SCHEMATIC DIAGRAMS
COMPACT COMPONENT SYSTEM
STANDBY/ON
SLEEP
AUX
FM MODE
FM/AM
VIDEO INTRO
ON SCREEN
HIGHLIGHT
PREV.
NEXT
SET
RETURN
ENTER
PBC
STILL
KEY CONTROL
1
2
3
DISC
DISC
DISC
DISC
REPEAT PROGRAM RANDOM
CANCEL
PROGRAM
REC
TURBO
SOUND
TAPE-A
TAPE-B
START/STOP
SOUND
MODE
KARAOKE
MPX
ACTIVE
FADE
BASS EX.
ECHO
MUTING
VOLUME
REMOTE CONTROL
COMPACT
DIGITAL VIDEO

Contents

Block Diagram ------------------------------------------------------ 2-1
Standard Schematic Diagrams ---------------------------------- 2-2
Printed Circuit Boards --------------------------------------------- 2-8
MX-SK1
CD-ROM No.SML200404
COMPACT
DIGITAL VIDEO
ACTIVE
BASS EX.
PHONES
S P -M X S K 1
C A -M X S K 1
COMPACT
DIGITAL AUDIO
COPYRIGHT
2004 VICTOR COMPANY OF JAPAN, LTD.
M X - S K 3
DISC
SELECT
SELECT
EJECT
EJECT
S P -M X S K 1
Area suffix
EE --------- Russian Federation
No.MB207CH
2004/4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-SK1 and is the answer not in the manual?

Questions and answers

Nithyesh
January 24, 2025

Stand by problem?????

User image 67933b4d90e79
-1
1 comments:
Mr. Anderson
February 10, 2025

When the JVC MX-SK1 is in standby mode, the STANDBY/ON lamp lights red. However, the fffff/I button in any position does not disconnect the mains line, meaning the unit remains connected to power even when in standby.
