Cypress PROC CY5672 Quick Start Manual

PR C BLE REMOTE CONTROL REFERENCE DESIGN KIT
TM
O
2
1
• Unpack the kit which includes: 1. PRoC
control, 2. CySmart USB dongle, 3. MiniProg3
TM
programmer/debugger, 4. 10-pin ribbon cable,
5. Two M2 X 5 mm screws, 6. Two AAA batteries,
7. Phillips head screwdriver, 8. USB 2.0 standard-A to
mini-B cable
• This guide explains how to evaluate the PRoC BLE
remote control using any PC
Two AAA Batteries
• Open the back cover, insert the AAA batteries and
move your finger on the trackpad of the PRoC BLE
remote control
• The blue LED, on dongle, glows to indicate successful
connection with the remote control
The PRoC BLE remote control features:
Y
Z
X
Note: The color of the actual product may differ from the color shown in images herein
CY5672 QUICK START GUIDE
4 5
3
6
7
8
1
BLE remote
TM
3
Bluetooth 4.1- compliant Bluetooth Smart connectivity
®
Trackpad with two- and one- nger gestures
Microphone to capture and stream voice data
Six-axis motion sensing
• Connect the CySmart USB dongle to a USB port on a PC
• The red LED glows to indicate that the dongle is
powered, the green LED glows to indicate that the
enumeration has finished on the dongle side and the
blue LED breathes slowly to indicate that dongle is
scanning for the remote control
Note: Time taken to complete enumeration on the PC,
for the first time, depends on the driver installation time
• Start using the PRoC BLE remote control with your PC
