- Page 1 Ventra VDR-220 2 CH HD Vehicle DVR System User Manual Ideal For - Vehicles - Motorcycles / Scooter - Golf Carts - Fork Lifts / Construction 06 19. V1.3...
- Page 2 Always make sure the product is used as intended. • Only using the power supply as recommended or supplied by Ventra • All cables MUST be properly fastened and secured to a vehicle or motorcycle to prevent from loosening •...
- Page 3 Numerous states have enacted restrictions against placing objects on the windshield in locations that obstruct the driver’s vision. 2. IT IS THE USER’S RESPONSBILITY TO MOUNT VENTRA EQUIPMENT IN COMPLIANCE WITH ALL PPLICABLE LAWS AND ORDINCANCE. Audio and Video Recording Notice 3.
- Page 4 2. If the card is unlocked but still cannot be formatted, please run the program as Administrator to prevent from this problem. Format steps： Insert the CD in your PC and open the file Install the VDR-760 / VDR-220 PC Software iii. program and click on “Format Micro SD Card”.
- Page 5 Vehicle video recorder user manual Regardless of SD card capacity (i.e. 16GB, 32GB, 64GB or 128GB Once its formatted via the Ventra PC player or VDR760, the SD card capacity will show between 77.5MB to 80.5MB This is due to the system design of the...
-
Page 6: Table Of Contents
Format memory card continued ..............24 Restore memory card ..................25 Restore memory card continued ..............26 Warranty Information ..................27 Note: VDR-760 and VDR-220 utilizes proprietary file format. The SD card MUST be Formatted via the VDR 760 desktop software prior to use https://ventrainc.com/ventra-products-all-in-one-vdr-760/... -
Page 7: Feature
Plug and Play 10. 110 degree wide angle recording/viewing for both cameras 11. Driving Route and Speed history in Ventra software playback with Google Map Integration 12. G-sensor sensitivity adjustable according to vehicle type and road condition 13. -
Page 8: Specifications / Recording Frame Rate
Recording Resolution and Frame Per Second (FPS) Camera 1 Camera 2 Resolution / FPS recording in SD card 720P @ 30 FPS 720P @ 30 FPS Upload to Ventra Cloud Server - Event Only Videos 720P @ 30 FPS 720P @ 30 FPS (Optional Fee-Based Service) -
Page 9: Included Components / Models / Recording Time
VDR-220 VDR-220BT VDR-220ZT Models 32GB SD Card 64GB SD Card 128GB SD Card SD Card Included All VDR-220 models are the same except for the SD card included Recording Time VDR-220 VDR-220BT VDR-220ZT Models 32GB SD Card 64GB SD Card... -
Page 10: Product Diagram
Vehicle video recorder user manual Product Diagram Dustproof Cover & Screw SD Card WiFi Slot Adapter Microphone EX22-GPSMIC (Optional Power Status WiFi Status GPS Status REC Status... -
Page 11: Product Dimension
Vehicle video recorder user manual Product Dimension Unit：inch 1.88”... -
Page 12: Installation Power
Vehicle video recorder user manual Installation - Power G. VDR requires 2 wires for power: (12V DC) and Black (Ground) for installation. Use the power cable included with the system. Do not modified the power cable or video cable. Connect power cable to vehicle fuse: Red Wire = 12V DC Constant or IGNITION Black = Ground... -
Page 13: Installation Diagram
Vehicle video recorder user manual Installation Diagram Installing DVR Use「Double-sided adhesive」to mount DVR to a suitable location within the vehicle or the compartment in a motorcycle. DVR may be mounted vertically or horizontally to a flat surface Clean the surface before mounting the DVR NOTE: The DVR is not weather resistant and must be mounted inside a vehicle with air ventilation. -
Page 14: Installation Camera
Vehicle video recorder user manual Identify the mounting location of the camera BEFORE running the cable. Once location is determined, TEST the camera recording angle first PRIOR to installing the cables inside panels and lining. This will allow easy adjustment of camera angle as needed. The Cameras are outdoor rated and can be mounted inside or outside the vehicle, motorcycle, forklifts or special machinery. -
Page 15: Installation Ex22-Gpsmic
Vehicle video recorder user manual Installation Continued: EX22-GPSMIC The optional EX22-GPSMIC is a multi-function device that can added to the system. It should be mounted in a location with line of sight to the sky for signal acquisition (i.e. dashboard, windshield) System Status LED Rec: (Red) indicates system recording Power: (Red) indicates power on... -
Page 16: Installation Overview - Motorcycle
Vehicle video recorder user manual Installation Example On Motorcycle / Scooter... -
Page 17: Notice
(g) Memory card has life span. To ensure working correctly, please test and format the memory card on VDR-760 / VDR-220 software regularly (h) After SD card format by VDR software, 8 GB, 16 GB, 32 GB, 64 GB or 128 GB SD card will show 77.5... -
Page 18: System Recording - Normal / Event
Vehicle video recorder user manual System Recording – Normal and Event The VDR-220 system is designed to be Easy to Install, Operate and Manage When the vehicle powers on, VDR will automatically power on and start recording on both cameras Ventra systems are CONTINUOUS based recording so it will always record when the vehicle and VDR is powered on. -
Page 19: Playback Video Recording Continued
Drive, E Drive..etc) Note: Direct X 9.0 above is required for this program VDR-220 / VDR-760 utilizes the same software and can be downloaded on the webite. Ensure the correct software is used as various Ventra model utilizes different software... -
Page 20: Playback Video Recording Continued
Vehicle video recorder user manual Video Playback continued 2. Software Interface Main Screen Software Interface Description: Pause Play Stop Reverse play previous frame Play next frame Play previous file Play next file... -
Page 21: Playback Video Recording Continued
Vehicle video recorder user manual Google Map API Key .TS File (uploaded event video to server, may not be applicable to all customers) .SD File (Native recorded file on SD card) Close the PC Player Minimize the PC Player Playback Calendar Backup / Save Video Snapshot... -
Page 22: Back Up Video
Vehicle video recorder user manual Video Playback Video Speed Status BAR (1) Play BAR: Move the play BAR by mouse The flag above BAR can be move to backup video files (2)Video speed: Support 2x, 4x, 8x fast forwarding and -2x, -4x, - 8x slow play mode. -
Page 23: Back Up Video Continued
Step 1: select the SD card location Step 2: select the files to backup Step 3. Choose the backup file format (1) Raw Backup - Ventra File Format (*.sd) (2)AVI File Backup (*.avi) Backup format： (1) Raw Backup -Ventra File Format Micro SD Card File type (*.sd) -
Page 24: Settings / System Configuration
Vehicle video recorder user manual Configuration Insert memory card into adapter card before recording, and then plug in adapter card to PC USB slot. Click and run software to setting recording method, after setting complete, insert the memory card back to device and continue recording. The vehicle or driver ID can set and recorded. -
Page 25: Settings / System Configuration Continued
Vehicle video recorder user manual Enable or Disable Daylight Daylight Saving Time. If enabled, Saving Time system will automatically adjust based on calendar Assign Password to SD card to prevent unauthorized access. Set password to 15 characters max, for example： 123456789123456 After setting the password, Password... -
Page 26: Settings / System Configuration Continued
Vehicle video recorder user manual Save PC Save a copy of PC player to Player To SD the SD card Card Km/h: kilometer per hour Mile/h: Mile per hour Unit of Speed ★ Note: 1 KM=0.6214 mile, 1 mile=1.6093KM G Sensor: On /Off Off: Disable G Sensor Of: Enable G sensor If disabled, VDR will not... -
Page 27: Snapshot Setting
Vehicle video recorder user manual Snapshot Tool While playing the video file, user can use this function snapshot the picture and save it into PC. Default saving path for snapshot picture will be in /Snapshot folder. File format as *.bmp... -
Page 28: Format Memory Card
Vehicle video recorder user manual Format memory card When Should You Format Micro SD CARD? When you use the Micro SD card for the first time or use a new card, the SD card MUST be formatted prior to use. VDR system cannot delete a particular video as a security measure. -
Page 29: Format Memory Card Continued
Vehicle video recorder user manual... -
Page 30: Format Memory Card Continued
Vehicle video recorder user manual... -
Page 31: Restore Memory Card
Vehicle video recorder user manual When formatting is completed, please insert the card into the VDR Open the DVR cover by loosening the screw Restore memory card When you have backed up the recorded files into PC and want to use the Micro SD card for other purposes, the SD card has to be restored to original format to be used correctly. -
Page 32: Restore Memory Card Continued
Vehicle video recorder user manual How to restore memory card to default Steps as below： Insert the SD card into the card Connect the card reader with reader (Please make sure the the PC direction is correct) 3、Insert the CD in your PC and open file 4、Find and run program and click on “Format Micro SD... -
Page 33: Warranty Information
Vehicle video recorder user manual Windows 10 IMPORTANT Restoring the SD card will permanently DELETE all data from the SD card. Restoring the SD card to the original format so it can be utilized for non Ventra system recording. - Page 34 Vehicle video recorder user manual VENTRA LIMITED WARRANTY Ventra Technology warrants the system against defects in material and workmanship for a period of one (1) year from the date of original purchase. During this period, Ventra’s liability for any defective product, or any product part, shall be limited to the repair or replacement of the product, at Ventra’s sole discretion.
