Mincey Marble SS-05 Installation Instructions

Installation Instructions for Mincey Marble Manufacturing's
DISCLAIMER
MATERIALS & TOOLS
INSTALLATION INSTRUCTIONS
Disclaimer Notice: If the prescribed method of installation is not followed precisely,
the accessories ledge may detach from the wall and cause damage to the panels and the
walls. If the ledge detaches, physical injury to the occupant of the shower may occur.
Mincey Marble will not be liable for any damages to persons or property because of incorrect installation.
These instructions have been written for Mincey Marble's SS-05 Cast Marble Wall Mount Accessories Ledge.
If you have a different product than shown, please call us for instructions for the product you have purchased.
In preparation, before installing these accessories ledges, you will need to have completed the installation of the
panel system and sealed the seams of the shower where the ledges are to be installed with 100% silicone.
MATERIALS & TOOLS REQUIRED:
1. Drill, preferable corded, for required drilling
2. 3/16" Masonry Drill Bit
3. Measuring Tape
4. Pencil
5. 100% Silicone for marble to marble seams (color matched to the marble)
6. Clean, dry cloth for the accessories ledge and the wall
7. #2 Phillips Head Screwdriver to tighten the screws when attaching the Standoff Mounting Tubes
8. 2 - WingIt MAW35-SD fasteners and 2 - Standoff Tubes (provided by Mincey Marble)
9. A 3/4" Masonry Bit, for drilling holes for MAW35-SD Master WingIt
, inc.
15" Wall Mount Accessories Ledge
Product Number: SS-05
Mincey Marble Mfg., Inc.
Elevation
15"
1 / "
1
2
Perspective
1940 New Harvest Road
Gainesville, GA 30507
Ph: 770.532.0451
www.minceymarble.com
Plan View
15"
3"
/ "
1
2
