RMDC Series Installation Instructions 52-376 Rev B01
Rack Mount DC Power Supplies
Operating and
Installation
Instruction Manual
Includes PS5-M Power Supplies &
FAI Accessory Boards
MEA
Approved
AlarmSaf, Inc.
65A Industrial Way, Wilmington, Massachusetts 01887
978-658-6717 800-987-1050
www.alarmsaf.com
Advertisement
Table of Contents
Related Manuals for AlarmSaf RMDC Series
Summary of Contents for AlarmSaf RMDC Series
- Page 1 RMDC Series Installation Instructions 52-376 Rev B01 Rack Mount DC Power Supplies Operating and Installation Instruction Manual Includes PS5-M Power Supplies & FAI Accessory Boards Approved AlarmSaf, Inc. 65A Industrial Way, Wilmington, Massachusetts 01887 978-658-6717 800-987-1050 www.alarmsaf.com...
-
Page 2: Table Of Contents
When installed in accordance with all standards listed on page 3 of primary power source. this document, the RMDC series provides DC power for DC CCTV Screw-secured plug-in terminal strips for field wiring cameras, access control equipment, IT equipment and related Removable face plate for ease of serviceability accessories, or other DC powered devices. -
Page 3: Rmdc Model Descriptions
Technical Repair Department will not be considered under warranty. warranty except on certain products where the warranty is specifically AlarmSaf will not be obligated to repair or replace any product not designated as two (2) years. The lifetime warranty will be in effect under warranty. -
Page 4: Section 1: Overview
REPLACE FUSES ONLY WITH SWITCH JP4 ABC BUSS OUTPUT SAME STYLE AND RATING MODEL PS5–M FUSE RATING: ATM 15A CONFIGURATION JUMPER COMMON FAULT AC FAULT GROUND FAULT VISUAL INDICATOR VISUAL INDICATOR VISUAL INDICATOR AlarmSaf, Inc. 65A Industrial Way, Wilmington, MA 01887 978-658-6717 www.alarmsaf.com... -
Page 5: Terminal Descriptions
See Page 10, Appendix A for FAI connection examples. AlarmSaf offers an RMBE Battery Enclosure for use with the RMDC series power supplies. It provides battery backup in 1.3 FUSES a standard 19 inch 2RU rack mountable enclosure. -
Page 6: Section 2: Installation
– + – + – + – + – + – + – + – + – + Model Shown: RMDC-PS5-MD-16F-UL-FAI OUTPUTS 9 –16 AC INPUT OUTPUTS 1 – 8 AlarmSaf, Inc. 65A Industrial Way, Wilmington, MA 01887 978-658-6717 www.alarmsaf.com... -
Page 7: Section 3: Operation
Jumper is D13 D12 38-137 REV B01 DC1 DC2 ATM -10 provided without a default setting. Installer must select setting. FAI INPUT PWR LTD DC 2 AlarmSaf, Inc. 65A Industrial Way, Wilmington, MA 01887 978-658-6717 www.alarmsaf.com... - Page 8 DE’BRANCHER AVANT DEREMPLACER LE FUSIBLE JP10 JP11 JP12 JP13 JP14 JP15 JP16 SPARE REFER TO NAMEPLATE LABEL FOR INSTALLATION DOCUMENT ZONES 1 - 8 ZONES 9 - 16 REFERENCE NUMBER AlarmSaf, Inc. 65A Industrial Way, Wilmington, MA 01887 978-658-6717 www.alarmsaf.com...
-
Page 9: Visual Indicators
Indicators on the PS5-M board DESCRIPTION COLOR CONDITIONS B1: Illuminates when AC voltage is present on Buss 1of the ABC Connector. In the RMDC series this voltage is sourced from the AC ON (D19) AC Power Green Lights when AC... -
Page 10: Appendix A: Fai Input Connection Methods
RMDC Series Installation Instructions 52-376 Rev B01 APPENDIX A: FAI INPUT CONNECTION METHODS Warnings and Notices The RMDC series can be ordered with an optional FAI input to collector for activation. disable the power to selected outputs upon activation of the FAI These diagrams show various wiring methods. -
Page 11: Appendix B: Enclosure Cad Drawing
RMDC Series Installation Instructions 52-376 Rev B01 APPENDIX C: ENCLOSURE CAD DRAWING Warnings and Notices 3.25” 18.80” 9.94” 1.20” 1.20” 0.75” 0.75” 0.68” 3.25” 0.82” 16.87” 0.38” DETAIL “A” 0.38” TYPICAL 4 PLACES 0.25” Ø 0.19” AlarmSaf, Inc. 65A Industrial Way, Wilmington, MA 01887 978-658-6717 www.alarmsaf.com... -
Page 12: Troubleshooting
Verify presence of at least 102VAC on the input, the AC switch indicates fault condition is “ON” and the input circuit breaker is not tripped. Blown AC fuse on the internal PS5-M This fuse is not replacable. Contact AlarmSaf. No battery presence Battery not connected... -
Page 13: Glossary
RMDC Series Installation Instructions 52-376 Rev B01 GLOSSARY See “Accessory Board Connector.” Accessory Board Connector Connector on some AlarmSaf power supplies and accessory boards, allowing plug-in expansion of the system. Accessory Board AlarmSaf product used with AlarmSaf power supplies having an ABC connector. These boards allow plug-in expansion of system functionality.
