DS-200 INSTALLATION GUIDE
Before You Begin
Read these instructions completely.
Note to Installer
Be sure to leave these instructions with the user.
Note to User
Keep these instructions for further reference.
SAFETY INSTRUCTIONS
The DS-200 Charge Station is designed with the safety concerns of the consumer as an utmost priority; however, the
following safety precautions must be read and followed:
•
The EVSE (Electric Vehicle Service Equipment) should be installed by a qualified electrician in accordance with local
electrical codes and ordinances.
•
Grounding Instructions - The charge station should be connected to a grounded, metal, permanent wiring system; or
an equipment-grounding conductor should be run with circuit conductors and connected to the grounding terminal on
the charger. Connections to the charge station should comply with all local codes and ordinances.
•
Call your local service provider anytime a procedural question arises; DO NOT attempt to perform a procedure you
are unsure of.
•
Read all installation instructions carefully before performing the installation
WARNING THIS MEANS DANGER. You are in a situation that could cause bodily injury. Before you work on
any electrical equipment, be aware of the hazards involved with electrical circuitry and standard
practices for preventing accidents.
INSTALLATION REQUIREMENTS
Inventory
•
Either Wall or Pedestal Mount DS-200 Charge Station
•
DS-200 User's Guide
•
DS-200 Installation Guide
Special Tools and Requirements
•
A manufacturer-approved pedestal for pedestal-mount charge station.
•
SAE wrench set or equivalent, Phillips head screwdriver, T-15 & T-27 Torx wrenches.
•
Each charge station requires a dedicated 208 / 240 VAC, 50/60 HZ, single-phase, 60 amp circuit.
•
Wire the EVSE to the breaker panel using wire sized according to local electrical codes.
•
The electrical junction box for a wall mounted charge station should be installed approximately 42 inches above
ground level.
•
The pedestal mounted charge station should have the pedestal mounted in place according to the siting instructions.
•
The charge station should be located to allow the charge cable to reach the vehicle's charge port.
Office: 530-823-8077 or 888-823-8077 Fax: 530-823-0857 Web: www.evii.com
Electric Vehicle Infrastructure, Inc.
11839 Industrial Court
Auburn, California 95603
Advertisement
Table of Contents
Summary of Contents for Evi DS-200
- Page 1 Note to User Keep these instructions for further reference. SAFETY INSTRUCTIONS The DS-200 Charge Station is designed with the safety concerns of the consumer as an utmost priority; however, the following safety precautions must be read and followed: • The EVSE (Electric Vehicle Service Equipment) should be installed by a qualified electrician in accordance with local electrical codes and ordinances.
- Page 2 2. Mount and secure the pedestal with four washers and nuts. Note Power conductors must reach at least 48 inches above ground-level to reach the DS-200. 3. Install the pedestal base cover using (4) #8-32 flat head Phillips head screws.
- Page 3 Install the pedestal cap using (2) ¼-20 button head screws with washers. Mount the DS-200 to the mounting plate and back cover using (4) 1/4-20 button head screws with washers. Remove (2) #8-32 button head screws with washers from the front door of the DS-200 enclosure and open the door.
- Page 4 WIRING WARNING: Be sure the EVSE circuit breaker is OFF at the service or distribution panel before attempting wiring of the DS-200. Refer to the DS-200 User’s Manual for instructions when connecting the Service Wiring.
