RADIAL FLOATING SHELF
With Mirror Installation Instructions
Screws x 2
Bracket x 1
1.
Locate bracket at desired wall position and swrew in one screw. If screwing into a drywall,
you may need to use a dry wall (GIB) fixing.
2.
Level the bracket using a spirit level and screw in the second screw.
3.
Wind on the locator pins to the wall bracket.
Locator Pins x 3
Cam Lock Grip x 1
Shelf x 1
Mirror & Tape x 1
CITTADESIGN.COM
Advertisement
Table of Contents
Summary of Contents for Citta RADIAL FLOATING SHELF
- Page 1 RADIAL FLOATING SHELF With Mirror Installation Instructions Screws x 2 Locator Pins x 3 Cam Lock Grip x 1 Mirror & Tape x 1 Bracket x 1 Shelf x 1 Locate bracket at desired wall position and swrew in one screw. If screwing into a drywall, you may need to use a dry wall (GIB) fixing.
- Page 2 RADIAL FLOATING SHELF With Mirror Installation Instructions 4. Locate the shelf onto the wall bracket. Using a screwdriver insert the cam lock under the shelf and turn until you feel the cam lock grip the shelf to the wall. If cam lock does not grip...
