9.5 Ounces (270 g) Dimensions 9-3/4” long x 15/16” diameter (22 cm x 2.3 cm) Batteries 2 CR2 Lithium 3Volt Operating Temperature -4° F ~ 167° F (-20° C~75° C) Maximum Depth...

  • Page 55: Appendix F Dual-Scan Camera

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix F Dual-Scan Camera...
  • Page 56 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Dual-Scan Camera Exploded View 1) MP-0135 #8-32 x 1/4” Stainless Steel Screw 7) MP-1670 18 mm x 1 mm Buna-N O-Ring 2) MP-0152 #8-32 x 5/8” Stainless Steel Screw 8) GVJR-0821 Centralizer Clamp Half #2 3) MP-1714 #4-40 x 3/16” Stainless Steel Screw 9) GVJR-0822 Centralizer Clamp Half #1 4) MP-0700 #2-56 x 3/16”...
  • Page 57 Introduction The GeoVISION Dual-Scan camera is Allegheny Instruments most advanced camera ever. It has three independently controlled banks of high intensity LED lights and the ability to rotate more than 360°. The Dual- Scan's state of the art video modules provide unparalleled video images in bores as small as 1-1/2" (4 cm) in diameter and up to 2,000 feet (600 meters) deep.
  • Page 58 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 4. If needed, lightly coat the pins in the connector on the rear of the camera with silicone grease, align the holes in the connector on the end of the winch cable with the pins and connect the camera to the winch cable by rotating the knurled metal nut on the cable connector.
  • Page 59 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 9. Turn on the winch and check that all three banks of lights work correctly by using the three light switches. Move the Joystick up and then release it to switch to the side looking camera move the joystick down and then release it to switch to the down looking camera.
  • Page 60 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 61: Appendix G Pan-Tilt Control

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix G Pan-Tilt Control...
  • Page 62 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Pan-Tilt Control Explode View 15 15 1) MP-0152 #8-32 x 5/8” Stainless Steel Screw 2) MP-0145 #4-40 x 3/16” Stainless Steel Screw 3) MP-0110 #4-40 x 5/16” Stainless Steel Screw 4) MP-0502 #4-40 x 3/8” Stainless Steel Screw 5) MP-0502 #4-40 x 1/2”...
  • Page 63 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Pan-Tilt Centralizer Exploded View 1) MP-0135 #8-32 x 1/4” Stainless Steel Screw 2) MP-0152 #8-32 x 5/8” Stainless Steel Screw 3) MP-0191 #4-32 x 1/2” Stainless Steel Screw 4) MP-0507 #005 Buna-N O-Ring 5) GVJR-0821 Centralizer Clamp Unthreaded Half...
  • Page 64 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Introduction The GeoVISION Pan-Tilt Control is designed to rotate and tilt Standard Stainless Steel and Standard Plastic cameras inside a borehole. Using a Pan-Tilt Control, these cameras can be rotated 360-degrees and can tilt from looking straight down, to looking back up the bore. Camera manipulation is controlled using the joystick on a Deluxe Winch Control Panel.
  • Page 65 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 14. Tighten the clamp on the Pan-Tilt Control firmly around the cable. Loosely tighten the halves of the Centralizer clamp around the cable. Be sure the winch cable can slide through the clamp. 15. Slide the Centralizer clamp down the cable towards the Pan-Tilt Control to flare the Centralizer Straps. The straps should be narrower than the smallest section of the bore you are going into.
  • Page 66 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Removing the camera from a Pan-Tilt Control Attaching a camera to the Pan-Tilt Control is quite simple provided the camera was properly removed. To properly remove a camera from a Pan-Tilt Control, use the following procedure.
  • Page 67 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 20. Remove screw #13. For a Standard Plastic Camera you will need to use the aluminum wrench as in step #4, for a Standard Stainless Steel Camera, there is no nut, so you will not need the wrench.
  • Page 68 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 22. Reinstall screw #9 and its nut on the upper strap. If you are removing a Standard Stainless Steel Camera, pass screw #13 through the lower strap and then through the pulley and screw a #8-32 nut onto it, don’t forget to place screw #14 in the pulley first, you will find an #8-32 nut in the spare parts that came with your system.
  • Page 69 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Reinstalling the camera on a Pan-Tilt Control This section covers reattaching a camera that was removed using the above process. If your camera was not removed using the above procedure, skip ahead to the next section.
  • Page 70 Allegheny Instruments, Inc. www.AlleghenyInstruments.com For a Standard Plastic Camera, install screw #12 through the lower strap, a #8 nut and into the camera. Note that the camera’s Accessory Attachment screw is facing out and the Tilt Pulley is on the bottom. Tighten the screw so that the camera can rotate freely and yet the screw head is close to the camera body, then using the flat aluminum wrench that came with the system, tighten nut #8 to pinch the pulley against the camera body.
  • Page 71 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 4. If necessary, loosen the screw that clamps the ends of the tilt cord (#5) and adjust the tension of the cord so that the camera has approximately 1/4” of free play. When done correctly, the cord will be loose enough to allow the front of the camera to rotate approximately 1/4”...
  • Page 72 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Reassembly of a Pan-Tilt Control This section covers setting up a Pan-Tilt Control that has been completely stripped. While this is usually not the case, steps 4 through 9 are critical and need to be performed each time a camera is attached.
  • Page 73 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 4. Set the Camera Select Switch on the winch to the “Pan-Tilt with Camera” position as shown. 5. Align the holes in the yellow Curled Cord with the pins in the camera and screw the two together. Do not attach the camera to the Pan-Tilt Control at this time.
  • Page 74 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 10. Slide the Tilt Shaft Pulley #21 over the Tilt Shaft with the Tilt Cord Clamping Screw #11 facing away from you. 11. Position the Tilt Shaft Pulley so that there is a small, but visible gap between the pulley and the Turntable.
  • Page 75 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 14. Clamp the Tilt Cord to the Camera Tilt Pulley as shown below, the measurements are approximates and will be fine tuned later.. A Standard Stainless Steel Camera uses a #2-56 x 5/16” screw and a Tilt Cord Clamp, it will look like this.
  • Page 76 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 16. Place the camera between the Camera Mounting Straps #20. Align the holes in the yellow curled cord with the pins on the camera and using fingers only, tighten the yellow curled cord to the camera. Attach the camera and the Camera Tilt Pulley to the Pan-Tilt Control.
  • Page 77 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 17. Place nut #9 between the camera and the upper strap and install screw #8 through the strap and the nut and into the camera. Tighten the screw so that the camera can rotate freely and yet the screw head is close to the camera body, then using the flat aluminum wrench that came with the system, tighten nut #8 against the camera body.
  • Page 78 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 19. Turn the entire assembly over, loosen the Cord Clamping Screw #11 and cross the two ends of the cord under the screw. 20. Lift the ends of the cord toward the camera. This will wrap each end around the screw. Pull the ends so that they are even and then tighten the clamping screw to hold them in place.

  • Page 79: Appendix H Fixed Camera Mount

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix H Fixed Camera Mount...
  • Page 80 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Fixed Camera Mount Exploded View...
  • Page 81 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Fixed Camera Mount allows you to mount the camera in a fixed position. It can be used with either the plastic or Standard Stainless Steel Camera and is the most commonly used mount for these cameras.
  • Page 82 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Fixed Camera Mount must be used with a Cable Support Clamp. Attach the Cable Support Clamp directly to the Fixed Camera Mount, or to a centralizer which is then connected to the Fixed Camera Mount.

  • Page 83: Appendix I Tilting Camera Mount

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix I Tilting Camera Mount...
  • Page 84 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Tilting Camera Mount Exploded View...
  • Page 85 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Tilting Camera Mount is designed for use with a pipe-string when rotating and tilting the camera are required. It can be used with either a plastic or Standard Stainless Steel camera. The Tilting Camera Mount comes fully assembled and ready for the camera. There are two screws that join the camera to the mount, #4 and #5 in the exploded view on the previous page.
  • Page 86 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Pass the male end of the flexible cable through the bottom of the Centralizer and out through the hole in the side. Lightly coat the pins in the camera’s connector with silicone grease and Screw the Centralizer to the tilting Camera mount.

  • Page 87: Appendix J Standard Centralizer

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix J Standard Centralizer...
  • Page 88 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Centralizer Exploded View 1) MP-0152 2) MP-0153 #4-40 x 1/4 Stainless Steel Cap Screw 3) GVJR-1001 Plastic Clamp 4) GV-0014 Stainless Clamp Strap 5) MP-1712 #4-40 x 5/8 Stainless Steel Socket Head Cap Screw 6) MP-0135...
  • Page 89 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Centralizer is used to keep the camera and lights away from the walls of the bore. It should always be used with a Cable Support Clamp unless it is attached to a pipe-string. The Centralizer can be used in combination with many...
  • Page 90 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 91: Appendix K Cable Support Clamp

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix K Cable Support Clamp...
  • Page 92 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Cable Support Clamp Exploded View 1) MP-0152 #8-32 x 5/8 Stainless Steel Screw 2) MP-0145 #4-40 x 3/16 Stainless Steel Screw 3) MP-0153 #4-40 x ¼ Stainless Steel Screw 4) GVJR-0014 Stainless Steel Strap 5) GVJR-1001 Acetal Splice Clamp...
  • Page 93 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Cable Support Clamp is used primarily to support a camera without a centralizer or auxiliary lighting as illustrated here.
  • Page 94 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 95: Appendix L Auxiliary Single Light

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix L Auxiliary Single Light...
  • Page 96 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Auxiliary Single Light Holder Exploded View 1) MP-1719 #8-32 x 3/4 Stainless Steel Screw 2) GVJR-1290 Single Light Holder...
  • Page 97 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Auxiliary Single Light is composed of one light and a Single light holder. To attach the Auxiliary Single Light, remove the two screws and separate the two halves of the holder. Place the cable in the slot in the holder’s bottom half, place the upper half of the holder over the cable, replace the screws but do not tighten them.
  • Page 98 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 99: Appendix M Auxiliary Double Light

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix M Auxiliary Double Light...
  • Page 100 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Auxiliary Double Light Holder Exploded View 1) MP-1720 #8-32 x 1 Stainless Steel Screw 2) MP-0145 #4-40 x 3/16 Stainless Steel Screw 3) GVJR-1315 #4-40 x ¼ Double Light Holder...
  • Page 101 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Overview The Auxilliary Double Light can be used with either a Standard Stainless Steel or Standard Plastic camera. The light holder mounts directly to the camera and can be used with a fixed camera mount or with a Pan-Tilt Control.
  • Page 102 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Secure the lights to the camera by reinserting and tightening the Attachment screw and tighten the two long screws to firmly clamp them in the holder..

  • Page 103: Appendix N Auxiliary Fixed Eight Light

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix N Auxiliary Fixed Eight Light...
  • Page 104 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Auxiliary Fixed Eight Light Holder Exploded View 1) MP-0152 #8-32 x 5/8 Stainless Steel Screw 2) GVJR-1210 Fixed Eight Light Holder...
  • Page 105 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Overview The Auxiliary Fixed Eight Light is designed for use in very large bores or in bores with very dark walls. The light clamps onto the winch cable and can be positioned anywhere above the camera. The larger the bore, the farther the lights should be placed from the camera.
  • Page 106 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Pass the winch cable through the clamp and the holder and clamp the assembly to the cable. The Auxiliary Fixed Eight Lights can be used in many configurations, a few are shown below.

  • Page 107: Appendix O Auxiliary Adjustable Eight Light

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix O Auxiliary Adjustable Eight Light...
  • Page 108 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Auxiliary Fixed Eight Light Holder Exploded View 1) GVJR-1329 c 2) MP-0189 #8-32 x 3/8 SS Rotation Locking Screw 3) MP-0189 #8-32 x 3/8 SS Pivot Adjustment Screw 4) MP-0189 #8-32 x 3/8 SS Light Clamping Screw...
  • Page 109 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Overview The Auxiliary Adjustable Eight Light is designed for use in very large bores or in bores with very dark walls. The light clamps onto the winch cable and can be positioned anywhere above the camera and adjusted to point anywhere from straight down to nearly straight out.
  • Page 110 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Loosen the two large screws in the Cable Support Clamp, slide the two halves of the clamp sideways and open the clamp. Pass the winch cable through the clamp and holder assembly, slide the two halves of the clamp together over the cable and tighten the screws to clamp the lights to the cable.
  • Page 111 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Auxiliary Adjustable Eight Lights can be used in many configurations, a few are shown below.
  • Page 112 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 113: Appendix P Emergency Crank Handle

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix P Emergency Crank Handle...
  • Page 114 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Emergency Crank Handle Exploded View 1) MP-1442 1/2-13 x 1” Stainless Steel Button Head Cap Screw 2) GVJR-0994 Aluminum Deluxe Crank Shaft 3) MP-1581 1/4-20 Stainless Steel Nut 4) MP-1243 Deluxe Crank Handle...
  • Page 115 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Emergency Crank Handle is designed for use in the event of winch motor failure. The following procedure describes the installation and use of the Emergency Crank Handle. 1. Remove the 1/2 by 1 inch bolt from the center of the winch shaft. It is located on the opposite side of the winch from the Control Panel.
  • Page 116 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 3. While holding onto the Emergency Crank Handle, turn off the Control Panel and unplug the winch. 4. Remove the 8 screws that hold the Control Panel to the winch and unplug the Control Panel from the winch.
  • Page 117 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 6. Grasp the end of the brass key and gently pull it out. If the key does not come out easily, use the Emergency Crank Handle to gently rotate the shaft clockwise and then counter-clockwise until the key can be removed.
  • Page 118 Allegheny Instruments, Inc. www.AlleghenyInstruments.com...

  • Page 119: Appendix Q Cable End Replacement Kit

    Allegheny Instruments, Inc. www.AlleghenyInstruments.com Appendix Q Cable End Replacement Kit...
  • Page 120 Allegheny Instruments, Inc. www.AlleghenyInstruments.com Cable End Replacement Kit Contents 5) MP-1462 Two 0.5 oz Tubes of 2 Ton Epoxy 6) GVJR-0968 Cable End Connector with Hex Key...
  • Page 121 Allegheny Instruments, Inc. www.AlleghenyInstruments.com The Cable End Replacement Kit contains the parts necessary to replace the connector on the end of the winch cable. While the connector can be replaced using only this kit, it is highly recommended that the cable be soldered to the connector before the connector is filled with epoxy.
  • Page 122 Allegheny Instruments, Inc. www.AlleghenyInstruments.com 6. Insert the cable into the connector and tighten the set screws to lock the conductors in place. Be very careful not to lose the tiny set screws because there are no extras. Use the following images as a reference.

  • Page 123: Limited Warranty

    Before returning any component you must c ontact Allegheny Instruments for an RMA number. Failure to obtain an RMA number could result in the return of all parts without repair. To obtain an RMA number, contact Allegheny Instruments in one of the following ways.
