- Page 1 BIFROST 240 LIQUID COOLING...
- Page 2 CPU for superior thermal transfer. The cooling block with precision carved with a micro-channel interior for improved cooling. Note: This manual is a guide for the BIFROST 240 liquid cooling. For instructions on installing the motherboard and other components, please refer to their documentation.
-
Page 3: Table Of Contents
- Cooling block installation - AMD AM2, AM3, AM4 - Connecting fans and cooling block LED to power Top / Front Panel Assembly - General Maintenance - Important Safety Information - Limited product warranty ("Limited Warranty") - Troubleshooting your new BIFROST 240 - Recommended parts... -
Page 4: Before You Begin
Before You Begin www.riotoro.com/watercooling... -
Page 5: Detailed View
BIFROST 240 LIQUID COOLING Detailed view 1. Two 120.0 mm Fans 2. 120.0 mm Radiator 3. Twin braided tubes 4. Mounting screw set 5. L-Shaped Connector 6. INTEL bracket 7. AMD bracket 8. Backplate Before You Begin... -
Page 6: What's In The Box
BIFROST 240 LIQUID COOLING WHAT’S IN THE BOX ITEM IMAGE DESCRIPTION AIO 240.0 mm Cool your CPU Radiator & Waterblock 120.0 mm black fan Airflow Backplate Secure cooling block INTEL Bracket Secure cooling block AMD Bracket Secure cooling block Thumb screws... -
Page 7: Precautions
BIFROST 240 LIQUID COOLING PRECAUTIONS Please take the following precautions: - Handle all PC components and cards with care. - Hold cards and processors by their edges to avoid damaging components. - To avoid damaging components by electrostatic discharge, periodically ground yourself by touching an unpainted metal surface or by using a wrist grounding strap. -
Page 8: Requirements
2. A magnetic Phillips screw driver This means you need to have the Phillips screw driver available in order to complete this assembly. Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support Before You Begin... -
Page 9: Ready, Setup, Go
Ready, Setup, Go www.riotoro.com/watercooling... -
Page 10: Specifications
BIFROST 240 LIQUID COOLING SPECIFICATIONS - Cooling Block Material: Copper - CPU Compatibility: - AMD: AM2, AM3, AM4, FM1, FM2 - Intel LGA: LGA: 1150, 1151, 1155, 1156, 1366, 2011, 2011-3, 2066 - Radiator Dimensions: 120.0 x 270.0 x 27.0 mm... -
Page 11: Backplate Installation
Note: The backplate provided in the box does not work with AM3 or AM4 processors, go to https://www.riotoro.com/contact to get a free backplate and bracket kit. Chapter 2... -
Page 12: Radiator Installation - Front, Top, Bottom, Back
LIQUID COOLING RADIATOR INSTALLATION – FRONT, TOP, BOTTOM, BACK BIFROST 240 is designed for quick installation, depending on the type of case you have, you may install the radiator on the front, top, bottom or back. Remove the front panel and filters... -
Page 13: Preparing The Cooling Block
BIFROST 240 LIQUID COOLING PREPARING THE COOLING BLOCK Depending on the type of CPU (INTEL or AMD) you need to install the specific bracket and backplate before installing the cooling block to the CPU. INTEL LGA: 1150, 1151, 1155, 1156,... -
Page 14: Cooling Block Installation - Intel
BIFROST 240 LIQUID COOLING COOLING BLOCK INSTALLATION - INTEL Use the provided screws to attach the cooling block to the motherboard. There is no need to apply thermal paste to the CPU as it is already pre-applied to the cooling block. -
Page 15: Cooling Block Installation - Amd Fm1, Fm2
BIFROST 240 LIQUID COOLING COOLING BLOCK INSTALLATION - AMD FM1, FM2 Use the provided screws to attach the cooling block to the motherboard. There is no need to apply thermal paste to the CPU as it is already pre-applied to the cooling block. -
Page 16: Cooling Block Installation - Amd Am2, Am3, Am4
BIFROST 240 LIQUID COOLING COOLING BLOCK INSTALLATION - AMD AM2, AM3, AM4 Use the provided screws to attach the cooling block to the motherboard. There is no need to apply thermal paste to the CPU as it is already pre-applied to the cooling block. -
Page 17: Connecting Fans And Cooling Block Led To Power
BIFROST 240 LIQUID COOLING CONNECTING FANS AND COOLING BLOCK LED TO POWER BIFROST 240 is designed for quick installation, simply connect the fans and the cooling block to the corresponding headers. To connect directly to the motherboard To connect directly to a fan hub, find a 4-pin... - Page 18 Everything Else...
-
Page 19: General Maintenance
BIFROST 240 LIQUID COOLING GENERAL MAINTENANCE If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip. -
Page 20: Important Safety Information
- Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hot-line or go to www.riotoro.com for support. Do not attempt to service or fix the device yourself at any time. -
Page 21: Limited Product Warranty ("Limited Warranty")
LIQUID COOLING LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase. -
Page 22: Troubleshooting Your New Bifrost 240
BIFROST 240 LIQUID COOLING TROUBLESHOOTING YOUR NEW BIFROST 240 Air flow options to configure the liquid cooling system: there two options, push and pull and they work as follows: 1. Airflow push: the air is pushed through the radiator and out of the case. -
Page 23: Recommended Parts
BIFROST 240 LIQUID COOLING RECOMMENDED PARTS P O W E R S U P P L Y U N I T BUILDER EDITION 500W & 600W: The Builder Edition combines 80 PLUS White certified energy efficiency with flat cables for reduced energy consumption, quiet operation, and easy installation. -
Page 24: Bifrost
BIFROST 240 LIQUID COOLING RECOMMENDED PARTS R G B F A N QUIET STROM: Quiet Storm RGB 120.0 mm fans will transform your case into a whisper-quiet, super-cooled RGB PC. The fans are illuminated by ten individually addressable RGB LEDs for dazzling multi-color effects, and are compatible with ASUS, Gigabyte, and MSI motherboards with 5-volt RGB connectors. - Page 25 BIFROST 240 LIQUID COOLING RECOMMENDED PARTS G A M I N G M I C E G A M I N G K E Y B O A R D AUROX: the Aurox Prism RGB gaming mouse combines an ergonomic exterior with an ultra-precise 10000 DPI optical sensor, 8 programmable buttons, aluminum scroll wheel, and customizable RGB lighting.
- Page 26 © 2019 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo, and BIFROST 240 are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.
- Page 27 www.riotoro.com...
