- Page 1 User Manual CAM-KIT15 Solar Wireless Digital Reversing System...
- Page 3 Welcome Thank you for purchasing the CAM-KIT15. This solar-powered wireless digital reversing system is designed to make it easier and safer to manoeuvere and park your vehicle. Please read the instructions carefully before installing and using the product. We reserve the right to modify printing errors or update specifications without prior notice.
-
Page 4: Table Of Contents
- CONTENTS - 1. Components..........4.2 Operate the Monitor......2. Getting Started..........4.3 Choose the Size of Guideline..... 2.1 Charge the Battery........5. Indication of Battery Power....2.2 Test the System........6. Battery Replacement of the 3. Installation............. Remote Control.......... 3.1 Adjust Camera Angle...... -
Page 5: Components
Components Backup Camera Assembly Remote Control Monitor Monitor Suction Mount ( Backup camera, solar battery unit ) User Manual Solar Wireless Digital Reversing System Car Charger Line (3.5 meters) Battery Charging Cable (1.5 meters ) User Manual... -
Page 6: Getting Started
Getting Started 2.1 Charge the Battery Use your existing USB charging port to initially charge your device before you install it on your vehicle and charge it when needed. 1. Connect the included USB cable to the Micro USB port of the solar battery unit. 2. -
Page 7: Test The System
Attention： 1. If the vehicle is parked for more than 2 months, turn off the solar battery unit switch to disable the camera and prevent the battery from discharging. 2. If you use a power bank or a jump starter to charge the device, make sure that its battery capacity is no less than 4000mA. -
Page 8: Installation
Installation 1. Remove the license plate from the vehicle. Clean the mounting surface of the licence plate on the car. 2.1. Mark the mounting location of the solar battery unit and backup camera on the license plate. 2.2. Remove the 3M glue on the front of solar battery bracket and the backup camera bracket. -
Page 9: Adjust Camera Angle
4. Put your license plate back on your vehicle and fix it. 3.1 Adjust Camera Angle Adjust the angle of the camera as needed: ● Tilt the camera to the correct angle. ● The camera should be adjusted to a horizontal position relative to the ground in order to provide the best view of the objects behind the vehicle. -
Page 10: Mount The Monitor
3.2 Mount the Monitor Find a mounting surface where the monitor can be easily seen inside the car, and does not obstruct your vision when driving. Note: Before permanently mounting the monitor, test the reception of the camera signal in several selected locations within easy reach as one may have better reception than another. - Page 11 3. Slide the monitor into the bracket. The angle of the monitor can be adjusted by loosening or tightening the rotary knob. 4. Insert the monitor car charger into the 12V DC power supply. ( 3 ) ( 4 ) Note: 1.
-
Page 12: Install Remote Control
3.3 Install Remote Control This solar wireless digital reversing camera system comes with a wireless remote control, which is used to activate the rear view camera. Remove the 3M adhesive film on the back of the remote and fix it in the chosen place: For example, 1. -
Page 13: Operate The Monitor
① ② ③ Tips: Pressing any button on the side of the monitor also activates the camera. 4.2 Operate the Monitor The indicator light is always red after the monitor is powered, which indicates the monitor is on and standby. Pressing any button on the side of the monitor you will see rear view image. -
Page 14: Choose The Size Of Guideline
Reversing Time: set the duration of reversing display time Guide Line: activate or deactivate the guide lines Reset: return to factory settings Tips: Normally, the pair between the camera and monitor has been done before they leave the factory. The “Pair” button will only be effective when you need to replace the camera. -
Page 15: Battery Replacement Of The
Battery power status Relative power Estimated duration Note ≈ 100% ≈ 60days ≈ 70% ≈ 45days ≈ 40% ≈ 24days ≤ 20% ≈ 12days Need to charge Note: Low temperature may drastically decrease the performance of the built-in lithium battery. This product can work at ambient temperatures as low as -20 °C. -
Page 16: Troubleshooting
1. Open the remote control shell. Use a small flat screwdriver and insert the blade into the slot. 2. Turn the screwdriver blade to separate the shell completely. 3. Slide the battery out of the holder for replacement. 4. Insert a new button cell and make the positive pole (+) up. (The positive pole has a “+” mark and it tells the battery type) 5. - Page 17 Error / malfunction Possible causes Solutions / repair If the indicator light on the monitor does not flicker after pressing the remote control(normally it will flicker twice), but the monitor can be activated and displays images when you press any button on the monitor. In this case the signal connection between the remote control and the monitor may be interrupted.
- Page 18 Error / malfunction Possible causes Solutions / repair 2. Press the “▲” or “▼” button to choose a matching channel(C1 or C2). Press M button to confirm and the icon flickers. The signal connection 3. Press the remote control, when you see the between remote control “NO”...
- Page 19 Error / malfunction Possible causes Solutions / repair C. Reconnect the monitor to the camera Please try to pair the monitor with the camera as following steps : 1. Power the monitor and press M button to enter the menu. 2.
- Page 20 Error / malfunction Possible causes Solutions / repair Check the screws which fix the camera angle, tighten these screws if necessary. The screws that fixes the camera angle are loose. The image shakes when the vehicle is moving. Check the screws that attach the camera to vehicle, tighten these screws if necessary.
-
Page 21: Care And Maintenance
Care and Maintenance Please do not use solvents or chemicals to clean or wipe the camera. If necessary, use a soft cloth dipped in neutral detergent to clean the dirt or stains. Disposal The system is designed to provide years of service and should be recycled or safely disposed of at a local recycling center. - Page 22 Monitor Operational Current <250mA Operating Voltage DC12V Standby Current 90mA Effective Pixels 480 x 272 Operation Temperature -4°to 149°F(-20°to 65°C) Storage Temperature -4°to 149°F(-20°to 65°C)
- Page 24 Ver-3.0...
