CFM Conference Mixer Product Manual
CFM Conference Mixer
Product manual
The information contained in this manual is subject to modify without notice.
Copyright © 2009-2010 All rights reserved by DigiSpider Inc. This publication contains
information that is protected by copyright.
"DS" , "Digispider", "Dspider" mentioned in this manual all refer to" DigiSpider Inc.
No part of it may be reproduced, transmitted, or translated any language without permission
from DigiSpider Inc. Trademarks as "DS", "Digispider", " Dspider" used in this manual are
registered by DigiSpider Inc.Trademark as "Intel" is registered by Intel Corporation;
Trademarks as "Microsoft", "MS-DOS", "Windows", "Windows 98", "Windows 2000",
"Windows XP" are registered by Microsoft Corporation;
Other trademarks and Names mentioned in this manual are belong to the corporation who
have registered the trademark or produced the product. DigiSpider Inc.has no patent right
for these products.
CFM Series
Mar. 2010
P/N:
Version: 1.0
1Copyright © 2009 Digispider. All rights reserved.
www.digispider.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFM Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DigiSpider CFM Series

  • Page 1 “DS” , “Digispider”, “Dspider” mentioned in this manual all refer to” DigiSpider Inc. No part of it may be reproduced, transmitted, or translated any language without permission from DigiSpider Inc. Trademarks as “DS”, “Digispider”, “ Dspider” used in this manual are registered by DigiSpider Inc.Trademark as “Intel” is registered by Intel Corporation;...
  • Page 2 CFM Conference Mixer Product Manual Thanks for your purchasing CFM conference mixer developed by our company. Human and high-tech essences are fused in our products. CFM series will give you one brand-new application experiences. Please follow the steps to protect your products, work area and personal safety, in order to avoid the potential danger of damage.
  • Page 3 If there are any revises, we will not give notice any more. If there is any revises in this manual, it will be promulgated in Digispider http://www.digispider.net Website: 3Copyright ©...
  • Page 4 Do not attempt to repair this equipment yourself. Refer all repairs to qualified service personnel. If there is any question, please contact the dealer you purchased CFM equipments from, you also can call Digispider customer service, ask for help. 4Copyright © 2009 Digispider. All rights reserved.

  • Page 5: Table Of Contents

    TECHNIQUE SPECIFICATION ..............29 1 ANALOG AUDIO INPUT SPECIFICATION.................29 2 ANALOG AUDIO OUT PUT SPECIFICATION..............29 3 INTERFACE SPECIFICATION....................29 4 OTHER SPECIFICATION......................29 CHAPTER 6 FAQS ........................30 CHAPTER 7 GLOSSARY ......................31 APPENDIX CFM SERIAL PORT CONTROL PROTOCOL..........33 5Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 6: About This Guide

    CFM Series Conference Mixer, by presenting the methods of installation, configuration, operations and maintenance. If you encounter any problem, or it is the first time for you to use Digispider’s CFM Series, please read this manual first for relevant information and technical supports. As for its upgrades and updates, some descriptions and illustrations in the manual may be different with your hardware.

  • Page 7: Announcement And Provisions

    CFM Conference Mixer Product Manual ANNOUNCEMENT AND PROVISIONS The manual prepared by Digispider Inc. does not provide any form of guarantee, clear or implied, including but not limited to, implied guarantees or a special-purpose commercial reasonableness. In some areas of specific transactions is a clear or implied guarantees, therefore, this statement may not apply to you.

  • Page 8: Cfm Synopsis

    Ethernet / RS232 Level control, Level control, Noise gate, Noise gate, Filter, EQ， Filter, EQ， SFC Mixer, SFC Mixer, priority control (duck), priority control (duck), Compressor/ Limiter Compressor/ Limiter Control software NSP-100 NSP-100 Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 9: Front And Rear Panel

    Take CFM1006 for example, the first two digits “10” means it has 10 mic/line input ports, and the latter two digits “06” means it has 6 mix output ports. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 10 Note: the pin 2 and pin 3 should not be connected to the pin1 when the 48V phantom power is open, otherwise the input port will be destroyed. 7—Earth GND Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 11 CFM-0800 front panel 1- Power LED Power LED red: normal power supply 2-Net LED Net LED green：Normal connection of CFM with internet 3- Status LED CFM status LED yellow: normal operating status 4- Model Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 12 The CobraNet interface also is a Ethernet interface for transmiting control data. The parimary port is active when both of the ports are connected. The secondary port will be a backup for the parimary port. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 13: Chapter 2 Cfm Operating Process

    NSP-100 software and can download them to the CFM hardware device. CFM-1006 device can be used independently separated from computer at the very moment of successfully downloading and confirming the DSP parameters. The stand alone system structure is as follows Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 14 Drag fader to complete adjustment, the detailed level value can be seen on the interface, also can be input a certain value into the interface directly for setting. Click to adjust the input level Input channel level adjustment interface Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 15 Priority “0”is the highest, “1”is medium, “2” is the lowest. And the detailed decreasing value can be set between -60~0dB when low priority user and high priority user meet together, also the recover time for low priority user can also be set. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 16 AutoSet Attenuation: set the auto adjust mode for the CFM-1006. In the auto mode, the user should open the all mic and speakers. The mixer will be adjusted automatic after the auto test for avoid the feedback. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 17: Cfm-0800

    Mic input ports. The process of signal working is as follows: One CFM-1006 can receive eight CobraNet signals from the network. So there are eight CFM-0800 can be connected to the CFM-1008 for expand. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 18 NSP-100 design Use the CFM-0800 for expand Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 19: Chapter 3 Basic Operation

    Startup CFM, and wait for CFM start to work in normal status with all LCD and indicator lights turn light. Step 3 Add the CFM into the software NSP-100 in a right way, please refer the NSP-100 user’s manual and CFM quick start guide. Step 4 Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 20: Expand Mode

    NSP-100 software user’s manual or CFM quick start guide. Step 3 According to the situation, adjust the I/O of microphone and mixer, and get into use. Please refer to the NSP-100 software user’s manual or CFM quick start. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 21: Network Mode

    NSP-100 software user’s manual or CFM quick start guide. Step 3 According to the situation, adjust the I/O of microphone and mixer, and get into use. Please refer to the NSP-100 software user’s manual or CFM quick start. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 22: Chapter 4 Nsp-100 Quick Start For Cfm

    Double click on the NSP-100 icon in the desktop. When the NSP-100 software is launched, a dialog box would display, requesting you to enter the password for the user. The initial password is “1” Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 23 Step3 Create a new project for the test system Click the “File-New” to create a new project. The main interface of NSP-100 when creating a new project. Menu Tool bar Device bar Layout area Status bar Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 24 Enter the serial number of CFM-1006 device and select the correct device type (the serial number is labeled on the rear panel of the CFM-1006 device). Click “OK” to add the configuration. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 25 The CFM-1006 is in the “CFM net device” User can drag the CFM-1006 from the device bar on the left of interface and add them to the document. Only one device can be added for one drag. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 26 Right click on the device, click the “Property” and select the right MAC for CFM device and then click “OK” After allocated the MAC address of the CobraNet device, the port of the device will be valid Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 27 The user could connect the network ports for the virtual connection. ， Step8 Compile After establishing Virtual connection. The user can click the button on the toolbar to download the existing active routing document to the corresponding CobraNet device. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 28 IN1 to IN10, you can open the gain adjustment dialogue window. There are total 10 ranks of different gains to choose, after a proper gain rank is selected, this detailed gain value will be indicated on the dialogue window in the software interface. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 29 4. DSP arithmetic： Noise gate, high-pass filter, low-pass filter and equalizer, all of these have icons and a bypass I/O. Click to adjust DSP DSP adjust interface Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 30 6. Mix enable: Green indicates Mix is open, red indicates close. Click to adjust mixer Click to control mix enable control matrix Mix control I/O and mixer position Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 31 AutoSet Attenuation: set the auto adjust mode for the CFM-1006. In the auto mode, the user should open the all mic and speakers. The mixer will prevent potential feedback be adjusted automatic after the auto test for problems For example: Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 32 Click to adjust C/L Fig.-C/L setting interface CFM-0800 control setting Double click CFM-0800 icon, to open CFM device control interface Click to adjust Mic gain CFM-0800 control interface Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 33 “solidify Attri..”, user can click it, wait until the below dialogue window pops-up, it means the confirmation is successful. CFM confirmation successful dialogue window The confirm operation will be failed if the DSP document has not saved before. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 34: Chapter 5 Technique Specification

    3 INTERFACE SPECIFICATION Two RJ45 network interface One RS232 interface (9-pin D-type) 4 OTHER SPECIFICATION Power supply:100-240V AC,frequency:40~60hz Power consumption: less than 30W Device dimension(L×W×H)：482×338×89（2u） ；482x296x44.5（1u） Surrounding temperature : +5-40°C Surrounding humidity: 5-85% Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 35: Chapter 6 Faqs

    1. Can the CFM remember its DSP parameters when restart the device? Yes, it can. The user can achieve this function by the confirm operation in the NSP-100 software. 2. Does Digispider Inc. recommend any specific Ethernet switches for CFM device? No, but you must use 100BaseT Ethernet switches.

  • Page 36: Chapter 7 Glossary

    A network that exists in the same building or group of buildings. CobraNet is a LAN technology. See also WAN. RS-232: A serial interface for connecting serial devices, offering a transmission distance of approximately 15 meters, typically using 9- pin or 25-pin D-sub connectors. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 37 A device is designed according to COBRANET technology to receive and transmit audio data. Channel type A classification of input and output audio signals, depending on its type, it can be divided into analog or digital channel. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...

  • Page 38: Appendix Cfm Serial Port Control Protocol

    Auto setting for mix open/release time *MIXDK x p aa.b# Mix DUCK level setting *GTSTA# Get channel ON/OFF status *INSTAxxy# Upload channel ON/OFF status *INITP# Initiate device DSP parameter *FIRMA# Firmware DSP parameter setting Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 39 （1） If no specified, return original sending command after execute correctly （2） return *ERRxx# indicate command has error, ，xx---is wrong code xx=00，no relative command can match with it xx=01 failed to verify xx=02 command failed to execute correctly Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 40 ：:phantom power：1-open，0-close aa（2 decimal character） ：gain increase gear,1-12 steps start from 1， 00~11 match with 0/6/12/18/24/30/36/42/48/54/60/66dB. There is no blank between in the character “xx”, “y”, “aa”, same as below. Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 41 ：8 output of mix，00 means setting all output channels. ii （2 decimal character） ：8 input of mix，00 means setting input channels p（1 decimal character） ：0 is positive， 1 is negative Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 42 ：00.0~60.0 10．*GTSTA# Function: all channels’ open status Instruction: Return *GTSTAxxxxxxxxxxxxxxxx# Return 10 local MIC and 8 NET input statuses. 0--- close，1---open， 2—open but DUCK1 (advanced priority MIC open) 3--- open but DUCK2 Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 43 First level(total three level 0/1/2) high -30DB，relatively high -20DB min DK level mix open value level -55DBFS Start time 20ms， release time 1s DUCK time mix enable close Matrix mixer gain All 0x20000000(0dB) Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
  • Page 44 SPK output level C/L parameter value 0db compress ratio =2.0 ， dynamic time 10ms release time 100ms BYPASS=1 Copyright © 2009 Digispider. All rights reserved. www.digispider.net...
