Summary of Contents for RackSolutions 108-6899
- Page 1 Adjustable 2-Post Shelf Installation Instructions Kit P/N: 108-6899...
- Page 2 Kit Contents Rack Mount Hardware x4: Kit Contents: (1) Adjustable 2-Post Shelf (4) #10-32 Phillips Head Screws (1) #10-32 Phillips Head Screw (4) #12-24 Phillips Head Screws (2) Push-In Bumpers (4) #12-24 Square Nuts (1) Velcro Strap (4) #12-24 Cage Nuts Installation Instructions Step 1 Unlock the Shelf: Loosen the #10-32 Screw attached to the shelf, but do not remove...
- Page 3 Installation Instructions Step 3 Install Device and Lock Shelf in Position: Place the device on the shelf and tighten the #10-32 Screw to lock the shelf into place. #10-32 Screw Step 4 Install Push-In Bumpers: Slide the Push-In Bumpers to an appropriate location along the rear slots to secure the back of the device.
- Page 4 Installation Instructions Step 5 Mount the Shelf: Using the hardware pack, Rack Mount Hardware x4, install the #12- 24 Cage Nuts to the rack and then screw the shelf into the Cage Nuts with the #12- 24 Screws. #12-24 Cage Nuts #12-24 Screws Step 6 Install Velcro: If necessary, secure any device accessories in the side shelf with...
