PARTS LIST
HUTCH
A
ADJUSTABLE SHELF
B
BASE ASSEMBLY *
C
* NOTE:
NOT INCLUDE IN THIS PACKAGE, YOU
HAVE TO PURCHASE MORGAN BOOKCASE
BOTTOM WITH LOT NUMBER 343-8932.
TOOL REQUIRED :
PHILIPS HEAD SCREW DRIVER
(NOT PROVIDED)
HARDWARE LIST
4
Ø 6X 1/2” PHILLIPS
1
FLAT HEAD
PCS
SCREWS
PREASSEMBLY :
READ ALL INSTRUCTIONS BEFORE USE OF THE BOOK CASE.
MAKE SURE YOU HAVE ALL THE PARTS INDICATED ABOVE BEFORE YOU BEGIN ASSEMBLING THIS ITEM, DO NOT
DISCARD ANY CONTENTS UNTIL AFTER ASSEMBLY IS COMPLETE TO AVOID ACCIDENTALLY DISCARDING SMALL
PARTS OF HARDWARE.
KEEP THE ASSEMBLY INSTRUCTION FOR FUTURE USE.
CUSTOMER CARE :
TO PRESERVE THE LUSTER AND BEAUTY, WE RECOMMEND CLEANING THE FURNITURE REGULARLY WITH A DAMP
CLOTH FOLLOWED BY A DRY CLOTH.
DO NOT USE WAXES OR CLEANERS (STRONG CHEMICALS).
1 pc
1 pc
2
MENDING PLATE
2
PCS
MORGAN BOOKCASE TOP
PRODUCT # : 343 - 8931
JC PENNEY - PLANO TEXAS 75024
THIS PRODUCT HAS BEEN TESTED AND COMPLIES WITH ASTM F2057-00
SHELF PIN
4
3
SUPPORT
PCS
A
B
C
1
4
PACK
FURNITURE
TIPPING
RESTRAINT
