AEI Security & Communications CTVM300AFR Quick Start Manual

Wirefree Monitoring System
CTVM300AFR
AEI Security & Communications Ltd
Pack Contents
1 x Wirefree Camera
1 x Camera PSU
1 x Monitor
1 x Monitor PSU
Fixings & Manual
In the interests of product development,
cosmetic appearance & colour may differ.
1 2
1) Power switch (ON/OFF)
2) Volume control
3) Channel selector (1,2,3,4)
4) Audio level meter
SEE OVERLEAF FOR QUICK SET UP GUIDE
4
3
160507-6
IMPORTANT NOTICES
This system is
EXTERNAL USE. Exposure to moisture
may damage this device, render it unsafe for
use and invalidate the 1 year warranty.
ALWAYS SWITCH OFF this device prior
to connecting to mains power and when not
in use.
1 2 3 4
1) 13.5VDC Power
2) Mode selector (WIRE/WIRELESS)
3) Audio/Video input (WIRE mode only)
4) Audio/Video output
5) V-Hold picture control
6) Contrast picture control
7) Brightness picture control
NOT SUITABLE FOR
5,6,7
