Summary of Contents for halo connect IN-100CM
- Page 1 USER MANUAL IN-100CM Keep this manual in the vehicle for future reference. Read this manual before using this product. Failure to follow the instructions and safety precautions in this manual may result in serious injury or death.
-
Page 3: Important Safety Information
The Halo Connect Gateway and its components should be installed and maintained in accordance with the instructions in this manual. Proper installation of the Halo Connect is critical to ensure safe use of the device. Failure to do so may result in injury or death, damage to equipment, material or property. -
Page 4: Table Of Contents
Safety Words and Symbols Introduction Getting Started System Components Installation Tools Halo Connect Installation Affix gateway ID sticker to vehicle Determine where to put the Gateway Locate power source and ground Attach TPMS antenna to vehicle Attach GPS antenna to vehicle... - Page 5 Halo Connect Gateway The Halo Connect Gateway is comprised of a durable enclo- sure that is secured in the cab of the vehicle. It uses a built-in LTE cellular connection to send data to the cloud, TPMS to talk to the sensors, and a bluetooth connection to talk to mobile devices.
-
Page 6: Getting Started
Getting started SYSTEM COMPONENTS HALO Connect Gateway • Pack of Halo Connect sensors • Power cable with mini fuse connector • TPMS cable • TPMS antenna • Cellular antenna • GPS antenna INSTALLATION TOOLS • 5/16" Hex Head Screwdriver •... -
Page 7: Halo Connect Installation
HALO CONNECT INSTALLATION 1. AFFIX GATEWAY ID STICKER TO VEHICLE Select an easy to access location to permanently attach the gateway ID sticker inside the vehicle. The gateway ID sticker contains gateway identification infor- mation used to pair the gateway when using the phone app. -
Page 8: Determine Where To Put The Gateway
HALO CONNECT INSTALLATION, CONT'D 2. Determine where to put Gateway Select a location to permanently attach the Gateway box inside the cab of the vehicle. Consider that the Gateway will have power and antenna ca- bles attached to it that need to be routed to locations specified in later steps. -
Page 9: Locate Power Source And Ground
HALO CONNECT INSTALLATION, CONT'D 3. locate power source and ground In order for the vehicle's tires to be monitored 24 hours, the Gateway power cable should be connected to a 24 hour con- tinous 12-20V power source and be securely grounded to the vehicle chassis. -
Page 10: Attach Tpms Antenna To Vehicle
HALO CONNECT INSTALLATION, cont'd 4. attach TPMS antenna to vehicle The TPMS antenna must be placed outside on the rear of the vehicle and the cable needs to be routed back to the Gateway. Find an opening in the cab to route the antenna cable from the Gateway to the outside of the vehicle. -
Page 11: Attach Gateway To Vehicle
HALO CONNECT INSTALLATION, cont'd 6. Connect cables to gateway On the gateway, the side label marks the port for each of the cables, as seen below: ANTENNAS Ensure the cables are securely attached to the Gateway to avoid loosening due to vibration during vehicle operation. -
Page 12: Install Tpms Sensors
10. Pair gateway using mobile app On the Gateway, ensure that the Ready LED is emitting blue. Download the Halo Connect mobile app to a compatible de- vice, and complete the pairing process. Ready Error Power... -
Page 13: Regulatory
Regulatory RF Exposure This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled envi- ronment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. - Page 14 Robert Lawson Email: robert.lawson@aperiatech.com Phone No.: 16507413231 Fax No.: 4152734649 Product details Product: Halo Connect Gateway Brand name: Aperia Technologies Model name: GW-10, GW-20 Manufacturer: Volansys Technologies Pvt Ltd. A-503, Mondeal Square, Near Crown Plaza Hotel, S. G Address: Highway, Ahmedabad 380 015, Gujarat.
- Page 16 QTY: Part Number: IN-100CM Description: User Manual, Halo Connect Aperia Technologies, Inc. © 2019 Aperia Technologies, Inc. 1616 Rollins Rd. IN-100CM Burlingame, CA 91040 91-00006672 Rev. R02 Phone: (650) 741-3231 PMN: Halo Connect Gateway Fax: (415) 524-2449 Model No.: GW-10 (for xBR type sub-1GHz Rx) www.aperiatech.com...
