All Occasions PARTY CANOPY Setup Instructions

The all purpose canopy is a light weight unit designed for shade purposes only.
Evacuation is recommended any time weather becomes inclement.
If YOU hAvE PROblEMS OR qUESTIONS REgARdINg INSTAllATION,
PlEASE CAll OUR AfTER hOURS EMERgENCY NUMbER 513-563-0600.

PARTY CANOPY SET-UP INSTRUCTIONS

SET UP:

1. Spread the canopy flat, then pull the corners square.
2. Pull straps out perpendicular to the edge of the canopy. See diagram.
2
2
1
1
MATCH NUMBERS to build center pole.
3. Place stakes in the ground at each strap location, approximately 4´ from tent's edge. Loop the strap
over each stake.
4. Put side poles together, one flat-bottom pole and one pointed pole.
5. Place the four corner poles into position with the bottom slightly inward, toward the center. Tighten
straps until snug.
6. Put up the other side poles and tighten straps. SEE DIAGRAM ON BACK.
7. Erect center pole by matching #1 on the flat bottom pole to the #1 on longest pole then #2
on the longest pole to #2 on the pointed top pole (see diagram).
8. Position the center pole(s).
9. Go back around canopy and tighten all straps.
10. CAUTION: DO NOT decorate the tent with crepe paper or any material that will stain the canopy top.
11. Grilling and cooking should NOT be done under the canopy.
Mailing Address:
Main Location
10629 Reading Road
Evendale, OH 45241

CONTENTS 20X20:

8 two piece side poles (16 total)
1 three piece center poles (3 total)
14 18˝ steel stakes
14 tensioning straps (attached to canopy)
1 pole bag
1 stake bag
1 canopy bag
x
X
X's are stake locations
O's are strap attachment locations
X
X
x
IMPORTANT:
See other side for diagrams and further instructions
513-563-0600
X
x's are stake locations
o's are strap attachment locations
Jumper Rope
jumper
X
Tie the jumper ropes to the center pole.
800-670-4899
FAX 513-563-6757
x
X
X
rope
X
x
