Summary of Contents for Fotodiox SkyFiller Series
- Page 1 . f o t o d i o x p r o . c o m SkyFiller SkyFiller Bi-Color LED Bi-Color LED Fotodiox Inc. 1100 Lakeside Dr Gurnee , IL60031, United States Toll Free:(866)812-1107 Local & International: (847)201-4623 Fax: (847) 261-0295...
- Page 2 DC Power cable (control box light unit)-1PC AC power cable -1PC 9.ONLY use the provided control box. Using other control boxes may result in damage to your light. Please contact techsupport@fotodiox.com should you need a replacement. Power control box-1PC 7 Remote control-1PC 8 Instruction manual -1PC 10.Avoid impact to the LCD screen;...
- Page 3 LED PORTABLE LIGHT LED PORTABLE LIGHT Parts Diagram: Power control box: Skyfiller SF50/SF70 Soft diffuser Power input cable Metal mouning plate (detachable) Stand mount locking screw Secondary locking screw Magic arm Magic arm knob A B C LCD screen Operation buttons AC power input socket 4pin DC input socket DC output socket (to light unit)
- Page 4 LED PORTABLE LIGHT LED PORTABLE LIGHT LCD display: Operating instructions 1.Set up instructions: (1) Align the four indication points on the metal mounting plate (A, B, C, D) with corresponding holes on the back of the light unit, rotate the connecting plate counterclockwise until you hear the “click”. The metal mounting plate is now secured on the light body.
- Page 5 LED PORTABLE LIGHT LED PORTABLE LIGHT (3) Turn the magic arm knob counterclockwise to loosen the magic arm, adjust the light to proper 3.Operating Instructions for operation buttons on remote control and power control box angle and turn the magic arm knob clockwise to secure in place. (1) Sound Button:Press once to turn sound on, press again to turn sound off.
- Page 6 (2) Press and hold the Pairing Button for more than 5 seconds, until buzzer sounds. (3) The light/lights are now paired with your remote control. Note: When pairing, all light units that are powered on will pair to a single remote control. The Sky Filler is backed by Fotodiox's 24 month limited warranty...
