QUAR TZ J A PA N CHRO NO GR APH WI TH DAT E
SETTING THE TIME
1. Pull the crown out to the 2nd position.
2. Turn the crown clockwise to set hour and minute hands.
3. When the crown is pushed back to the normal position, small second hand
begins to run.
SETTING THE DATE
1. Pull the crown out to the 1st position.
2. Turn the crown clockwise to set the date.
*If the date is set between the hours of around 9:00 PM and 1:00 AM, the
date may not change on the following day.
3. After the date has been set, push the crown back to the normal position.
USING THE CHRONOGRAPH
This chronograph is able to measure and display time in 1/1 second united up
to maximum of 60 minutes.
The chronograph second hand keeps continuously for 60 minutes after
starting. Measuring time with the chronograph
SECOND HAND
HOUR HAND
CHRONOGRAPH
HOUR HAND
DATE
CHRONOGRAPH
SECOND HAND
BUTTON A
[ START / STOP ]
MINUTE HAND
2ND POSITION
1ST POSITION
NORMAL CROWN
POSITION
BUTTON B
[ SPLIT / RESET ]
24H HAND
