ARM-L-1512 / ARM-L-1524
Quick Installation Guide
Important Safety Instruction
General Safety Instructions
All electrical work must be done in accordance with local, and/or
international electrical codes.
Before installing or using this device, read all instructions and cautionary
marking located in (or on) this guide, the controller, the batteries,
PV(Photovoltaic) array and any other equipment used.
To reduce the risk of short-circuits, use insulated tools when installing or
working with the inverter, the controller, the batteries, or any DC source (e.g.,
PV, hydro or wind).
Remove all jewelry. This will greatly reduce the chance of accidental
exposure to live circuits.
The controller contains more than one live circuit (batteries and PV array,
wind or hydro). Power may be present at more than one source.
This product contains no user serviceable parts. Do not attempt to repair this
unit unless fully qualified.
Trademarks
DOS, Windows 95, 98, ME, NT, 2000, XP are registered trademarks of Microsoft
Corporation. All other trademarks belong to their respective proprietors.
Advertisement
Table of Contents
Summary of Contents for ARM Solar ARM-L-1512
- Page 1 ARM-L-1512 / ARM-L-1524 Quick Installation Guide Important Safety Instruction General Safety Instructions All electrical work must be done in accordance with local, and/or international electrical codes. Before installing or using this device, read all instructions and cautionary marking located in (or on) this guide, the controller, the batteries, PV(Photovoltaic) array and any other equipment used.
- Page 2 1. Installation Connect the system according to following instructions in sequence: Connect the Battery’s (-) terminal to the Battery’s (-) terminal of the Controller Connect the Battery’s (+) terminal to the Battery’s (+) terminal of the Controller Connect the PV (-) terminal to the PV (-) terminal of the Controller Connect the PV (+) terminal to the PV (+) terminal of the Controller Connect the Load (-) terminal to the load (-) terminal of the Controller Connect the Load (+) terminal to the load (+) terminal of the Controller...
- Page 3 2. Descriptions for the controller Light test button Pressing the light test button will activate the light (don't press the button for more then 10 sec). This button can only be used 5 times when the battery is below the LVD. Reset button Pressing the reset button for more then 10 sec will reset the system.
- Page 4 3. Use Solar Controller Utility: Run “Solar Controller Utility.exe” on a PC and you will see below user interface. Link PC: Connect a PC onto the PC terminal of the controller using a RJ45/RS232 cable. Click Link PC button on the user interface, then select your PC COM port or use ‘Auto Detect’...
