MIAMI HEAT PUMP
Rev. 022014003
Water Source Heat Pumps
Vertical / Horizontal
HPX SERIES 7.5-TON & UP
Reader should pay particular attention to the words: NOTE, CAUTION, and WARNING. NOTES are
intended to clarify or make the installation easier. CAUTIONS are given to prevent equipment damage.
WARNINGS are given to alert reader that personal injury and/or equipment damage may result if
installation and/or service are not handled properly.
1
Advertisement
Table of Contents
Summary of Contents for Miami Heat Pump HPX Series
- Page 1 Water Source Heat Pumps Vertical / Horizontal HPX SERIES 7.5-TON & UP Reader should pay particular attention to the words: NOTE, CAUTION, and WARNING. NOTES are intended to clarify or make the installation easier. CAUTIONS are given to prevent equipment damage.
-
Page 2: Table Of Contents
Table of Contents 1. Description General Feature Overview Safety 2. Delivery Receipt and Inspection Storage 3. Installation General Codes and Ordinance Handling Location Service and Installation Clearance Mounting and Suspension ... -
Page 3: Description
The equipment is protect- In the cooling mode, heat is ejected from the heat pump ed by a standard limited into the source water loop. A cooling tower provides warranty under the cond- evaporative cooling to the loop water thus maintaining a ition that initial installat- constant temperature to the unit. -
Page 4: Safety
Safety WARNING! RISK OF DAMAGE, INJURY AND LOSS OF LIFE – Improper installation, adjustment, alter- Installation and ation, service or maintenance can cause service must be property damage, personal injury, or loss performed by a life. A qualified installer or service agency qualified licen- must perform installation and service. -
Page 5: Delivery
2. Delivery All shipments are FOB factory. It is the responsibility of If damage is found or items are missing: the receiving party to inspect the equipment upon 1. Note on Bill of Lading immediately. arrival. 2. Photograph damage if possible. 3. -
Page 6: Codes And Ordinance
dictated by the specific design of the system and the unit. Dependent upon the optional accessories ordered this equipment may contain fragile components and delicate Flexible connectors are required on all duct connections to electronics. Although the unit is constructed of sturdy minimize air leaks. -
Page 7: Duct Work
Galvanized pipe or fittings are NOT recommended for use with the HPX Series heat pumps due Sealing to possible galvanic corrosion. All plumbing, both supply and... -
Page 8: Condensate Piping
Drain pans in any air conditioning equipment, even when A Miami Heat Pump’s HPXVS model is furnished with its they have a built-in slope to the drain, will have moisture own Wall Handset. For this unit four (4) telephone wires... -
Page 9: General
Before the structure is occupied, the installation, 4. Start-up start-up personnel must take three essential steps: 1. Check Out 2. Start-up 3. Commissioning Equipment operation during con- struction is not recommended. Check Out Construction site pollution may Equipment should be thoroughly checked for loose wiring, seriously degrade performance, a free spinning blower wheel, and wheel fitting access pan- damage unit and void all manu-... -
Page 10: Operation And Maintenance
Make sure reversing valve (if included) is energized operating conditions, and to configure the air delivery sys- but neither fan nor compressor is running. tem for optimal performance. Reduce temperature setting to about five (5) deg- rees below room temperature. Fan should start Water Balancing immediately and compressor shall start after about three (3) minutes. -
Page 11: Filters
Inspect coils, clean if dirty or obstructed in any Indoor Coils way. Coils should be inspected and cleaned annually to ensure In case of excessive noise or unusual operation there is no obstruction to airflow. Dirty evaporator coils check for reason and act accordingly. -
Page 12: Troubleshooting
6. Troubleshooting Possible Problems, Causes & Solutions Problem Possible Cause Checks and Corrections Power Supply OFF Apply power, close disconnect switch. Blown Fuse Replace fuse or reset circuit breaker. Check for correct fuses. Voltage Supply Low Contact local power company. Entire unit does Set the fan to “ON”, the fan should run.
