Summary of Contents for JCM Technologies GSM-CARD
- Page 1 GSM-CARD/VGSM-CARD communications card...
-
Page 2: Table Of Contents
GSM-CARD / VGSM-CARD Contents Safety instructions Solving problems Introduction FAQs Technical data General description Introduction Electrical parameters Assembly Physical parameters Configuration Radiofrequency parameters Using the system Verification EC declaration of conformity LED indicators 2 - jcmtechnologies... -
Page 3: Safety Instructions
GSM-CARD / VGSM-CARD Safety instructions In compliance with the European Directive low-voltage electrical equipment, we hereby inform users of the following requirements: • Disconnect the device from the power supply before handling. • For units which are permanently connected, an easily accessible circuit-breaker device must be built into the wiring system. -
Page 4: Introduction
GSM-CARD / VGSM-CARD Introduction General description GSM communication card for real-time management LED GS, TRANSMISSION STAT INDICATORS GOOD COVERAGE POOR COVERAGE SMA CONNECTOR FOR GSM INDICATORS ALARM ERROR ANTENNA LED STATUS INDICATORS CONNECTOR TO MAIN BOARD Connected to an ACCESS-5K access control, it allows remote management of users. -
Page 5: Introduction
GSM-CARD / VGSM-CARD Introduction General description Back view MICRO-SD MEMORY CARD SLOT (only Versus) SIM CARD SLOT jcmtechnologies - 5... -
Page 6: Assembly
GSM-CARD / VGSM-CARD Installation Assembly GSM ANTENNA Screw the GSM ANTENNA STAT GOOD POOR COVERAGE supplied into the SMA ALARM ERROR connector CONNECTION TO MAIN PCB With the power supply disconnected, insert the card into the device COMMS. CARD ACCESS-5K... -
Page 7: Configuration
GSM-CARD / VGSM-CARD Configuration GSM-CARD VGSM-CARD To configure the device, please To change the default options, access the following website: you must install the SoftAssistant program for Windows For more information, visit: http://versuscloud.jcm-tech.com/ https://www.jcm-tech.com/JCM/motion-programmers/ jcmtechnologies - 7... -
Page 8: Verification
GSM-CARD / VGSM-CARD Verification LED indicators LEDs GSM GOOD Good coverage. GOOD Optimum data transfer POOR COVERAGE POOR Weak coverage, but sufficient for data transfer Unstable coverage or no connection. ALARM We recommend you not use the device in this status, as there may be errors... - Page 9 ALARM ALARM Use of backup GSM frequency (850 MHz) ERROR ERROR System error If the GSM-CARD uses the backup frequency, it can interfere with the Motion transmitters ERROR LED Number of flashes Error type Action required Module initialisation Wait for the initialization to be completed...
-
Page 10: Solving Problems
A: No, you cannot. In addition to the serial number, it is also required the unique key to connect remotely. Q: If I have the main equipment installed, will it work remotely only by plugging in a GSM-CARD? A: Yes, the card is configured by default with the communication parameters of the approved operator. ... -
Page 11: Technical Data
GSM-CARD / VGSM-CARD Technical details Electrical parameters Power supply 12V dc Standby / Op. consumption <500 mA Maximum power absorbed Operating temperature -20ºC … +55ºC Size (without antenna) 77 x 52 x 10 mm Physical parameters Operating temperature -20ºC … +55ºC... -
Page 12: Using The System
The manufacturer reserves the right to modify equipment specifications without prior notice. EC declaration of conformity JCM TECHNOLOGIES, S.A. declares that the GSM-CARD/VGSM-CARD complies with the applicable provisions of the section 3 of the R&TTE 2014/35/ CEE Directive and complies the fundamental requirements of the 2014/30/ EU Directive on electromagnetic compatibility and 2006/95/EC on low volta- ge, insofar as the product is used correctly.
