- Page 1 Quick Start Guide Model :...
-
Page 2: Package Contents
Thank you for purchasing iwata Master E photography light! Please read this Quick Start Guide carefully before using the product and keep it for reference. Package Contents Ｍaster E、Portable package、USB Charging Cable、 Quick Start Guide. Specifications... - Page 3 1. CCT Range：2600K~8000K（±200K） 2. CCT Color Rendering Index: CRI≥96，TLCI≥98 3. Maximum Power：16W 4. LED Beam Angle：45° 5. Adjustment Range of Beam Angle Limitator：0°- 170° 6. Illuminance (0.5 meter apart)：2000lx@8000K，1700lx@2600K 7. Operating Mode：CCT /Scene Effect 8. Internal Lithium Battery Capacity：14.8V/2200mAh 32.5Wh 9.
- Page 4 15. Allowable Temperature Range：In use between -5~30℃ During charging between 0~30℃ Storage between -20~60℃ Layout of MA-02 M ode Butto n Col or Adju sti ng Ri ng Di sp lay Scre en Powe r S witch Bri gh tne ss Adju sti ng Ri ng Ring 2 of Beam Angel Limitator USB Ch arg ing P ort...
- Page 5 Description of Adjusting Rings Brightness adjusting ring. Rotate the adjusting ring to switch the corresponding parameter in the setting interface Color adjusting ring. Rotate the adjusting ring to switch among color temperature,Scene effect or preset adjustment. In the setting interface, it’s used for the columns in the list. Description of Power Switch Slide the power switch to the "green"/"red"...
-
Page 6: Beam Angle Adjustment
Beam Angle Adjustment Rotate the adjusting ring of beam angel limitator to narrow or enlarge the beam angle. The adjusting angle range: 0 ° - 170 °. Screen Icons CCT Mode 2.0h Indicator INT ( % ) CCT ( K ) Current Selected Item 8000 Current Color Temperature... - Page 7 Rotate the adjusting rings to adjust brightness and color temperature. Brightness range: 1%-100%, Color temperature range: 2600k-8000k. Scene Effect 2.0h button to select between Indicator effect（EFFECT）and preset INT ( % ) EFFECT PRESET （PRESET）adjustment,rotate the Current Effect color adjusting ring to change current Current Preset parameters.
- Page 8 Scene Effect Description A.Fire A1:Candle A2:Fireplace A3:Bonfire B.Lightning B1:Intermittent Lightning B2:Frequent Lightning B3:Continuous Lightning C3:Paparazzi C.Photoflash C1:Product Launch C2:Press Conference Power Icon Description 1.Remaining Battery Time 2.Insufficient Power Supply 3.Remaining Battery 2.0h Capacity INT ( % ) CCT ( K ) 5500...
- Page 9 4.External Power Connected 5.Remaining Charging Time INT ( % ) CCT ( K ) 4300 1. Remaining Battery Time: "m" for minute and "h" for hour. 2. X icon comes out, When Master E works with insufficient power supply, for example, connected to a 5V / 1A charger or a charging cable of low quality.
- Page 10 Temperature Icon Description High temperature warning Low temperature warning The low temperature warning icon appears when ambient temperature is below the lowest allowable temperature. INT ( % ) CCT ( K ) Master E may not work properly under this circumstance. 5500 The high temperature warning icon appears when ambient temperature is above the highest allowable temperature.
- Page 11 Setting Interface Description Adjusting Rings Lock Adj. Rings Lock Screen Orientation Lock Screen Lock Standby Time 10m/30m/60m/120m Off Art-in System Art-in Group A-Z A Group Factory Reset Press and hold button to enter setting menu. Rotate color adjusting ring to select setting option. Rotate brightness adjusting ring to switch current parameters.
- Page 12 On-current parameters of the Adjusting rings are locked down. Adj. Rings Lock On-current screen orientation is fixed. Screen Lock When the light is off and not operated,system will be Standby Time automatically standby. On/Off Art-in For group setting in Art-in system. "-" means ungrouped. Group Select "Yes"...
-
Page 13: Battery Use And Maintenance
Battery Use and Maintenance 1. When the battery of Master E is fully charged, please detach Master E from the USB cable. 2. Please do not charge the battery, when the ambient temperature is beyond the allowable range, otherwise Master E can be damaged or battery life can be shortened. 3. -
Page 14: Disposal Information
3. Do not hit or hammer this product with hard objects. 4. Master E’s temperature may increase, when it works. Please make room for heat dissipation. 5. Do not expose this product to the environments with drastic changes in temperature and humidity.
