- Page 1 STULZ the natural choice Technical Manual Technical Manual Humidifi cation Version 01-2015 1000645 / EN STULZ UltraWater ® Humidifi cation STULZ UltraWater 3 Stufen-Umkehrosmosesystem 3-stage reverse osmosis systems Version 05-2012 Translation of the original User Guide – Read carefully before use-...
- Page 2 Dear Customer, Many thanks for choosing to buy a STULZ product. STULZ has been a purveyor of sophisticated technical solutions for comfort and precision air conditioning applications since 1947. Hotline If you have any questions or problems regarding our products, please get in touch via our hotline on +49 40 5585 252 or at hotline@stulz.de.
-
Page 3: Table Of Contents
STULZ UltraWater 3-stage reverse osmosis system SUW Contents INFORMATION ON THIS GUIDE ............5 1.1. - Page 4 STULZ UltraWater 3-stage reverse osmosis system SUW START-UP ...............32 OPERATION .
-
Page 5: Information On This Guide
STULZ UltraWater 3-stage reverse osmosis system SUW Information on this guide INFORMATION ON THIS GUIDE This guide is part of the product package. It must be made accessible to all persons performing assembly, installation, start-up and maintenance work on the product. -
Page 6: Nomenclature
SUW 400 1.4. Liability claims for defects Following the instructions in the Technical Manual is a prerequisite for trouble-free operation of the STULZ UltraWater and for eventual claims for defects. Read the Technical Manual before working with the product. 1.5. -
Page 7: Safety Instructions
(tap water and surface water has up to approx. 1000 mg/l). If STULZ systems are used for water of a different quality, it is essential that you first contact STULZ. -
Page 8: Personnel Qualification
STULZ UltraWater 3-stage reverse osmosis system SUW Safety instructions 2.4. Personnel qualification All electrotechnical work must be performed exclusively by authorized and trained specialist personnel. Specialist personnel within the context of this documentation are persons who are familiar with the electrical... -
Page 9: Safety Instructions For Maintenance, Inspection And Installation Work
• We recommend the use of genuine spare parts. Genuine spare parts and spare parts/accessories ap- proved by STULZ GmbH are a guarantee of safety. • The spare parts list can be found in the following section: Spare parts. To order spare parts, call the hotline or your specialist retailer. - Page 10 The system may only be converted or modified following consultation with STULZ. Original spare parts and parts/accessories approved by STULZ are a guarantee of safety. Use of different parts may void any liability for claims arising from any possible consequences.
- Page 11 STULZ UltraWater 3-stage reverse osmosis system SUW Safety instructions We recommend you to read this “SAFETY PRECAUTIONS” carefully before the installation work in order to gain full advantage of the functions of the unit and to avoid malfunction due to mishandling.
-
Page 12: Transport / Storage
STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage TRANSPORT / STORAGE Before transport, fully drain the system and seal with plugs to prevent water from escaping. Pack the system in a sufficiently large and cushioned cardboard box (preferably the original box) for transport, to prevent damage. -
Page 13: About This Device
About this device ABOUT THIS DEVICE The STULZ UltraWater is intended for the treatment of drinking water for use in ultrasonic humidifiers. Adiabatic humidifying systems produce cold mist and must be supplied with demineralized drinking water, in order to ensure that the vibrating elements continue to function throughout the life of the system, and to prevent any buildup of limescale in the system or in the humidified room. -
Page 14: The Principle Of The Reverse Osmosis System
STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage 6.1. The principle of the reverse osmosis system If two solutions with different ion concentrations – aqueous solutions with different salt content – are sepa- rated by a semi-permeable membrane, the solutions attempt to equalise the concentration. This attempt Reverse osmosis technology results in ions from the aqueous solution, with the higher concentration trying to “migrate”... -
Page 15: Product Package
6.2. Product package STULZ UltraWater reverse osmosis systems are delivered fully preassembled. The system must be tight- ened and supplied with water and electricity. In addition, it must be connected to the pressure tank. Please check that your delivered product is correct and complete. -
Page 16: Rating Plate
6.3. Rating plate The rating plate contains the most important data for identifi cation of the STULZ UltraWater, and concern- ing the application limits. The rating plate is affi xed to the base plate of the UltraWater. The data on the rating plate are required for the following: •... -
Page 17: Technical Data
STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage 6.4. Technical data Model SUW 120 basic SUW 400 basic Permeation rate 12 l/h 288 l/d 40 l/h 960 l/d Retention rate Waste water/pure water ratio Operating temperature 4…30°C 4…30°C Ambient temperature 5…35°C... -
Page 18: Filter Service Life
• Filterbehuizing met dubbele O-ring afdichting IJzer- en mangaanconcentratie: onder 0,1 mg/l ning en mag er zich geen strontium en barium in het leidingwater bevinden. STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage • Automatische afsluiter en terugslagklep van roestvast staal Bedrijfscondities •... -
Page 19: Device Construction
STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage 6.8. Device construction 6.8.1. UltraWater 120 Gehäuse entgraten, O-Ring mit Vaseline The system comprises an installation board with the actual reverse osmosis systems, and a pressure tank for storing the pure water: 1. -
Page 20: Ultrawater 400
STULZ UltraWater 3-stage reverse osmosis system SUW Transport / storage 6.8.2. UltraWater 400 Gehäuse entgraten, O-Ring mit Vaseline The system comprises an installation board with the actual reverse osmosis systems, and a pressure tank for storing the pure water: Terminal assignments: 1. -
Page 21: Installation
STULZ UltraWater 3-stage reverse osmosis system SUW Installation INSTALLATION To ensure safe operation of the system, the erection standards of DIN VDE 100 must be complied with. If the equipment is installed in an environment in which no leakage must occur, a water detector should be installed at a suitable location. -
Page 22: Connection Diagram
STULZ UltraWater 3-stage reverse osmosis system SUW Installation 7.2. Connection diagram Install a pressure reducer upstream of the system, which restricts the intake pressure to max. 4 bar. Note: Connection of the pressure tank is absolutely essential for reliable operation of ultrasonic... - Page 23 STULZ UltraWater 3-stage reverse osmosis system SUW Installation SUW 120 SUW 400 Gehäuse entgraten, Gehäuse entgraten, O-Ring mit Vaseline O-Ring mit Vaseline Symbol Connecting hose Type of connection (color) Black 6 mm Pipe to mains water connection Red 6 mm...
-
Page 24: Connecting The Reverse Osmosis Water (D)
Abflussventil Brauchwasser gelventil Verbindungsschlauch UV-Röhre asserspeicher Proceed as follows to connect the STULZ UltraWater: Connect the hose (blue) to the consumer. The hose is available as an accessory (1220950). Hose Make sure that the connection to the consumer is pressure-tight (minimum 4 bar). -
Page 25: Connecting The Waste Water (B)
STULZ UltraWater 3-stage reverse osmosis system SUW Installation Wasserhahn 12 Liter Wasserspeicher Gehäuseschüssel 7.2.2. Connecting the waste water (B) To connect the supplied pressure hoses, cut the ends of the hoses straight using a sharp pipe cutter. The supplied waste water connection has the following components: •... -
Page 26: Connecting To The Pressure Tank (C)
STULZ UltraWater 3-stage reverse osmosis system SUW Installation 7.2.3. Connecting to the pressure tank (C) asserhahn 12 Liter Wasserspeicher Gehäuseschüssel To connect the supplied pressure hoses, cut the ends of the hoses straight using a sharp pipe cutter. The components of the supplied connection material are as follows: •... -
Page 27: Connecting The Water Supply (A)
STULZ UltraWater 3-stage reverse osmosis system SUW Installation 7.2.4. Connecting the water supply (A) asserhahn 12 Liter Wasserspeicher Gehäuseschüssel To connect the supplied pressure hoses, cut the ends of the hoses straight using a sharp pipe cutter. The components of the supplied connection material are as follows: •... -
Page 28: Installing The Membrane
STULZ UltraWater 3-stage reverse osmosis system SUW Installation 7.3. Installing the membrane If the membrane is not yet installed at the site of installation (membrane is delivered sealed in plastic film), it must be installed. Use the supplied membrane and, if applicable, the housing key:... -
Page 29: Tightening The Filter Housing
STULZ UltraWater 3-stage reverse osmosis system SUW Installation Carefully close the module housing once more (use the key). Put the hose connection back together. Press the complete module housing back into the retaining clips. 7.4. Tightening the filter housing Use the supplied housing key (to open the housing): Proceed as follows to tighten the filter housing: Tighten the filter housing firmly by hand. -
Page 30: Electrical Connection
Installation 7.5. Electrical connection Both STULZ UltraWater models are delivered fully wired. Only connect the power supply when installation is complete. Check the power cable, plugs and transformer housing for areas of damage. Only connect equipment in perfect condition to the power supply. Faulty parts must be replaced by specialist personnel. -
Page 31: Wall-Mounted Installation
Select minimum distances from obstacles and minimum lengths of hoses and cables so as to ensure that hoses and cables cannot be kinked or squashed. Check the function and tightness of the STULZ UltraWater. For this, see the "Start-up" section. -
Page 32: Start-Up
STULZ UltraWater 3-stage reverse osmosis system SUW Start-up START-UP The drain water connection must be ensured. Do not use mains water with a temperature above 45°C. Protect the system against frost. If the system is disconnected from the mains water for more than 5 days, the system must be disconnected from the mains electricity and the water drained from the system. - Page 33 STULZ UltraWater 3-stage reverse osmosis system SUW Start-up All steps from section 8 must have been completed prior to start-up! Check that all hose connections are securely fastened. Turn on the drinking water supply. Check all connected hoses for possible leakage.
-
Page 34: Operation
• The higher the water pipe pressure, the more pure water can be produced, and also with better quality. The devices of the STULZ UltraWater series are therefore equipped with a booster pump. Excessively high pressure can damage the membrane. -
Page 35: Shutting Down The System
STULZ UltraWater 3-stage reverse osmosis system SUW Shutting down the system 6.2 Membranwechsel SHUTTING DOWN THE SYSTEM If the system is to be shut down for a longer period (more than 2 weeks), the following steps must be per- formed: Zur Umkehr- Turn off the supply (tap). -
Page 36: Maintenance
Maintenance MAINTENANCE The STULZ UltraWater reverse osmosis system is low-maintenance. However, the function (water volume, water quality) and the condition of the membrane and prefilter must be checked at regular intervals. Wear- ing parts must also be replaced regularly. The usual water throughput and quality cannot be guaranteed if the necessary maintenance is not performed. - Page 37 STULZ UltraWater 3-stage reverse osmosis system SUW Maintenance Install new filters in the prefilter housing (first remove the plastic film). The two filters are identical. Check sealing rings for damage. Check that sealing rings are clean. Lightly grease sealing rings with silicone.
-
Page 38: Replacing The Membranes
6.2 Membranwechsel STULZ UltraWater 3-stage reverse osmosis system SUW Maintenance 12.2. Replacing the membranes Zur Umkehr- Zur Umkehr- Zur Umkehr- When the quality and/or volume of the pure water is no longer adequate, the membranes must be re- Osmose-Anlage Osmose-Anlage Osmose-Anlage placed. -
Page 39: Replacing The Flow Restrictor
STULZ UltraWater 3-stage reverse osmosis system SUW Maintenance 12.3. Replacing the flow restrictor When the membrane is replaced, you should always replace the flow restrictor at the same time. Proceed as follows to replace the flow restrictor: Disconnect the system from the mains voltage. -
Page 40: Checking The Pure Water Quality And Throughput
STULZ UltraWater 3-stage reverse osmosis system SUW Maintenance 12.5. Checking the pure water quality and throughput Determine the actual permeation rate Check the pure water quality and throughput of the reverse osmosis membrane. For this purpose, the system should be in operation and the pure water must drain away freely (pressure tank disconnected from the system). -
Page 41: Troubleshooting
STULZ UltraWater 3-stage reverse osmosis system SUW Troubleshooting TROUBLESHOOTING Problem Cause Remedy System does not switch on Water is not connected Connect the system to the drinking water mains and turn on the tap. Insufficient water pressure Make sure the inlet water pressure is at least 1 bar. - Page 42 STULZ UltraWater 3-stage reverse osmosis system SUW Troubleshooting Quality of pure water is too poor Water quality monitoring system Check or replace water quality is faulty monitoring system. Prefilter extremely contaminated Replace prefilter insert. Pure water quality of untreated Install a deionizer behind the mem-...
-
Page 43: Spare Parts Lists
STULZ UltraWater 3-stage reverse osmosis system SUW Spare parts lists SPARE PARTS LISTS 14.1. Spare parts list for SUW 120 Item Item number Designation Quantity 1220910 Screw-in connector G1/4"a-6i 1220911 Holder 16-23 1220912 Flow restrictor 1:1 system: 200G 1220913 Y-connector 6... -
Page 44: Assembly Drawing Of Suw 120
STULZ UltraWater 3-stage reverse osmosis system SUW Spare parts lists 14.2. Assembly drawing of SUW 120 - 44 - © STULZ GmbH, Hamburg... -
Page 45: Spare Parts List For Suw 400
STULZ UltraWater 3-stage reverse osmosis system SUW Spare parts lists 14.3. Spare parts list for SUW 400 Item Item number Designation Quantity 1220910 Screw-in connector G1/4"a-6i 1220911 Holder 16-23 1220952 Flow restrictor 1:1 system: 600G 1220913 Y-connector 6 1220914 Holder 12-16 1220915 Screw-on connector G1/8"a-6i... -
Page 46: Assembly Drawing Of Suw 400
STULZ UltraWater 3-stage reverse osmosis system SUW Spare parts lists 14.4. Assembly drawing of SUW 400 - 46 - © STULZ GmbH, Hamburg... -
Page 47: Ce-Certification
STULZ UltraWater 3-stage reverse osmosis system SUW CE-Certification CE-CERTIFICATION - 47 - © STULZ GmbH, Hamburg... - Page 48 STULZ UltraWater 3-stage reverse osmosis system SUW Notes NOTES - 48 - © STULZ GmbH, Hamburg...
-
Page 49: Maintenance Plan
STULZ UltraWater 3-stage reverse osmosis system SUW Maintenance plan MAINTENANCE PLAN To ensure correct maintenance, we recommend the following maintenance plan. Adapt the maintenance intervals to suit the local conditions. For this, see section 6.6 Filter service life. Copy this sheet before filling it in! - Page 50 Exclusion of liability STULZ GmbH reserves the right to adapt the product specifications in line with, for example, technical developments, changes to legis- lation or future market requirements. All previous versions of this manual become void upon the publication of this one.
