- Page 1 Fiber Optics TII FDH1 Indoor Fiber Distribution Cabinet Fiber Optics. A Division of Tii Network Technologies Inc. 5103 Pegasus Ct., Suite H Frederick, MD 21704 Contact – 888-844-4720 301-874-4688 fibersales@tiinetworktechnolgies.com Tii Network Technologies Inc. 2012...
-
Page 2: Trademark Information
DISCLAIMER OF LIABILITY Contents herein are as of the date of publication. Tii Network Technologies Inc. (Tii) reserves the right to change the contents without prior notice. In no event shall Tii be liable resulting from the loss of data, loss of use or loss of profits and Tii further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. - Page 3 1. General 1.1. The Tii FDH1 Series is a wall mount fiber distribution hub designed to support patching, splicing and optical splitting in one unit. The enclosure has 9 adapter panel positions allowing for a wide variety of patching and splitting combinations. Two compartments separate the network terminations from the distribution terminations and a single outer door.
-
Page 4: Warranty
4.1. Modular LGX bulkhead adapters - for interconnection between feeder and distribution fibers. 4.2. Slack Storage - The FDH1 is designed to allow for storage of pre-terminated 12F SST drop cable inside the unit with tie-downs to secure the cable. - Page 5 FIGURE 1a. Basic Layout 5. FDH1 Cabinet 5.1. The Tii FDH1 Series Cabinet can be configured in three (3) versions including an all patch version, a patch and splice version and a PON Version. 5.2. Figures 1 and 1a shows the general features of the FDH1.
- Page 6 4 – 12 LGX adapter plates for distribution fibers Fiber Routing Guides 4 Blank LGX plates for 1x32 splitter parking lot FIGURE 2. Patch and Splice. Splice Trays Multiple Entry Ports FIGURE 3. Splice tray layout Tii Network Technologies Inc. 2012...
- Page 7 Splitter Module Retainer 1 x 12 Feeder fiber module FIGURE 4. PON Version 4 – 1x 8 LGX Distribution Modules 4 – 1 x 8 LGX Splitter Parking Lot FIGURE 5. PON Version- Layout with labeling. Tii Network Technologies Inc. 2012...
- Page 8 8.2. Figure 6 shows the standard door label for the recording of Feeder and distribution fiber (Subscriber Termination Field). 8.3. The surface allows for field recording of the designated fiber and subscriber terminations. FDH Label FIGURE 6. Tii Network Technologies Inc. 2012...
-
Page 9: Recommended Tools
9.3.1. Install 4’x4’x¾” plywood backboard to most secure points practical using appropriate hardware 9.3.2. Concrete block 9.3.3. Brick 9.3.4. Structural studs Secure FDH to backboard using provided 4 point attaching brackets using ½” wood screws 9.3.5. typically centered or as appropriate to install site Tii Network Technologies Inc. 2012... -
Page 10: Install Cables
9.5.1. Set a portable table as close to final installation site as feasible and stage items. 9.5.2. Hand tools. 9.5.3. Splicer & Cleaver (if required). 9.5.4. Cleaning supplies. 9.5.5. If configured remove pigtail from slack storage up to breakout, ensure pigtails reach workspace or remove adapter plates if necessary. Tii Network Technologies Inc. 2012... - Page 11 9.7.1. Install each MDU home run drop cable to rear patch panel, label as required. 9.7.2. Install pre-terminated trunks or field install feeder cables front of patch panel, inactive fibers stored in parking lot. 9.7.3. Dress, route and secure feeder & MDU drops to provided cable management clips Tii Network Technologies Inc. 2012...
- Page 12 9.8.7. Route pigtails to front side of panel, stage fibers in parking lot and secure slack using fiber management clips. Activate MDU connections by moving from parking lot to MDU dwelling ports as required 9.8.8. Tii Network Technologies Inc. 2012...
- Page 13 9.9.6. Install splitter input (blue strand) to top adapter plate feeder cable. 9.9.7. Install splitter outputs (yellow strands) to parking lot. 9.9.8. Activate MDU connections by moving from parking lot to dwelling ports as required. Tii Network Technologies Inc. 2012...
- Page 14 Typical insertion loss of factory terminated pigtails and fusion splice should be expected to be 0.25 – 0.5 Db. 9.11.3. Typical reflectance -55 dB UPC. 9.11.4. Typical reflectance -65 dB APC. 9.12. Close unit and secure. Tii Network Technologies Inc. 2012...
