HPSA-7100-R SERIES
INSTALLATION AND USER MANUAL
Part Number P01- 04946 Rev C
July 2014
Cooper Notification
th
7246 16
Street East, Suite 105
Sarasota, FL 34243
Tel.: 941.487.2300
Fax: 941.487.2387
www.coopernotification.com
Cooper Notification is
Notification

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPSA-7100-R Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Waves HPSA-7100-R Series

  • Page 1 HPSA-7100-R SERIES INSTALLATION AND USER MANUAL Part Number P01- 04946 Rev C July 2014 Cooper Notification 7246 16 Street East, Suite 105 Sarasota, FL 34243 Tel.: 941.487.2300 Fax: 941.487.2387 www.coopernotification.com Notification Cooper Notification is...
  • Page 2 This page intentionally left blank...
  • Page 3 Under the copyright laws, this manual may not be reproduced in any form without the prior written consent of Cooper Notification, Inc. No patent liability is assumed with respect to the use of the information contained herein. Any use of WAVES Software is subject to and conditioned upon acceptance of the Cooper Notification, Inc. software licensing agreement.
  • Page 4 It is the responsibility of the Installer to obtain structural, mechanical and civil engineering approval for all installations and to ensure the site and equipment installation complies to local/national codes and standards and meets all requirements set by the Authority Having Jurisdiction. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 5 Select an appropriate compound based on environmental factors and the type of hardware and materials used during installation. • All wiring to and from the HPSA must be Class 2/Power Limited. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 6 • TUV Certification Designed to meet Life Safety requirements, CE Mark approved and TÜV certification, the HPSA-7100-R Series integrates directly to an existing audio source, including voice-capable Fire Alarm Control Panels (FACP). The HPSA-7100-R Series can be also be integrated with Eaton’s SAFEPATH Voice Evacuation Systems (SP40S) and Mass Notification Systems (SPMNS).
  • Page 7 Speaker Lines: 12 - 16 AWG (Connectors are limited to #14 Lug; Installer should transition appropriately wire to wire lug.) Audio Input and Control Lines: 12 - 22 AWG AC Mains: 10 - 16 AWG HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 8 11 Ohm (Typical) TABLE FR.6 Environment Specifications Operating -40°F to 140°F (-40°C to +60°C) Temperature Electronic Cabinet NEMA 4X Rating Transients Built-in protection on mains, external interfaces, and speaker lines Protection HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 9 5. Updated and added Cautions and Warnings 6. General verbiage and typo corrections 7. Replaced Figure 1.5 8. Updated horn installation figures in Chapter 5 9. Added “Approvals” Section to Front Matter HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 10 HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 11: Table Of Contents

    Seismic Activity ......................13 Temperature Variations....................13 HPSA AC Input Voltage .....................14 Electrical Considerations....................14 Chapter 3 Installing the Speaker Array Installation Methodology..................15 Unpacking Equipment ..................16 Installing the Speaker Array .................16 Hearing Protection Warnings................24 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 12 Connect a Laptop to the Device Controller Board............63 Prepare HyperTerminal....................63 Install HyperTerminal ...................63 Verify the Communications Port................64 Configure HyperTerminal ..................64 Navigating HyperTerminal to set HPSA Volume Controls........66 Adjusting Volume Settings ..................70 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 13 HPSA Components, Cabling and Wiring ..............102 HPSA Cabinet Diagram .....................103 HPSA Electronics Cabinet Wiring Diagram..............104 HPSA Cable and Wiring Chart ...................107 HPSA PDB (A4) Test Points and Voltages ..............108 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 14 Dedicated SP40S With Multiple HPSA-7100-Rs ..........133 Multi-Use SP40S With Multiple HPSA-7100-Rs ...........134 Combination FACP/SP40S and Multiple HPSA-7100-Rs........135 Appendix B Omni-directional Horn Array Pole Mount Heights HPSA-7100-R Series Speaker Mounting Heights ..........138 Appendix C Driver/Speaker, Audio Input and Control Wire Gauge Distances Driver (Speaker) Wiring ..................139 Audio input and Control Wiring................140...
  • Page 15 1 VRMS Audio Input and Control Wiring and Distances ..........142 Appendix D HPSA-7100-V-KIT AMB Audio IN Connections ..................144 Optional 70.7/100 VRMS Interface Module Connections ........145 AMB Settings......................146 HPSA Unit Volume Settings .................146 INDEX HPSA-7100-R Series Installation and User Manual xiii P/N P01- 04946 Rev C...
  • Page 16 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 17 Stainless Steel Door Clamps ................55 Figure 6.4 Battery Shelf ....................56 Figure 6.5 Battery Location and Terminal Positions ............57 Figure 6.6 Battery Cable Connections ................58 Figure 7.1 Red Power Button................... 60 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 18 AMB’s 70.7V/100V Input and NAC/Sounder Trouble Connections....127 Figure A.3 AMB’s 1V/25V Input and Closed Contact Trouble Connections ....128 Figure A.4 AMB’s 70.7V/100V Input and Closed Contact Trouble Connections .... 129 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 19 AMB J5 Audio Connection for 70.7/100 VRMS..........144 Figure D.3 AMB Plate Assembly Interface Module............145 Figure D.4 AMB SW1 - Set to the 1V Position for 70.7/100 VRMS Audio Inputs .... 146 HPSA-7100-R Series Installation and User Manual xvii...
  • Page 20 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 21 1 VRMS Wire Gauge and Distances to Furthest HPSA........142 TABLE D.1 AMB Audio IN Connections ................144 TABLE D.2 Interface Module Connections and Jumper Settings ........145 TABLE D.3 100 VRMS Unit Volume Settings ..............146 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 22 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 23 This chapter provides instructions for connecting the speakers and power cables. Chapter 6, Installing the Batteries This chapter discusses the steps for installing the batteries in the HPSA-7100-R cabinet and the optional external battery compartment. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 24: Table Fr.1 Table

    100 V audio inputs Liquid Crystal Display. The alpha-numeric readout screen located on the HPSA Control Panel. Notification Appliance Circuit. Power Distribution Board. SP40S SAFEPATH Audio Panel xxii HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 25: Table Fr.3 Table

    For assistance, comments, or inquiries please contact Customer Satisfaction at the following: Cooper Notification 7246 16th Street East Suite 105 Sarasota, Florida 34243 U.S.A. Telephone: 1.800.631.2148 941.487.2379 Fax: 941.487.2389 Email: mvsr-support@cooperindustries.com HPSA-7100-R Series Installation and User Manual xxiii P/N P01- 04946 Rev C...
  • Page 26 Preface xxiv HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 27: Chapter 1 Introduction

    • System Components WHAT IS THE HPSA-7100-R? High Power Speaker Arrays (HPSA-7100-R Series) broadcast intelligible voice messages and tones, covering large geographic areas. The HPSA can be installed on a static pole, affixed to a building or mounted on a rooftop.

  • Page 28: System Requirements

    P10-00096 Network Configuration Tool Administrator Manual P01-04933 HOW DOES THE HPSA-7100-R WORK? The HPSA-7100-R Series can be integrated and controlled by either Cooper Notification’s ® SAFEPATH 4 (SP40S) Voice Evacuation Systems, SAFEPATH Mass Notification Systems (SPMNS), or other external audio system.

  • Page 29: System Components

    Figure 1.2 and the 180 Uni-directional (side-by-side) coverage is shown in Figure 1.3. FIGURE 1.2 Positioning of Omni-Directional Speaker Pairs FIGURE 1.3 Positioning of Uni-Directional Speaker Pairs HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 30: Electronics Cabinet

    • Power Distribution Board (PDB version M52-05705) • Audio and Monitoring Bridge (AMB) • Amplifier Module • Control Panel • Power Supply • HPSA-MIC (Optional) • HPSA-7100-V-KIT (Optional for 70.7 and 100 V Audio Input) HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 31: Power Distribution Board (Pdb)

    +48VDC Battery Charge voltage to the four 12VDC Back-up Batteries Steps the 36 VDC down to +15 VDC and distributes as follows: • • +15VDC to the Amplifier Board and Controller HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 32: Audio And Monitoring Board (Amb)

    The HPSA-7100-R is powered by four, maintenance-free AGM SLA batteries. When active, the HPSA runs on battery power only. Therefore, the type and quality of batteries used is critical for proper operations. Contact Cooper Notification for replacement. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 33 System Components HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 34 Introduction HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 35: Chapter 2 Site Design

    Only authorized trained personnel should install and activate the HPSA and its associated hardware and software. In addition to factory WAVES training, it is recommended the installer attend the HPSA-7100-High Power Speaker Arrays E-Learning course offered via the Cooper Notification web site located at the following URL: http://www.cooperindustries.com/content/public/en/resources/education/elearning.html...

  • Page 36: Acoustic Considerations

    Amps. Take care to ground one end of the shielded cable. AC Power, Data and Audio cables should be placed in separate conduits, to minimize the risk of interference. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 37: Grounding And Lightning Considerations

    However, the site designer and the installer must take into consideration all local, regional and national codes and standards may apply. Refer to Appendix B for information regarding the Omni-directional pole mount Horn Array height installation. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 38: Distances Between Hpsa And Speakers

    Refer to Appendix C for additional information regrading speaker wire gauge and distances. Recommended wiring distance between the HPSA Electronics Enclosure and Speakers is 100 ft. max. Each Speaker should have a separate cable run. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 39: Wind Load Considerations

    Extreme temperatures falling outside the range of normal operating conditions could adversely affect system operation. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 40: Hpsa Ac Input Voltage

    Considerations for placement of the HPSA should include access to a standard electrical outlet. A laptop computer is needed when configuring the HPSA during initial set up and activation. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 41: Chapter 3 Installing The Speaker Array

    HPSA-7100-R speakers are designed to be mounted to a steel pipe such as a pole, mast, tripod or other pole-mounting method. This Chapter details how to mount to a pipe, however does not address options for installation of the pipe. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 42: Unpacking Equipment

    Appendix B for Omni-directional Speaker Array pole mount height guidelines used with the HPSA-7100-R. when Refer to the site design to determine the number of speakers to be installed (2–8). The speakers must be installed as a pair. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 43 (see Figure 3.1) Be sure to mark both ends of the cable to ensure proper connection to the amp. Refer to Chapter 5, Connecting Cables to Electronics Components for more information HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 44: Figure 3.1 Thread Cable Through Speaker Recess

    Additionally, to prevent removal of the driver cover, place a mark on the outside of the horn at the edge, just below where the drain is located on the driver. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 45: Figure 3.2 Attach The Driver To The Speaker

    8. If not already done, attach the quick connect to each of the driver terminals as described in Step 2. Ensure these connections are tight for a proper connection. FIGURE 3.3 Attaching the Quick Connect to the Speaker Driver HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 46: Figure 3.4 Attach The Horn Driver Cover

    13. Refer to the site design to determine which speaker configuration to use: omni- directional (360°) (facing opposite directions) or uni-directional (180°) (facing the same direction). FIGURE 3.5 Correct Positioning of Multiple Uni and Omni Directional Speaker Pairs HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 47: Figure 3.6 Positioning Omni-Directional Speakers

    Ensure the gap between the speaker edges, as shown in Figure 3.7, are the equal on each side of the pole (the gap will vary depending on the size of the pole); tighten the hexagon nuts. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 48: Figure 3.7 Verify Gap Distances Between Drivers Are Equal

    Verify the gap distance between the speaker edges is equal on each side of the pole; if the gap is not equal, additional speakers added to the system will not properly line up. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 49: Figure 3.9 Label Cable With Speaker Number

    Audio Input connections from the HPSA to the Drivers. Be sure to ground one end of the cable. 16. Continue with the installation procedure as outlined in Chapter 4, Installing the Cabinet. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 50: Hearing Protection Warnings

    HPSAs and Speakers in accordance with the local protection codes and OSHA requirements. Figure 3.10 provides examples of Hearing Protection and Warning signs. FIGURE 3.10 Hearing Protection and Warning Sign Examples HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 51: Chapter 4 Installing The Cabinet

    The contracted installation crew is responsible for procuring all installation equipment and hardware not included with the Cooper Notification equipment. All mounting hardware not provided by Cooper Notification must be corrosion resistant. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 52: Unpacking Equipment

    INSTALLATION OF THE HPSA AND SPEAKER/HORN ASSEMBLIES SHOULD BE DESIGNED AND INSPECTED FOR STRUCTURAL SAFETY AND INTEGRITY BY QUALIFIED PERSONNEL. ALL INSTALLATIONS SHOULD BE IN ACCORDANCE WITH COUNTRY, NATIONAL, OR LOCAL AUTHORITIES HAVING JURISDICTION. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 53: Installing A Ground Mount

    Measurements in Figure 4.1 are shown in inches. • 36 inches = 94.1 cm • 48 inches = 121.9 cm • 12 inches = 30.5 cm • 13 3/8 inches = 34.0 cm HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 54: Installing The Pedestals

    ELECTRONICS IN THE CABINET. COVER ALL ELECTRONICS PRIOR TO DRILLING. 5. Drill holes into the electronics cabinet for each mounting hole (14 total) and mount the pedestals to the cabinet using the hardware provided. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 55: Ground Mounting The Electronics Cabinet

    Refer to the structural, mechanical, or civil engineer to ensure compliance with local codes and requirements. 3. In the location determined in the site design, mark the positions for the mounting positions. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 56: Figure 4.3 Wall Mounting Hole And Slit Dimensions

    7. Install the appropriate hardware for the top two mounting holes and secure. Refer to a structural, mechanical, or civil engineer to ensure compliance with local codes and requirements. FIGURE 4.3 Wall Mounting Hole and Slit Dimensions HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 57: Cabinet Penetrations

    Conduit Hole Size TABLE 4.1 Recommended Trade Size of Conduit Recommended Diameter Minimum Diameter of (Inch) of Opening (mm) Flat Surface (mm) .375 3.75 1.25 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 58 Installing the Cabinet HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 59: Chapter 5 Connecting Cables To Electronics Components

    Driver (Speaker) wiring and connectors are included in kit P/N CAB-SPKR-KIT. It is strongly recommended that only the connectors and cable supplied with CAB-SPKR-KIT be used during installation and connection of the the Speakers to the HPSA. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 60: Wiring Speaker Array

    Panel and all LEDs on the boards are off. Ensure all Country, National and Local codes and regulations are followed when installing the system. Push the Red power button. FIGURE 5.1 Power Down the HPSA-7100-R HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 61: Figure 5.2 Pull Speaker Cables Into The Electronics Cabinet

    “Pull Speaker Cables into the Electronics Cabinet” for the correct positions. Only these positions should be used. Speaker wire entrance Speaker wire entrance FIGURE 5.2 Pull Speaker Cables into the Electronics Cabinet Speaker wiring is supervised, non-power limited HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 62 DIRECTIONAL OR OMNI-DIRECTIONAL CONFIGURATION. 8. When wire connection is complete, tighten the screws to secure the leads. 9. Secure the speaker lines to the cabinet using the four available zip tie anchors. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 63: Connecting The External Audio System To The Hpsa-7100-R

    • Care must be taken to ensure none of the HPSA-7100-R inputs and voltages are exceeded • End of Line Resistors (EOLR) should be installed at the furthest HPSA on the circuit • Refer to Appendix A for the following Application wiring diagrams: HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 64: Connect An External Audio System To The Amb

    The HPSA-7100-R’s Audio Monitoring Bridge provides a User configurable 1 V 25 V Audio Inputs. The optional HPSA-7100-V-KIT expands the configurations to include 70.7 V and 100 V Audio Inputs. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 65: Audio And Nac Cables And Connections

    4. Connect the Trouble monitoring cable to the appropriate trouble connections on the AMB as described in Section 5.2.1.1.4. Insert the wire through the left side, into electronics cabinet FIGURE 5.4 Pull the Wires through the HPSA-7100-R Cabinet HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 66: Audio Connections

    Some audio systems require end of line (EOL) resistors for supervision. Install the EOL resistors across the AUD IN and AUD RET terminals on the AMB according to the manufacturer's instructions. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 67: Figure 5.5 1 Vrms And 25 Vrms Amb Audio In Using Nac Activation

    HPSA Trouble being reported. The single trouble includes multiple HPSA Trouble circuits; the Operator will need to troubleshoot the HPSA to identify which specific Trouble circuit is causing the reported trouble. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 68: Figure 5.6 70.7 Vrms And 100 Vrms Amb Audio In Using Nac Activation

    Trouble circuit is causing the reported trouble. For 70.7 and 100 V set SW1 to the 1V position. FIGURE 5.7 Set SW1 to the 1VPosition for 70.7 and 100 V Audio Input HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 69: Figure 5.8 Audio And Monitoring Bridge Connections

    Connecting the External Audio System to the HPSA-7100-R TAMPER BATT BATT Shorting Bars FIGURE 5.8 Audio and Monitoring Bridge Connections FIGURE 5.9 Shorting Bar/Jumper NO/NC Positions HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 70: Nac Connections

    System; supervision must be provided by the External Audio System. 3. If required by the External Audio System, install the End-of-Line Resistor across J5-5, CC IN A and J5-6, CC IN B. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 71: Figure 5.10 1V/25V Audio Input Using Closed Contact Activation

    Source is Normally Open or Normally Closed. The configuration shown in Figure 5.10 and Figure 5.11 will result in each individual HPSA Trouble being reported to the External Source. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 72: Trouble Connections

    EOLR(s) will determine if the AMB is providing all the individual Trouble states or if it is providing a single (consolidated) Trouble. Refer to Appendix A for additional Contact Closure and NAC wiring applications. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 73 3. Install an End-of-Line Resistor (EOLR) as required by the External Audio System, across the appropriate Trouble output (Shown as J2-6, NO/NC and J2-7, COM in Figure 5.5 and Figure 5.6). HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 74 C - NO 11 to 12 Open Closed Drivers J12 1-2 C - NC 11 to 12 Closed Open a. NO = Normally Open b. NC = Normally Closed HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 75: Connecting Ac Mains To The Hpsa

    2. Connect one end of the AC wiring from the AC power source. 3. Penetrate the HPSA-7100-R cabinet. Refer to Figure 5.12, “AC Power Penetration Location.” and.Section 4.5, Cabinet Penetrations for more information. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 76: Figure 5.12 Ac Power Penetration Location

    (2.) Wrap both lines around and through the ferrite again (resulting in two passes through the ferrite). (3.) Position the ferrite to be immediately adjacent to the point where the AC enters the enclosure. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 77: Figure 5.13 Ferrite Location

    Earth Ground to the Ground Stud. Ground stud Neutral and Line connections FIGURE 5.14 HPSA-7100-R AC Power Connections 6. Verify all connections are tight and compliant to applicable codes/standards. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 78 Connecting Cables to Electronics Components HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 79: Chapter 6 Installing The Batteries

    • Installing the Batteries in the Cabinet PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL THE HPSA-7100-R. FAILURE TO FOLLOW DIRECTIONS CAN CAUSE BODILY INJURY AND/OR DAMAGE TO THE HPSA-7100-R. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 80: Opening And Closing Cabinet Doors

    FIGURE 6.1 Stainless Steel Door Clamp Locations 3. Pull each of the six stainless steel door clamps away from the HPSA cabinet and door until they stop. 4. Pull the door open. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 81: Closing And Securing The Door

    Stainless Steel Door Clamp Positions FIGURE 6.3 Stainless Steel Door Clamps 4. Secure the area and/or replace any locks that may have been applied to the HPSA cabinet door. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 82: Installing The Batteries

    Battery 1: Positive + terminal at bottom.  Battery 2: Negative terminal at bottom. –  Battery 3: Positive + terminal at bottom.  Battery 4: Negative terminal at bottom. – HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 83: Figure 6.5 Battery Location And Terminal Positions

    Attach the other end to the NEG ( ) terminal of Battery 3. – g. Attach the Ring terminal end of the POS (+) battery cable (36 inches/91.44 cm) to Battery 4. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 84: Figure 6.6 Battery Cable Connections

    Contact Cooper Notification for replacement batteries. Ensure the batteries are fully charged prior to initial use. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 85: Chapter 7 Activating The Hpsa-7100-R

    HAZARDOUS VOLTAGES AND CURRENTS ARE PRESET IN THE HPSA ELECTRONICS CABINET. ONLY PROPERLY TRAINED SERVICE PERSONNEL ARE ALLOWED TO ACCESS AND PROGRAM THE STEPS LISTED IN THIS CHAPTER. USE EXTREME CAUTION WHEN WORKING INSIDE THE HPSA. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 86: Figure 7.1 Red Power Button

     A short beep is heard from the Control Panel.  A Silent Test occurs. A Silent Test occurs every three minutes automatically. Push the red Power Button, adjacent to the FIGURE 7.1 Red Power Button HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 87: Trouble Led Descriptions

    If the Dvrs LED is illuminated, there is a Trouble in the driver circuit, Dvrs such as an Open or a Short on the line. See Table 7.5 for additional infor- mation. (D15) HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 88: Setting The Volume Controls

    A portable notebook (laptop) with HyperTerminal installed, and a straight- through male-to-female DB9 serial port cable are required to configure the Volume Controls. If the laptop does not have a serial DB9 port, a USB/serial converter is required. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 89: Connect A Laptop To The Device Controller Board

    3. On the Add/Remove Programs menu, select the Windows Setup tab. 4. On the Windows Setup tab menu, select Communications and press the Details button. 5. Select the checkbox for HyperTerminal. 6. Click OK and then click OK again. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 90: Verify The Communications Port

    FIGURE 7.4 Default Telnet Program Dialog Box 3. Type the connection Name, select a shortcut icon and select OK (see Figure 7.5); the Connect To dialog box opens. FIGURE 7.5 Connection Description Dialog Box HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 91: Figure 7.6 Connect To Dialog Box

    5. Enter the following values for the Port Settings.  Baud Rate (Bits per second): 115200  Data bits: 8  Parity: None  Stop Bits: 1  Flow Control: None HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 92: Navigating Hyperterminal To Set Hpsa Volume Controls

    Adjust Master Volume and Master Limit settings down if a reduced sound output is required. ONLY LINE-IN, MASTER AND MASTER LIMIT SHOULD BE ADJUSTED. ALL OTHER SETTINGS MUST REMAIN AT THE FACTORY DEFAULT. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 93: Table 7.2 Volume Types

    1. Verify the Control Panel on the HPSA is set to the Main Menu by pressing the CANCEL button located on the bottom right side of the Control Panel keypad as HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 94: Figure 7.9 Hpsa Control Panel

    Section 7.2.3.1. verified or adjusted in b. Stop at [Line In][Left]: Figure 7.11 identifies the Line-In setting, which will be Section 7.2.3.1. verified or adjusted in HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 95: Figure 7.11 Adjusting The Line-In Setting Using Hyperterminal

    Press the “D” key on the laptop keyboard to decrease the setting by 10  Press the “d” key on the laptop keyboard to decrease the setting by 1 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 96: Adjusting Volume Settings

    If possible, use the 1 KHz tone in the External Source for setting the HPSA Volume Controls; alternatively use a 1 KHz tone from a source co-located at the External Source’s location. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 97 AMB, then adjust the Line-In on HyperTerminal to be 524 (the final Line-In value will be adjusted when measuring the Amplifier Output Voltage in Section 7.2.3.3). HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 98: Setting The Master Volume And Master Limit

    FAILURE TO PROPERLY SET THE MASTER LIMIT COULD RESULT IN A USER OVERRIDING THE REDUCED MASTER VOLUME SETTING. WHEN A REDUCED MASTER VOLUME SETTING IS REQUIRED, THE MASTER LIMIT MUST BE SET TO MATCH THE (REDUCED) MASTER VOLUME SETTING. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 99: Reduced Audio Output Master Volume And Master Limit Settings

    HPSA is configured will be active and provide an output voltage reading on the AC Multimeter. The HPSA configurations and their respective active output Channels are listed in Table 7.4. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 100: Measuring Amplifier Output Voltage Under No-Load Conditions

    External Source level input. An explanation of all levels and their respective default values can be found in Table 7.3. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 101: Figure 7.13 Measuring Output Voltage On The Amplifier Board

    For Channel 4: disconnect the AC VRMS Multimeter from the Amplifier Board’s TB3 and connect it to the (+) and (-) terminals of TB4 (Channel 4); measure, record and verify the voltage is within the acceptable range. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 102: Measuring Amplifier Output Voltage Under Load Condition

    The initial readings may be high; for a system under load (drivers connected), allow the system to stabilize 1 - 2 minutes prior to measuring the Amplifier Output voltage. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 103: Testing The System

    Master Volume, performing administrative diagnostic tests and configuring performance settings. Table 7.5 describes the command options that are accessible from the Control Panel. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 104: Figure 7.14 Hpsa-7100-R Control Panel

    10X Switch: Used in conjunction This menu does not time out. with Volume Up / Volume Down. Multiplies the action by 10 (2.5 dB). Back: Returns the screen to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 105 GG (all good), (BB) all bad, GB, or BG (one driver good, one bad). Extended Status: This function is used for factory testing. This menu has a 60-second time-out setting. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 106 Displays the date and time the Control Panel software was compiled. Show Elapsed Run Time: Displays the Control Panel run time in hours, minutes, and seconds. This menu has a 60-second time-out setting. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 107: Hpsa-Mic (Optional)

    THE CABINET. CARE MUST BE TAKEN TO AVOID FEEDBACK. FEEDBACK MAY CAUSE DAMAGE TO THE UNIT. Internal Speaker switch Sub-panel speaker External Speaker switch Headphone jack Microphone FIGURE 7.15 HPSA-7100-R Microphone Sub-Panel (Optional) HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 108: Configuring The Control Panel Lcd Attributes

    Backlight screen appears. b. Press the Up or Down buttons below the screen to adjust the backlight setting. 4. When finished, press CANCEL to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 109: Run A Silent Test On Amplifiers

    FIGURE 7.16 Sub-Panel Speaker and Speaker Switch 6. On the keypad, press CANCEL to return to the main menu. 7. Announce a live message as described in Section 7.3.5. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 110: Test The Audio And Monitoring Bridge

    4. Reset the output on the external audio system. The audio on the HPSA-7100-R turns off. The Audio and Monitoring Bridge has six trouble outputs. Refer to Table 7.7 for the six trouble output states, jumpers and connections. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 111: Announce A Live Voice Test Message Using The Optional Hpsa-Mic

    1. Notify any personnel in the area that a test is upcoming and apply sufficient ear protection. 2. Ensure the Master Volume is reduce to avoid feedback. 3. Remove the microphone from its storage clip. 4. Press and hold down the Push-to-Talk (PTT) button. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 112: Figure 7.17 Local Microphone

    The announcement broadcasts through the speakers. 6. When finished, place the microphone back onto its storage clip. When replacing the microphone, slide it onto its storage clip until it clicks securely into place. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 113: Chapter 8 Using The Hpsa-7100-R

    1. From the HPSA-7100-R’s Control Panel, press the down arrow, select Adjust Volume and then press ENTER. The LCD screen changes to Setting HPSA Master Volume. 2. Perform the following until the volume is set as desired: HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 114 Limit. 9. When finished, press CANCEL from the Control Panel or Stop Alarm or Cancel Alarm from the sub-menu command buttons (the softkeys) to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 115: Stored Alarms/Tones On The Hpsa-7100-R Control Panel

    Several default Alarm Tones are built into the HPSA and can be played from the Control Panel. Additional tones and messages can be recorded, stored, and played from the WAVES Base Station. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 116: Playing Default Local Alarms

    Internal Speaker switch on the sub-panel. 7. On the keypad, press CANCEL to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 117: Play Live Voice Messages From The Hpsa-7100-R

    3. Remove the microphone from its storage clip. 4. Press and hold down the Push-to-Talk (PTT) button. THE HPSA-MIC IS NOT FEEDBACK PROTECTED. DO NOT USE THE HPSA-MIC IF FEEDBACK OCCURS. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 118: Stopping A Playing Alarm/Tone

    1. While an alarm/tone or message is playing, toggle and hold down the External Speaker switch on the microphone sub-panel. 2. When ready, release the switch. The alarm/tone resumes playing. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 119: Changing The Lcd Screen Attributes

    Press the Done button below the screen to return to the setup menu, or CANCEL to return to the main menu. 4. When finished, press CANCEL to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 120: Gathering Hpsa-7100-R Information

    Battery Voltage - Reports the battery voltage for the four connected lead- acid batteries. 3. When finished, do one of the following:  Press Back to return to the sub-menu.  Press CANCEL to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 121: Amplifier And Driver Status

    Refer to the table in Table 8.2, HPSA-7100-R Amp/Driver Settings and Configurations to determine which amplifier channels and drivers are used. Amps A5 through A8 and Drivers S5 through S8 are not used in the HPSA- 7100-R series. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 122: Table 8.2 Hpsa-7100-R Amp/Driver Settings And Configurations

    7108 2-11Ω 8 horns 3. When finished, do one of the following:  Press Back to return to the sub-menu.  Press CANCEL to return to the main menu. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 123: Chapter 9 Troubleshooting The Hpsa-7100-R

    The most common cause of trouble symptoms in the HPSA electronics is due to loss of AC Power and a resulting low (or no) Battery Backup Power. Initial troubleshooting should always begin with verifying the HPSA’s AC and Battery Backup Power status. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 124: Power Verification

    (+) voltage is not blown • If battery stack voltage is less than 48VDC, disconnect and test each battery individually for proper voltage (12VDC) • Replace batteries as necessary HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 125: Sub-Assembly Troubleshooting

    D10 (No AC LED) on the AMB will be OFF during normal operation and AMB: illuminated when the HPSA has an AC input. AC Voltage LED If the D10 LED is illuminated, refer to Section 9.2.4, HPSA PDB (A4) Test Points and Voltages. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 126 On the PMI, the following LEDs will be illuminated during normal operation. If they are not lit, call Eaton’s Cooper Notification Tech Support for assistance and Control Panel Assembly: further troubleshooting. PMI LEDs • D17 (3.3V LED) • D16 (5.5V LED) HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 127 Key the Mic to a test announcement. If no announcement is heard: Optional MIC • Follow steps outlined above in Low or No Amplifier Volume. • Replace (optional) MIC Assembly. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 128: Hpsa Components, Cabling And Wiring

    This section provides diagrams, cabling, and wiring information for the assemblies inside the HPSA Electronics cabinet. When Troubleshooting, refer to Table 9.2, “HPSA-7100-R Enclosure Wiring Chart” along with the appropriate Figures in the sections below. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 129: Hpsa Cabinet Diagram

    Optional PTT MIC Control Panel AMB shown with optional HPSA-7100-V- AC Power TB-6 Driver Power TB 1 - 4 Distribution Board (PDB) Batteries Amplifier Board FIGURE 9.1 HPSA-7100-R Cabinet Electronics and Batteries HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 130: Hpsa Electronics Cabinet Wiring Diagram

    Troubleshooting the HPSA-7100-R 9.2.2 HPSA Electronics Cabinet Wiring Diagram FIGURE 9.2 HPSA 7100-R Series Cabinet Wiring Diagram HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 131: Figure 9.3 Hpsa 7100-R Series Wiring Diagram - Left View Expanded

    HPSA Components, Cabling and Wiring FIGURE 9.3 HPSA 7100-R Series Wiring Diagram - Left View Expanded HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 132: Figure 9.4 Hpsa 7100-R Series Wiring Diagram - Right View Expanded

    Troubleshooting the HPSA-7100-R FIGURE 9.4 HPSA 7100-R Series Wiring Diagram - Right View Expanded HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 133: Hpsa Cable And Wiring Chart

    HPSA, along with their respective connection points. Refer to Figure 9.1 thru Figure 9.11 when troubleshooting. HPSA-7100-R Enclosure Wiring Chart TABLE 9.2 Note: Item 64 is the Fuse between the PDB and the Battery (+). HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 134: Hpsa Pdb (A4) Test Points And Voltages

    J2 Pins 1 and 2 (Gnd) +36 VDC From AC/DC Converter. Refer to Section 9.3 for a list and description of the LED Status and Trouble Indicators on the PDB. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 135: Amplifier Board (A3), Test Points And Voltages

    DC Supply Voltage J7Pins 1 and 2 (Gnd) 48 VAC Measure across each Chnl 1 Audio 42 mVAC speaker pair Measure across each Chnl 2 Audio 42 mVAC speaker pair HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 136: Control Panel Assembly (A9) And Pm1 Board (A9-A1)

    Control Panel Assembly (A9) and PM1 Board (A9-A1) 9.2.6.1 Control Panel Assembly (A9) FIGURE 9.7 Control Panel Assembly (A9), Bottom View 9.2.6.2 PM1 Board (A9-A1) FIGURE 9.8 Control Panel PM1 Board (A9 (A1)) HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 137: Hpsa Fan Assembly (A5)

    HPSA Components, Cabling and Wiring 9.2.7 HPSA Fan Assembly (A5) FIGURE 9.9 HPSA Fan Assembly Connections (A5) 9.2.8 Optional Microphone Assembly (A6) FIGURE 9.10 Optional MIC Assembly Connections (A6) HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 138: Pdb Led Status And Trouble Indicators

    Table 9.5, “PDB Status and Trouble LED Indicators” provides a description of the Status and Trouble LEDs located on the Power Distribution Board (PDB) shown below in Figure 9.11. FIGURE 9.11 PDB LED Status and Trouble Indicator Locations HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 139 4A, Stage 2 applies a constant voltage of Batt Charge 54.6 VDC. State • OFF: Stage 1 (constant I) • ON: Stage 2 (constant V) Batt Meas. Indicates the Battery Stack Voltage; no Batt detection. HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 140: Amb Led Status And Trouble Indicators

    On when Driver circuit is D16 Drivers Open or Shorted Open or Shorted * Verify the Jumper settings on the AMB match correctly with the No/NCJ2 input connections on J2 HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 141: Amp/Driver Settings And Configurations

    Settings and Configurations TABLE 9.7 Driver Number of HPSA Model # HPSA-7100-R Driver Status Configuration Drivers 7102 2-11Ω 2 horns 7104 2-11Ω 4 horns 7106 2-11Ω 6 horns 7108 2-11Ω 8 horns HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 142 Troubleshooting the HPSA-7100-R HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...

  • Page 143: Chapter 10 Hpsa-7100-R Maintenance

    • Upkeep of External Cables • Audio Test • Returning Equipment PERFORM ALL MAINTENANCE AS DIRECTED. FAILURE TO FOLLOW DIRECTIONS MAY RESULT IN BODILY INJURY AND/OR DAMAGE TO THE UNIT. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 144: Powering Off The Hpsa-7100-R

    From the lower left panel, push the red power button. The Control Panel, AMB and PDB board LEDs power down. Push the Red power button. FIGURE 10.1 Powering Down the HPSA-7100-R HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 145: Replacing Fuses

    6. Turn on the AC source or reconnect the AC connector mate to TB7 of the PDB. 7. Reconnect the DC power at the battery cabinet. 8. When finished, power up the unit as described in Section 7.1 and then close the cabinet door. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 146: Battery Maintenance

    HPSA-7100-R. For more information regarding battery thresholds, please refer to Section 1.4.3.5, Battery Charger Operations. Use the guidelines and procedures in this section to maintain the batteries. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 147: Checking The Battery Charge

    Connect AC power, power-up the HPSA-7100-R and allow AC to charge the batteries for several hours before rechecking the power range. If the battery cannot be recharged, replace it. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 148: Removing Batteries

    FOR INSTRUCTIONS. FAILURE TO FOLLOW INSTRUCTION MAY RESULT IN BODILY INJURY AND/OR DAMAGE TO THE UNIT. Refer to Section 6.2, Installing the Batteries for instructions on installing a new or replacing a battery. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 149: Cleaning Battery Terminals And Case

    Cooper Notification suggests a weekly audio test of all speaker units. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 150: Returning Equipment

    Support call 1-800-631-2148 option 3. 3. Package and return the equipment as directed by Customer Satisfaction. 4. Refer to the first page of this manual for recycling under the WEEE directive. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 151: Appendix A Nac And Sp40S Applications

     All connections between multiple HPSAs are in parallel.  Refer to Figure A.1, Figure A.2, Figure A.3 and Figure A.4 for Audio In, NAC In, Dry Contact Closure, and Trouble connector pin outs on the HPSA AMB. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 152: 25V Audio In Using Nac/Sounder Trouble Connections

    The configuration shown in Figure A.1 and Figure A.2 will result in a single HPSA Trouble being reported. The single trouble includes multiple HPSA Trouble circuits; the Operator will need to troubleshoot the HPSA to identify which specific Trouble circuit is causing the reported trouble. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 153: V/100V Audio In Using Nac/Sounder Trouble Connections

    The configuration shown in Figure A.1 and Figure A.2 will result in a single HPSA Trouble being reported. The single trouble includes multiple HPSA Trouble circuits; the Operator will need to troubleshoot the HPSA to identify which specific Trouble circuit is causing the reported trouble. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 154: 25V Audio In Using Closed Contact Trouble Connections

    External Source based on whether the input to the Source is Normally Open or Normally Closed. The configuration shown in Figure A.3 and Figure A.4 will result in each individual HPSA Trouble being reported to the External Source. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 155: V/100V Audio In Using Closed Contact Trouble Connections

    External Source based on whether the input to the Source is Normally Open or Normally Closed. The configuration shown in Figure A.3 and Figure A.4 will result in each individual HPSA Trouble being reported to the External Source. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 156: Multiple Hpsa-7100-Rsusing A Single Nac

    HPSA Trouble circuits. The Operator will need to troubleshoot the HPSA to identify the specific Trouble circuit is causing the reported trouble. FIGURE A.5 Connecting Multiple HPSA-7100-R AMB’s Using a Single NAC HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 157: Figure A.6 Multiple Hpsa-7100-Rs /Single Nac/Detail Hpsa #1 And #2

    Multiple HPSA-7100-R Using a Single NAC FIGURE A.6 Multiple HPSA-7100-Rs /Single NAC/Detail HPSA #1 and #2 *Refer to the Notes in Figure A.5 HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 158: Figure A.7 Multiple Hpsa-7100-Rs /Single Nac/Detail Hpsa #2 And #3

    FIGURE A.7 Multiple HPSA-7100-Rs /Single NAC/Detail HPSA #2 and #3 Refer to the Notes in Figure A.5 HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 159: Dedicated Sp40S With Multiple Hpsa-7100-Rs

    EOLR must be connected on the Audio In and Trouble Contacts on the furthest HPSA. When connecting to the HPSAs, break the wire runs at each terminal block on the HPSA, DO NOT loop the wire under the terminals. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 160: Multi-Use Sp40S With Multiple Hpsa-7100-Rs

    HPSA, DO NOT loop the wire under the terminals. Dedicated circuits are required on all audio, control and monitoring lines. Additional circuits from the SP4Z-A/B are available for in building (or other) applications. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 161: Combination Facp/Sp40S And Multiple Hpsa-7100-Rs

    For FACO operation, each monitored Trouble contact must have an EOLR across the terminals. Refer to the FACP manufacturer’s Instructions and the SP40S Installation, Testing, Operations and Maintenance Manual, P84714, for details regarding cable connections and pin outs. HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 162: Table 9.3 Table

    Open J12 2-3 C - NO 11 to 12 Open Closed Drivers J12 1-2 C - NC 11 to 12 Closed Open a. NO = Normally Open b. NC = Normally Closed HPSA-7100-R Series Installation and User Manual P/N P01-04946-C...

  • Page 163: Appendix B Omni-Directional Horn Array Pole Mount Heights

    Appendix B includes the following application note sections: • HPSA-7100-R Series Speaker Mounting Heights Figure B.1 shows the minimum pole mounting heights for HPSA-7100-R Series Omni-directional speakers based on the number of horn arrays in the system. The installer should take care to place the speaker arrays in a location based on height, near and far obstructions, acoustics, and all other conditions that might hinder or impede audio performance.

  • Page 164: Hpsa-7100-R Series Speaker Mounting Heights

    HPSA-7100-R SERIES SPEAKER MOUNTING HEIGHTS FIGURE B.1 HPSA-7100-R Omni-directional Pole Mount Speaker/Horn Minimum Height HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 165: Appendix C Driver/Speaker, Audio Input And Control Wire Gauge Distances

    CAB-SPKR-KIT be used during installation of the HPSA. It is strongly recommended that the distance of the cable length between the HPSA and each Drivers is limited to a maximum of 100 feet. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 166: Audio Input And Control Wiring

    LONG WIRE RUNS OR INSTALLATION IN AN INDUSTRIAL ENVIRONMENT SHOULD USE SHIELDED WIRE. IT IS RECOMMENDED THAT ALL AUDIO INPUT AND CONTROL APPLICATIONS USE SHIELDED, TWISTED PAIR CABLE, HOWEVER, THE 1 V AUDIO APPLICATIONS MUST USE SHIELDED WIRE. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 167: Vrms Audio Input And Control Wiring And Distances

    6,000 6,000 6,000 6,000 6,000 6,000 6,000 6,000 6,000 6,000 6,000 5,613 6,000 6,000 6,000 6,000 6,000 4,811 6,000 6,000 6,000 6,000 6,000 4,209 6,000 6,000 6,000 6,000 6,000 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 168: Vrms Audio Input And Control Wiring And Distances

    Number of Max distance (feet) from source to furthest HPSA HPSAs 1,378 2,185 3,496 5,484 6,000 1,093 1,748 2,742 4,370 1,165 1,828 2,913 1,371 2,185 1,097 1,748 1,457 1,249 1,093 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 169: Appendix D Hpsa-7100-V-Kit

    100 V External Audio Inputs will both connect from the J3 connector on the Interface Module to the J5 connector on the AMB. FIGURE D.1 AMB Board with Optional HPSA-7100-V-KIT HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 170: Amb Audio In Connections

    Module to the HPSA AMB. AMB Audio IN Connections TABLE D.1 Interface Module J3 (+) J5 1V AUD J3 (-) J5 AUD RTN FIGURE D.2 AMB J5 Audio Connection for 70.7/100 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 171: Optional 70.7/100 Vrms Interface Module Connections

    FIGURE D.3 AMB Plate Assembly Interface Module An End of Line resistor (EOLR), not shown, shall be connected across the Audio In and Audio Return connections on the furthest HPSA. HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...

  • Page 172: Amb Settings

    Line-In Voltage Voltage Volume (Nominal) Allowed Range (rated load) 70.7 V 33 V - 34 V 386 - 461 100 V 33 V - 34 V 388 - 458 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 173 HPSA Unit Volume Settings HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 174 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 175 LCD screen 128, 129 phone xxiii compartment 4 LID v1.1 menus 78 Horn Arrays installing 56 location 5 wind load 13 maintenance 120 Conventions xxii wiring to junction box 118 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 176 PDB 5 wind load 13 replaceable tubes 6 location 5 wiring horns to junction site design 11 PDB Charger Status 79 box 34, 118 Locally Stored Messages. See Play Alarms Status HPSA-7100-R Series Installation and User Manual P/N P01-04946 Rev C...
  • Page 177 AC on PDB 49 Test amplifiers 94 cooling fans 94 HPSA Amps 80 HPSA drivers 80 play local alarm 83 silent 83, 94 Time-out 4 Trouble Meanings 61 Uni-directional Horns 21 HPSA-7100-R Series Installation and User Manual P/N P01- 04946 Rev C...
  • Page 179 Cooper Notification 7246 16th Street East Suite 105 Sarasota, FL 34243 Tel.: 941.487.2300 Fax: 941.487.2387 www.coopernotification.com Notification Cooper Notification is...

This manual is also suitable for:

Hpsa-7102-rHpsa-7104-rHpsa-7106-rHpsa-7108-r

Table of Contents
