Summary of Contents for BAB TECHNOLOGIE INTERCOMMODULE
- Page 1 BAB TECHNOLOGIE GmbH INTERCOMMODULE Documentation Version: 1.0.2 Type: IP Item No.: 10582 Manual version I Issue 08/2019 Date: 28. Aug. 2019...
- Page 2 Documentation Introduction INTERCOMMODULE BAB TECHNOLOGIE GmbH Hörder Burgstraße 18 D-44263 Dortmund info@bab-tec.de Tel.: +49 (0) 231 – 476 425 - 30 Fax.: +49 (0) 231 – 476 425 - 59 www.bab-tec.de BAB TECHNOLOGIE GmbH INTERCOMMODULE...
-
Page 3: Table Of Contents
System requirements ......................... 10 Establishing connections ......................11 3.3.1 Adjusting the network settings of your computer ............... 11 Adjusting the Network settings of the INTERCOMMODULE ............. 14 Configuration INTERCOMMODULE ....................17 Saving the configuration ......................17 General ............................17 Network............................18 User administration ........................ - Page 4 Figure 5: Properties of the LAN connection......................12 Figure 6: TCP / IPv4 properties ..........................13 Figure 7: INTERCOMMODULE web interface log in ....................14 Figure 8: Log in dialog..............................14 Figure 9: Web interface – open configuration ......................15 Figure 10: Network settings ............................
-
Page 5: Introduction
INTERCOMMODULE INTRODUCTION We would like congratulate you for purchase of the new INTERCOMMODULE and we would like thank you for your trust. That you’re able to cope right with the new device from the beginning, we recommend that you carefully read the operating manual. -
Page 6: Function Overview
INTERCOMMODULE FUNCTION OVERVIEW With the INTERCOMMODULE it will be able to display on a SMARTSURFACE via Software CONTROL T 2 an IP-capable video door-station system. In connection with the EIBPORT or CUBEVISIONMODULE there is possibility, through the integrated visualizations on e.g. touch screen, receiving the sound and video image of a video door-station and also controlling these (in preparation). -
Page 7: Technical Data
Communication: Network interface Browser: current standard browser SCOPE OF DELIVERY AND INTERFACES The INTERCOMMODULE will be delivered in carton with the following contents: 1x INTERCOMMODULE 1x screw-type terminal 2-way power supplier A power supply unit for the device is NOT included in the scope of delivery! -
Page 8: Mounting Intercommodule Ip
INTERCOMMODULE MOUNTING INTERCOMMODULE IP The device on picture is the INTERCOMMODULE IP, DIN-rail housing 4 units. Dimensions (width x height x depth): 70 x 90 x 63 mm So that the power supply can be connected easily, the screw-type terminals (see figure below) ... -
Page 9: Led Status
INTERCOMMODULE LED STATUS The INTERCOMMODULE has two DUO LEDs ("Power / Boot" and "Status"). Each DUO LED has one green and one red LED. The upper LED is for power / boot, the lower LED is the status LED. POWER / BOOT LED... -
Page 10: Initial Operation
The language used for the INTERCOMMODULE Web interface is based on the language set in the browser. German and English are currently available in the INTERCOMMODULE. If the browser is set to a language other than German or English, English is displayed in the INTERCOMMODULE interface. -
Page 11: Establishing Connections
INTERCOMMODULE ESTABLISHING CONNECTIONS In order to configure the INTERCOMMODULE, a current browser and a network connection to the device are required. If the device is in the condition of delivery, it can be accessed at the above- mentioned IP address and the network settings must be adjusted to the address range, where necessary. -
Page 12: Figure 4: „Ethernet"Status
Now note down the current IP address settings or take a screenshot in order to ensure that you can reset the IP address setting following the configuration of the INTERCOMMODULE. Now change the IP address settings (IP address and subnet mask) as required:... -
Page 13: Figure 6: Tcp / Ipv4 Properties
PC by following the steps described above as soon as you have configured the INTERCOMMODULE correspondingly. If the IP address of your PC and your INTERCOMMODULE are in the same network mask, you can continue with the configuration. -
Page 14: Adjusting The Network Settings Of The Intercommodule
settings: 192.168.1.221). Figure 7: INTERCOMMODULE web interface log in The start page of the INTERCOMMODULE opens. Click on "Log in" on the left edge of the screen (see figure above, orange circle) A login dialog appears. For factory settings, the login data is as follows: ... -
Page 15: Figure 9: Web Interface - Open Configuration
Information Log Out To change the IP address of the INTERCOMMODULE please click on "CONFIGURATION" Figure 9: Web interface – open configuration The configuration menu opens. In the menu item "Network" the following settings can be done: IP-address/ subnet Field for the static assignment of IP addresses. -
Page 16: Figure 10: Network Settings
Note: Please bear in mind that you might have to reset the IP address of your computer to the initial value in order to be able to access the INTERCOMMODULE after the change has been made. BAB TECHNOLOGIE GmbH... -
Page 17: Configuration Intercommodule
Click on “Configuration” to make changes to the general settings. Figure 11: General configurations Device name: Here, you can assign an individual device name for your INTERCOMMODULE. This name is then displayed in the “Discovery Tool” and BAB STARTER. System time: The current system time of the device is shown. -
Page 18: Network
INTERCOMMODULE NETWORK The INTERCOMMODULE has no DHCP. The INTERCOMMODULE and the outdoor stations / gateways must have a fixed IP address. If the outdoor stations / gateways don’t have a setting for a static (fixed) IP address, they must receive a permanently assigned IP address by the DHCP service inside from router or server. -
Page 19: User Administration
INTERCOMMODULE USER ADMINISTRATION The user data required to access the INTERCOMMODULE Web interface is managed here. To change or add users, click “User administration” in the “Configuration” menu item. Note: Make sure that you always assign secure passwords and follow standard password guidelines. -
Page 20: Figure 14: Remote Servicing
Documentation Configuration INTERCOMMODULE INTERCOMMODULE Figure 14: Remote servicing Before you activate Remote Servicing Access, contact Support! BAB TECHNOLOGIE GmbH INTERCOMMODULE... -
Page 21: Backup The Settings
Configuration INTERCOMMODULE INTERCOMMODULE BACKUP THE SETTINGS The configuration data of the INTERCOMMODULE should be backed up at regular intervals in order to ensure that the current configuration status can be restored at any time. Figure 15: Backup / restore CREATING BACKUP Select the checkboxes under “Modules”... -
Page 22: System / Firmware Update
SERVICE Here the device can be restarted. FIRMWARE UPDATE Each INTERCOMMODULE can be updated. The firmware update is free of charge. The current firmware files can be found on the BAB homepage. Proceed as follows to update the device: ... -
Page 23: Figure 16: Configuration - System
Dokumentation Configuration INTERCOMMODULE INTERCOMMODULE Open “Configuration” – “System”. Figure 16: Configuration – system Select the firmware image file (*.bin extension) using the “Select update file” dialogue. Update type and version are displayed. Please choose one of the update options ... - Page 24 Documentation Configuration INTERCOMMODULE INTERCOMMODULE Wait until the update is complete. The Web interface is updated automatically once the process has been successfully completed. The update restores the device factory settings (except for the network settings; see above). Individual settings are only loaded again when you restore a backup (see „...
-
Page 25: Configurations Intercom Stations
INTERCOMMODULE. If you have any questions about the settings or the software of the door intercom systems, please contact yourself the manufacturer of the door intercom system. For further procedure the basic knowledge about SIP communication of door intercom systems is required. -
Page 26: Outdoor Station
This data requires the INTERCOMMODULE to log in to the gateway. The IP gateway must have a static IP address, since the INTERCOMMODULE will not notice a possible change of IP address by DHCP. -
Page 27: Indoor Stations
Here you can configure one or more indoor stations (Windows client with CONTROL T 2). Click on "Add" to connect an indoor station via its individual SIP ID to the INTERCOMMODULE and CONTROL T The configuration data of the indoor station such as "name of the indoor station" (without space), password of the indoor station "as well as the 1-9-digit individual"... -
Page 28: Call Buttons
CONFIGURATION FOR EIBPORT In order to adopt the settings for the indoor station at EIBPORT, now can be generated a TOKEN. This TOKEN must be copied to insert it into the configuration of the visualization at EIBPORT. BAB TECHNOLOGIE GmbH INTERCOMMODULE... -
Page 29: Configuration Examples
SIP user, see in Fig. 16. 11. Enter the number in the "SIP address" field as it was previously entered in the "name" field followed by a @ and the IP address of the INTERCOMMODULE, then save the settings. Example: 101@192.168.1.221... -
Page 30: Figure 25: Sip Numbers Configure
Date range Activate the respective number of button for "SIP Call" under "Actions" in the validity type "Date Range". Unique. Activate the respective number of button for "SIP Call" under "Actions" in the validity type "Unique". BAB TECHNOLOGIE GmbH INTERCOMMODULE... - Page 31 24/7. If you set other activation times in the weekly schedule or select a different validity type, please note that DoorBird does not establish a connection via SIP to the INTERCOMMODULE during the deactivation period and by that the call isn’t forwarded to the indoor station.
-
Page 32: Configuration Example On A 2N Helios Ip Verso Outdoor Station
Telephone ID: Assign any 1-9-digit number here. Domain: • Enter the IP address of the INTERCOMMODULE here. Authentication is optional. For the INTERCOMMODULE the authentication isn’t necessary. SIP proxy Proxy address: Enter the IP address of the INTERCOMMODULE here. -
Page 33: Figure 27: Phone Numbers Of The User
Time profile: A time profile isn’t necessary for using the INTERCOMMODULE. Please note that a time profile has an influence on the behaviour of the 2N. If, for example, you limit the time of the SIP phone calls, that no SIP call is forwarded to the INTERCOMMODULE during this time. -
Page 34: Figure 28: Configuration Http Api
Documentation Configuration examples INTERCOMMODULE Figure 28: Configuration HTTP API BAB TECHNOLOGIE GmbH INTERCOMMODULE... -
Page 35: Configuration Example On An Abb Welcome With Ip-Gateway 3 Button Outdoorstation
The following settings must be done in the IP gateway. Network configuration: For a faultless connection to the INTERCOMMODULE the IP gateway must get a static IP address. If you work with DHCP, it may happen that the IP gateway gets a different IP address than what you entered during the configuration. -
Page 36: Figure 32: Intercommodule Configuration Welcome
Configuration examples INTERCOMMODULE Now configure your Welcome outdoor station. For the INTERCOMMODULE there are three potentiometers on the back side of the outdoor station, there are important. Here you set the SIP ID of the call buttons. The left potentiometer indicates the address of the outdoor station. - Page 37 Dokumentation Configuration examples INTERCOMMODULE Parameter ICM.ods INTERCOMMODULE BAB TECHNOLOGIE GmbH...
