  • Page 1 WAVELET – V2 WA1111-xx-V2 QUICKSTART GUIDE Jan 2020 P/N0100706...
  • Page 2 It is important that you read the Quick Start Guide in a controlled environment prior to installation. Set up, activate, and successfully test the entire system (Wavelet-V2, sensors, antenna connection) indoors, in a controlled environment, before going to the field for installation.
  • Page 3 The Ayyeka Limited Warranty covers only Ayyeka-supplied hardware and software for the duration of the warranty period as per the warranty terms and conditions. Ayyeka is not liable for damage or injury as a result of handling, installation, or maintenance of its supplied systems.
  • Page 4 SCHEMATIC FRONT Magnetic Activator IP 68/ NEMA 6P Wavelet mechanical enclosure Slots for zip ties and/or bolts for mounting Panel connectors protector 13.3 cm (5.2 in.) LoRaWAN antenna port BOTTOM (for LoRaWAN- enabled devices) Discrete port Cellular antenna port Serial port External power port Analog port...
  • Page 5 SCHEMATIC INTERNAL UPPER ENCLOSURE Military-grade lithium battery pack (field replaceable, non-rechargeable) Interface board ON/OFF switch Indicator LEDs INTERNAL LOWER ENCLOSURE GSM antenna GPS antenna SIM card slot #1 SIM card slot #2 Memory card Cellular modem...
  • Page 6 COMPONENTS Wavelet Activator Panel connectors protector Wavelet Device M12 field attachable M8 female field attachable sensor connectors power connector (optional; ordered separately) (optional; ordered separately)
  • Page 7 COMPONENTS Cellular antenna and Zip ties, screws, and anchors mounting bracket (REQUIRED and sold separately)
  • Page 8: Sensor Connection

    SENSOR CONNECTION Connect the sensor cable(s) assembly with the field attachable connector to the mating panel connector on the Wavelet. See pages 20-24 for more details. Turn the adjustable stainless-steel end piece to secure the field attachable connector to the Wavelet. CAUTION: Do not turn the black plastic hood of the connector.
  • Page 9: External Antenna Connection

    EXTERNAL ANTENNA CONNECTION Connect the Cellular antenna to the antenna port (ANT1). Cellular antenna (required) The antenna does not appear in the remaining depictions in this guide, but it must remain connected after it is properly secured to the appropriate panel connectors.
  • Page 10 WAVELET POTECTOR After connecting sensors and antenna, place the Wavelet protector above the connector ports and secure the Wavelet protector into the Wavelet enclosure. Upper Clips Protector Arches Lower Clips a. Insert the two lower clips into the two lower holes of the Wavelet enclosure.
  • Page 11 The LED will turn off when the transmission is complete. GSM communication error. The device failed to Green-Red LEDs blink 5x transmit. Access the Ayyeka user interface at https://home.ayyeka.com by using your log-in credentials. Expect data to appear 5 – 10 minutes after the test mode is initiated.
  • Page 12 Wavelet installation location and activate again. If the problem persists, contact the You can now install the Wavelet in the field and begin to collect and Ayyeka Support Team for help: view your data! support@ayyeka.com +1 (310) 876-8040 (US) +31-40-209-1001 (EMEA)
  • Page 13 AyyekaGo MOBILE APP If you haven’t already done so, download the AyyekaGo mobile app for iOS or for Android. Search the App Store or Google Play for “AyyekaGo” or use the QR codes below. There are two ways to pair your phone with your Wavelet: 1.
  • Page 14 Wait for at least 15 minutes, then log pair with the device and confirm in to the user interface at transmission. You can also log into home.ayyeka.com to confirm the the StreamView user interface using updated location on the map. your credentials to validate...
  • Page 15 WAVELET MOUNTING Additional tools and/or materials might be required (not included) Rotary hammer Screwdriver with Phillips PH 1 bit...
  • Page 16: Wall Mounted

    WAVELET MOUNTING Secure the Wavelet on a wall, pipe, or other secure mount location by using zip ties or screws. Wall Mounted Pipe Mounted...
  • Page 17: Antenna Mounting

    AyyekaGo mobile app. securing them to the panel connectors. Ayyeka recommends using Dow Corning If needed during installation, use the Molykote 55 O-Ring Grease, though Transmit Now command in the similar products can be effective.
  • Page 18 Note: Ayyeka supplies antenna wall mounting hardware and various antennas, including in-road antennas — contact Support for details. USING YOUR OWN ANTENNA If you intend to use your own antenna, verify that the antenna uses an SMA male connector.
  • Page 19 YOUR WAVELET IS SUCCESSFULLY INSTALLED!
  • Page 20 WAVELET PINOUT Panel Connector Inputs 4x analog 1x discrete RS485, RS232, SDI-12 (16 channels) 4x discrete 6-24VDC...
  • Page 21 WAVELET PINOUT– PORT #1 M12 8-pin male panel connector Connector Field Attachable Connector Function Description Pin # Pin Assignment Signal 4-20mA / 0-27.5V Input #1 Front Back IO_4 – dry contact, open collector, Signal input/output 0V / 2.8V Wavelet 12V Sensor Power Supply Supply+ #2 (+) Wavelet 12V Sensor Power Supply...
  • Page 22 WAVELET PINOUT– PORT #2 M12 8-pin female panel connector Connecto Field Attachable Connector Function Description r Pin # Pin Assignment Signal RS232 TX Front Back Wavelet 12V Sensor Power Supply Supply+ #4 (+) Wavelet 12V Sensor Power Supply Supply+ #3 (+) Signal SDI-12 Signal...
  • Page 23 WAVELET PINOUT– PORT #3 M12 5-pin male panel connector Field Attachable Connector Connector Function Description Pin # Pin Assignment PCNT_0 – pulse counting, dry contact, Front Back Signal open collector, input/output 0V / 2.8V IO_3 – dry contact, open collector, Signal input/output 0V/2.8V PCNT_1 –...
  • Page 24: Power Connector Pinout

    POWER CONNECTOR PINOUT If you are using an external power source, refer to the following pinout: EXTERNAL POWER: M8 3-pin female power connector Negative (-) 6-24VDC (+) Connection Wires to connect: Cable wire cross 0.14 – 0.5 mm Installation tool for selection surface area wire termination (included)
  • Page 25 NOTES...
  • Page 26 NOTES...
