Assembly directions for the North Star 10,000 light box.

IMPORTANT: Make sure that the light box is unplugged
before assembling
1) Remove the two screws from end of unit and white
metal end strip.
2) Slide the plastic
diffuser cover out
and off.
Bulb installation directions – read before installing
3) Grasp the bulb with the thumb and middle fingers of
your left hand.
4) Align the 4-pins & the notch cut out in the light bulb
base, with the matching protrusion in the bulb
holder.
(800) 880-6953 www.alaskanorthernlights.com
3
4
2
Notch cut out
Pins
1
