Summary of Contents for Joe Due Z10
- Page 1 OperatingManualZ10/Z20/Z30 Joe Due Blades & Equipment N5437 US Hwy 12 & 16 Mauston, WI 53948 www.joedue.com info@joedue.com Operating Manual Dust ExtractorZ10/Z20/Z30 Read all instructions carefully before use 1 / 37...
- Page 2 OperatingManualZ10/Z20/Z30 Introductions Dear Valued Customer, Thank you foryour trust in Joe Due Blades & Equipment, Inc. and for choosing the single phase, 2 stage HEPA dust extractor! We hope the machine will be to your satisfaction and meet your expectations.
-
Page 3: Table Of Contents
Warranty…………………………………………………… Safety precautions………………………………………. Electric safety…………………………………………….. Thermal protection………………………………………. Grounding instructions………………………………….. Service……………………………………….…………….. Operating instructions……………………..……………. Filter change……………………………………………… Problem solving…………………………………………... Exploded view –Z10……………………………………. Exploded view- ZBD00313…………………………….. Exploded view- ZBD00312…………………………….. Exploded view- ZBD00323…………………………….. Accessories-Z10…..…………………………………….. Exploded view-Z20…………………………………..… Exploded view- ZBD00327…………………………….. Exploded view- ZBD00326 &ZBD00411……………. Accessories- Z20…………………………………………... -
Page 4: Unpacking
Do not use to pick up any substances that is burning or smoking substances, such as cigarettes and matches, or hot ashes. Joe Due Blades & Equipment, Inc..shall, under no circumstances, be deemed liable for any accidents or damage caused if the machine is used for other applications. -
Page 5: Identification Of Main Parts
OperatingManualZ10/Z20/Z30 Identification of main parts filter purgehandle die-casting inlet unit continuous fold bag assy. 4” front swivel casters, lockable 8” wheels rating label hour meter power switch vacuum meter HEPA chamber main filter chamber ergonomic handle 5 / 37... -
Page 6: Technical Data
OperatingManualZ10/Z20/Z30 Technical data data unit voltage (single phase) 1200 2400 3600 max. power current m3/h max. air flow mbar max. vacuum inch D38x5m D51x7.5m D51x7.5m main hose inch D1.5”x16.5’ D2.0”x24’ D2.0”x24’ inlet inch 2.5” 2.5” 2.5” pre-filter >99.5%@1.0 um >99.5%@1.0 um >99.5%@1.0 um (EN779-F8) pre-filter... -
Page 7: Declaration Of Conformity
Joe Due Blades & Equipment, Inc.. Warranty Joe Due Blades & Equipment, Inc.. offers to its customer the vacuums and accessories a 12-month factory warranty for material and manufacturing defects. In the event of any complaint, the machine or agreed part must be returned to us or our authorized representative for a warranty examination and for any warranty repair or replacement. -
Page 8: Safety Precautions
All repairs must be performed by a qualified service person. Use only manufacturersupplied or specified replacement parts. Joe Due Blades & Equipment, Inc..shall, under no circumstances, be deemed liable for any accidents or damage caused if the machine is used for other applications or in a way other than those required in the operating manual. -
Page 9: Thermal Protection
OperatingManualZ10/Z20/Z30 Do not use with damaged cord or plug. If the machine is not working as it should, has been dropped, damaged, left outdoors or dropped in water. Make sure it is repaired by a qualified person. Do not pull or carry by cord, use cord as handle, close a door on cord, or pull cord around ... -
Page 10: Operating Instructions
OperatingManualZ10/Z20/Z30 Operating Instructions Vacuuming process Before starting a vacuuming process, make sure the machine is properly connected to a grinder or a floor tool via the provided hose and fittings. chek the power cable and theplugsare in a good condition. ... -
Page 11: Filter Change
OperatingManualZ10/Z20/Z30 Dust collecting and bagging The machineis equipped with a continuous fold bag system for an effective dust collecting and bagging. The supplied fold bag is a 22 m long plastic tube that will be divided into individual bags using the zip ties attached with the machine. To assemble a new fold bag: Release the beltholding the last bag and take off the bag holder. -
Page 12: Problem Solving
OperatingManualZ10/Z20/Z30 Problem solving The machine is designed and manufactured for a specificsevere environments and tasks. Its filter, seals, attachments, and fittings are customized or selected specifically for the applications. Please note that the machine must be protected from knocks and blows. The operator and service personnel must treat the machine with care in order for it to work correctly for an expected life span. -
Page 13: Exploded View -Z10
OperatingManualZ10/Z20/Z30 Exploded view - Z10 13 / 37... - Page 14 Packing belt ZBH00099 Anti-skit ring ZBM00241 Fold bag ZBC00225 Fold bag holder ZBD00313 Z10 wagon frameassy ** ZBD00312 Motorcomplete assy(Z10 230v) ** ZBD00323 Motorcomplete assy(Z10 120v) ** ** refer to the followings for a breakdown of part list 14 / 37...
-
Page 15: Exploded View- Zbd00313
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00313 Z10 wagon frame assy POS. Part Number Description ZBC00381 Wagon frame base ZBD00530 Front wheel kit ZBD00385 Real wheel kit ZBH00076 Plastic insert 25x25 ZBD00382 L bracket kit ZBD00341 Mainstay right kit ZBD00344 Mainstay left kit... -
Page 16: Exploded View- Zbd00312
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00312 Motorcomplete assy (Z10 230v ) 16 / 37... - Page 17 OperatingManualZ10/Z20/Z30 POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00348 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00160 Motor 230V 1200W ZBH00023 Rubber ring ZBK00035 Bolt M6x12 ZBM00071...
-
Page 18: Exploded View- Zbd00323
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00323 Motorcomplete assy (Z10 120v) 18 / 37... - Page 19 OperatingManualZ10/Z20/Z30 POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00348 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00362 Motor110V 1200W ZBH00023 Rubber ring ZBK00035 Bolt M6x12 ZBM00071 Female spacer L76.5...
-
Page 20: Accessories-Z10
OperatingManualZ10/Z20/Z30 Accessories–Z10 POS. Part Number Description ZBD00558 Hose kit D40x5.0m ZBC00033 D40 lower wand ZBC00034 D40 upper wand ZBD00030 Floor brush D40x400 ZBM00004 Spare brush 20 / 37... -
Page 21: Exploded View-Z20
OperatingManualZ10/Z20/Z30 Exploded view–Z20 21 / 37... - Page 22 OperatingManualZ10/Z20/Z30 POS. Part Number Description ZBD00387 Purge handle cover kit ZBD00283 Purge handle kit ZBH00043 Bend connector seal ZBD00188 D50 bend connector ZBM00222 D50 hose clamp s.s. ZBH00105 D50 flexible hose L495 ZBH00058 D50 hose cuff ZBC00390 Top cover ZBM00285 Pre-filter ZBD00336 Hook 105 kit...
-
Page 23: Exploded View- Zbd00327
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00327 Z20 wagon frame assy POS. Part Number Description ZBC00382 Wagon frame base ZBD00530 Front wheel kit ZBD00385 Real wheel kit ZBH00077 Plastic insert 30x30 ZBD00382 L bracket kit ZBD00356 Mainstay right kit ZBD00354 Mainstay left kit ZBD00392 Tank holder kit ZBC00420... -
Page 24: Exploded View- Zbd00326&Zbd00411
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00326&ZBD00411 Motor complete assy (Z20 230v & 120v) 24 / 37... - Page 25 OperatingManualZ10/Z20/Z30 ZBD00326- Motorcomplete assy (Z20 230v) POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00360 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00160 Motor 230V 1200W ZBH00023 Rubber ring ZBK00035...
- Page 26 OperatingManualZ10/Z20/Z30 ZBD00411- Motorcomplete assy (Z20 120v) POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00360 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00362 Motor120V 1200W ZBH00023 Rubber ring ZBK00035...
-
Page 27: Accessories-Z20
OperatingManualZ10/Z20/Z30 Accessories–Z20 POS. Part Number Description ZBD00559 Hose assy kit D50x7.5m ZBD00050 D50 S wand ZBD00054 D50 floor brush ZBC00043 D50 crevice tool ZBM00001 Spare brush 27 / 37... -
Page 28: Exploded View-Z30
OperatingManualZ10/Z20/Z30 Exploded view–Z30 28 / 37... - Page 29 OperatingManualZ10/Z20/Z30 POS. Part Number Description ZBD00387 Purge handle cover kit ZBD00283 Purge handlekit ZBH00043 Bend connector seal ZBC00188 D50 bend connector ZBM00222 D50 hose clamp s.s. ZBH00106 D50 flexible hose L680 ZBH00107 D50 flexible hose L750 ZBH00058 D50 hose cuff ZBC00396 Top cover ZBM00286...
-
Page 30: Exploded View- Zbd00332
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00332 Wagon frame complete assy (Z30) POS. Part Number Description ZBC00383 Wagon frame base ZBD00530 Front wheel kit ZBD00385 Real wheel kit ZBH00031 Plastic insert 40x40 ZBD00382 L bracket kit ZBD00365 Mainstay kit ZBD00363 Tank holder kit ZBC00420 Back plate ZBD00367... -
Page 31: Exploded View- Zbd00412 &Zbd00414
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00412 &ZBD00414 Motor complete assy (Z30240v &120v) 31 / 37... - Page 32 OperatingManualZ10/Z20/Z30 ZBD00412- Motorcomplete assy (Z30 240v) POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00370 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00160 Motor 230V 1200W ZBH00023 Rubber ring ZBK00035...
- Page 33 OperatingManualZ10/Z20/Z30 ZBD00414- Motorcomplete assy (Z30 120v) POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filter cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00370 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00324 Motor 120V 800W ZBH00023 Rubber ring ZBK00035...
-
Page 34: Exploded View- Zbd00413
OperatingManualZ10/Z20/Z30 Exploded view- ZBD00413 Motor complete assy (Z30230v/63A) 34 / 37... - Page 35 OperatingManualZ10/Z20/Z30 ZBD00413- Motorcomplete assy (Z30 230v/63A) POS. Part Number Description ZBK00111 Nut M8 ZBH00082 Seal washer M8 ZBC00387 Filterer cover ZBM00287 HEPA filter ZBH00110 Top cover rubber seal ZBD00360 Top cover kit ZBC00388 HEPA chamber ZBM00344 Motor seal ZBM00160 Motor 230V 1200W ZBH00023 Rubber ring ZBK00035...
-
Page 36: Accessories-Z30
OperatingManualZ10/Z20/Z30 Accessories–Z30 POS. Part Number Description ZBD00559 Hose assy kit D50x7.5m ZBD00050 D50 S wand ZBD00054 D50 floor brush ZBC00043 D50 crevice tool ZBM00001 Spare brush 36 / 37... -
Page 37: Accessories-Z30 230V/63A
OperatingManualZ10/Z20/Z30 Accessories–Z30 230v/63A POS. Part Number Description ZBD00559 Hose assy kit D50x7.5m ZBD00050 D50 S wand ZBD00054 D50 floor brush ZBC00043 D50 crevice tool ZBM00001 Spare brush ZBM00413 Industrial connector 63A ZBM00411 Industrial plug 32A 37 / 37...
