Your purchase of a Wolo warning light is the perfect choice to complement your vehicle. Wolo's warning lights
are manufactured with the finest materials. Before being packaged, each light is tested to meet our high
standards and ensure a perfect working light. Our quality workmanship and components are Wolo's assurance
that this product will provide years of dependable service. If you need help or have any questions using your
new Wolo warning light, our technicians are available to answer your questions, Monday thru Friday, from 9 AM
to 4 PM EST at 888-550-4676.
Before installation of the light bar is attempted, it is important to read the installation manual completely. The
lives of people are dependent on a proper installation of the light bar to the vehicle. The person installing
this light bar must have advanced knowledge of the proper method for mounting and securing a light bar to
a vehicle's roof or exterior, as well as knowledge of the vehicle's electrical system. Again, read this manual
completely and note any messages marked "IMPORTANT", "WARNING'' or "NOTICE". A safe installation will
prevent serious injury or damage to the vehicle.
LUMINOUS comes completely wired and does not require any internal wiring by the installer. The light bar
has two electrical cables exiting from the bottom of the light bar. The thinner cable has a factory installed
waterproof plug that will ensure a successful installation and years of dependable service.
Installation of the LUMINOUS Light Bar requires drilling into the vehicle's roof and interior. The installer must
carefully inspect both sides of the selected locations to ensure that there are no components, wires and/or any
other vehicle part that could be damaged by drilling. IMPORTANT: Always de-burr any drilled holes, ensuring that
there are no sharp edges. Install a rubber grommet into all metal holes that the wires are being routed through.
IMPORTANT: Always refer to the vehicle's shop manual for deployment location of the air bags. Never install
the light bar's switch control panel, wires and or components in the deployment area of any air bag. Improper
installation could reduce the effectiveness of the vehicle's air bag system and/or project an object that could
cause serious personal injury, or death to driver and passenger. The user/installer assumes all responsibility to
properly access a safe mounting location of the light bar's switch control panel, so to provide ultimate safety to
the driver and passengers inside the vehicle.
The vehicle operator and/or maintenance department should inspect the light bar frequently to ensure all
brackets and bolts are securely attached to the vehicle and that all mounting hardware is free of corrosion.
The light bar's switch control panel should be mounted in a location where the switches can be easily reached.
Never attempt to power the light bar on/off while driving under hazardous conditions.
These installation instructions should always be kept and stored in a safe location so that they can be referred
to when information, maintenance or reinstallation is required.
Failure to follow all safety precautions and installation procedures outlined in these instructions could result in
property damage to the vehicle, serious injury or death.
MOUNTING THE LIGHT BAR
There are two methods to safely mount the light bar to the vehicle's roof. The light bar can be mounted directly
to the vehicle's roof or a flat surface using the slide brackets, or using the provided stainless-steel straps that
will secure the light bar to the vehicle's windows ledge.
570 Series LED LIGHT BAR
LED LIGHT BAR INSTALLATION MANUAL
LUMINOUS™ 570 SERIES LED LIGHT BAR - PAGE 1
TM
Advertisement
Table of Contents
Summary of Contents for Wolo LUMINOUS 570 Series
- Page 1 LED LIGHT BAR INSTALLATION MANUAL Your purchase of a Wolo warning light is the perfect choice to complement your vehicle. Wolo’s warning lights are manufactured with the finest materials. Before being packaged, each light is tested to meet our high standards and ensure a perfect working light.
- Page 2 Fig. 1 MOUNT LIGHT BAR - DIRECT MOUNTING 1. The light bar has two adjustable slide mounting brackets that are designed to mount the light directly to a rack or a flat surface such as the vehicle’s roof without using the stainless- DIRECT steel straps.
- Page 3 MOUNT LIGHT BAR - STAINLESS-STEEL STRAPS Fig. 5 11. There are two mounting brackets on the bottom of the light bar, one on each end. Loosen the four nuts on one bracket and the bracket will freely slide, repeat procedure for the other bracket. Do not tighten the nuts until the brackets have been positioned with the stainless-steel straps.
- Page 4 Fig. 10 “L” Bracket and nuts provided. Insert the tension Tension Adjustment Bolt adjustment bolt through the strap’s “L” bracket and thread bolt into the light bar’s bracket, hand tighten. Strap IMPORTANT: The “L” bracket can be repositioned for proper installation by Tension Adjustment Bolt “L”...
- Page 5 If any electronic component parts, fuse or wire is replaced, they must meet or exceed Wolo’s specifications. Any deviation to the electrical specifications is at the installers/user’s risk. IMPORTANT: Disconnect the vehicles battery before beginning any wiring.
- Page 6 TRAFFIC ADVISORY PATTERN FRONT SPOT Fig. 16 MIDDLE OUT TO ENDS NUMBER TAKE DOWN FLASH FLASH PATTERN PATTERN RIGHT INDICATOR ALLEY L/A R/A LIGHT PATTERN POWER LUMINOUS ON / OFF ® WOL O ALLEY & TAKEDOWN LIGHTS WARNING LIGHT BRIGHTNESS LEFT WITHOUT WARNING LIGHTS PATTERN...
- Page 7 FLASH PATTERNS CW = Clockwise CCW = Counter Clockwise FUSE TABLE Use ATO or ATC Type fuse 12-VOLT 24-VOLT LENGTH OF 12-VOLT FUSE 24-VOLT FUSE FUSE AMPERAGE FUSE AMPERAGE LIGHT BAR AMPERAGE AMPERAGE 31 Inch 10-Amp 7.5-Amp 48 Inch 15-Amp 10-Amp 57 Inch 15-Amp...
- Page 8 If there is such a proven defect, Wolo, at its option, will either repair or replace the item free of charge, if it is returned to Wolo within twelve months from the date of purchase together with proof of purchase as described below.
