(1) Description
(1.2) Installing The Device
(1.2.1) Place the incubator on a level and horizontal surface.
(1.2.2) Insert the column connector of the adapter into the
device, then plug the adapter into a wall outlet.
(1.2.3) Power ON the main switch. The incubator is ready to
operate when the display becomes visible.
(2) Technical Data
Model
Power supply
Power
Temperature range
Accuracy of the temperature
Display accuracy
Heating time (from 20°C to 80°C)
Ambient temperature
Dimensions (W×D×H)
Weight
Incubator - Manual
Block
Display
110 V
DC 24 V
u-test
DC, 24 V
35 W
20°C ~ 80°C
≤ ± 0.5°C
0.1°C
≤ 10min
5°C ~ 35°C
110 mm x 150 mm x 85 mm
0.65 kg
Panel
(1.3) Crushing a SCBI
(1.3.1) Insert one third of the way into crusher and push side-
ways to break the vile.
Power Switch
Power Connector
Crusher
Manual Continues on Reverse
