Summary of Contents for Form Factor Audio Bi 1000 Di
- Page 1 F orm Factor Audio. U ser Manual: Bi 1000 Di Bass Amplifier Bi 500 Di Bass Amplifier Made in USA...
- Page 2 T able of Content 1.Safety Instruction Page 2 2.Specifications Page 3 3.Front Panel Page 4 4.Rear Panel Page 5 5.Operating Instructions Page 6 6.Warranty Page 6 8.Registration Page 6...
- Page 3 WARNING: T o reduce the risk of fire or electric shock, do not expose the equipment to rain or moisture. Form Factor Audio assumes no responsibility for any damage or injury that results from improper use or service. CAUTION: R ISK OF ELECTRICAL SHOCK!...
- Page 4 Specifications: ● Model: Bi 1000 Di ● Configuration: Class D Amplifier ● Power Rating: Power 1000 Watts RMS @ 4Ω / 750Watts RMS@6Ω/ 600 Watts RMS @ 8Ω< 1%THD ● Mains input voltage and current: Nominal rating: 115 / 230 VAC, 12.5/10.0 A...
- Page 5 Front Panel: Inputs/Outputs. Bass Guitar Inputs: There are two instrument inputs on the unit, one for A ctive and one for P assive basses. The Active input is low sensitivity and lower impedance to suit the output from Active basses (Basses with powered preamps).
- Page 6 Rear Panel: Power In - Power in connector / Use cable with lockable (Power Con) connector supplied by factory. Speaker Output - Speakons. Standard chassis connectors for loudspeakers. Direct Output Post-EQ- X LR. Balanced Direct Out. The signal goes after the preamplifier with all the corrections. In this case, Gain influences the level of the output signal.
- Page 7 Form Factor Audio will, at their discretion, replace or repair any unit or part thereof, which is found by Form Factor to be defective. This warranty will not apply to the damage of covering, fittings or finishes when affected by carelessness, accident or extreme climate changes.
