Summary of Contents for Ovislink OV904GP
-
Page 2: Table Of Contents
Overview ......................... 2 Features and Functions................2 Front Panel and Rear Panel ............... 3 2.2.1 Front Panel ..................3 2.2.2 Rear Panel..................4 Installing the OV904GP ................. 5 Product Networking Application..............5 3.1.1 FTTH....................5 3.1.2 FTTB....................5 Installation Preparations ................6 Connecting the OV904GP .............. -
Page 3: Safety Guidance
Safety Guidance Safety Check Before installing the OV904GP device, you must check the following items. 1.1.1 Electric Safety Ensure that there are no inflammable, conductive or moist objects around. Check whether the cables are aged and whether other electrical appliances are placed stably. -
Page 4: Overview
This chapter mainly describes functions and the structure of the OV904GP. 2.1 Features and Functions The OV904GP is an GPON-based optical network unit (ONU). It contains the community antenna television (CATV) module and built-in voice over Internet protocol (VoIP) module. It provides network phone, high speed Internet access, online video on demand (VOD), video conference, large file transmission service, cable television service, and VoIP. -
Page 5: Front Panel And Rear Panel
Long transmission distance, up to 20 km. Provide CATV service. Front Panel and Rear Panel The description of the front panel and the rear panel of the OV904GP series GPON ONU is as follows. 2.2.1 Front Panel Figure 1 Front panel... -
Page 6: Rear Panel
Reset configurations. Power Connect to the interface of the power adapter. Turn on/off the power supply of the OV904GP (at the Power switch right side of Power interface). Optical Interface The optical interface is at the bottom shell, for connecting to the fiber. -
Page 7: Installing The Ov904Gp
The optical line terminal (OLT) is placed in the central equipment room. The OV904GP can be placed in the home of a user, or it can provide connection for the user through the Ethernet interface, according to the user requirement. The OLT connects to the OV904GP with an optical distributor in the point-to-multipoint way. -
Page 8: Installation Preparations
The OLT is placed in the central equipment room and the OV904GP can be mounted to the switch in the corridor. Then, you can perform networking configuration in the building according to the actual requirements. The OLT connects to the OV904GP with an optical distributor in the point-to-multipoint way. -
Page 9: Connecting The Ov904Gp
Avoid fiber extrusion, which may lead to increase of fiber material or unavailable fiber. Before connecting the OV904GP to the fiber, you must set up the fiber. To set up the fiber, do as follows: Remove the screws from the cover board. -
Page 10: Verifying The Installation
Otherwise, check whether the power cord and the power adapter are correctly connected. 3.3.4 Verifying the Installation When the OV904GP is powered on, check whether the LOS and PON indicators are on. If PON indicator is on, the connection is normal. Otherwise, check whether the fiber access is correct. -
Page 11: Troubleshooting
Check whether the optical fiber cable is properly The LOS indicator is inserted. not on Check whether the optical fiber connector is clean. Check whether the OV904GP is authorized by the carrier. Check whether the network cables included in the device package are used. The LAN1/2/3/4... -
Page 12: Technical Specifications
Technical Specifications Main Technical Specifications Standard GPON standard ITU-T G.984 Data Uplink 1.25Gbps transmission Downlink 2.5Gbps rate One optical interface Single mode Four fast Ethernet RJ-45, 10/100 Mbps, MDI/MDIX self interfaces adaptation Interface Two POTS RJ-11 interfaces One CATV interface Standard CATV interface Physical Characteristics and Environment Requirements Power adapter input... - Page 13 Appendix A Acronyms and Abbreviations CATV Community Antenna Television GPON Gigabit Passive Optical Network FTTB Fiber to the Building FTTH Fiber to the Home Optical Line Terminal Optical Network Unit Passive Optical Network Quality of Service VLAN Virtual Local Area Network VoIP Voice over IP...
