2 Door 1 Drawer Sideboard
Assembly Instructions
041 xx 5521
- Please keep for future reference
Dimensions
Width - 66.8cm
Depth - 38.8cm
Height - 73.5cm
MADE IN
GREAT BRITAIN
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Rev C - 20/03/17
Advertisement
Summary of Contents for Norton TD466
- Page 1 2 Door 1 Drawer Sideboard Assembly Instructions 041 xx 5521 - Please keep for future reference Dimensions Width - 66.8cm Depth - 38.8cm Height - 73.5cm MADE IN GREAT BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 If you have damaged or missing panels, call the Components - Panels Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the panels listed below Important - Thick lines indicate finished edges 622xx7002 Left drawer side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View 9171 9173 5684 9175 0707 9174 0707 9172 8553 622xx7002 624xx7010 5671 0708 623xx7002... - Page 6 Assembly Instructions Step 1 Fitting cams to the shelf panels. Insert 4 metal cams into the shelf panel 9175 9175 Note: Ensure cam arrow points towards the edge with the hole. Step 2 Fitting cams to the bottom panel. Insert 4 metal cams into the bottom panel 9172 9172...
- Page 7 Assembly Instructions Step 5 Front of Runner Attaching runners to the end panels. Position the runner so that the second hole from the front of the 9173 runner lines up with the pre-drilled hole nearest to the edge of the panel. Back of Runner Use screws to secure...
- Page 8 Assembly Instructions Step 7 Correct Attach hinges and handles to the doors Incorrect Insert hinges into holes, ensure the hinge is straight (90 degree angle). 0707 Bradawl Before securing the hinges , we recommend you pre - mark the doors using a bradawl.
- Page 9 Assembly Instructions Step 8 Drawer images reduced in size for illustration Insert small cams Right hand side purposes. 622xx7002 into left 623xx7002 and right 623xx7002 drawer sides. Note: Ensure cam arrow points towards the edge with hole. Left hand side 622xx7002 Insert wooden dowels in drawer back...
- Page 10 Assembly Instructions : Insert 2 metal dowels into the the drawer 0708 fronts 0708 : Locate the metal dowels (already inserted) in the drawer front into the small cams in the left and right hand drawer sides. Ensure drawer sides are 623xx7002 pressed against drawer front.
- Page 11 Assembly Instructions Step 9 9174 Connect the right end panel to the shelf, bottom and plinth panel. Ensure plinth sits flush. Connect the dowels in the 9175 9174 right end panel the cams in the shelf 9175 panel , the bottom 9172 panel and the...
- Page 12 Assembly Instructions Step 12 Squaring up the unit. DIAG 2 DIAG 1 DIAG 3 IMPORTANT! Ensure a tape measure is used to square unit up. Before securing the back it is necessary to square up the unit. You can do this by measuring between XX - XX and YY - YY ensuring these are the...
- Page 13 Assembly Instructions Step 14 Hanging doors Diagram 1 With help, slot door hinges onto hinge plates. Ensure screw on hinge slides into the slot on hingeplate. Ensure the underside of screw See Diagrams 1, 2 and 3. B slides into slot on hingeplate. Diagram 2 Tighten screw shown 0707...
- Page 14 Assembly Instructions Step 15 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen or tighten screw as shown.
- Page 15 Assembly Instructions Step 16 Fitting the drawer. For this step we recommend you follow the helpful hints on the next page. 2nd Hole...
- Page 16 Assembly Instructions Step 17 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer in until the screwdriver pushes against the 2nd Hole panel.
- Page 17 Assembly Instructions Step 18 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
- Page 18 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
