Summary of Contents for April AD32LCDG80
- Page 1 AD32LCDG80...
-
Page 2: Table Of Contents
Safety Warnings................3 Accessories................. 3 Do / Don’t do................4 LCD TV Panel................5 LCD TV Panel(continued)............6 Remote control................7 Application instruction of remote control........8 Connecting to antenna or TV radio network........9 Connecting digital TV Set Top Box..........9 Picture............ -
Page 3: Safety Warnings
Safety Warnings The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated WARNING dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to RISK OF ELECTRIC SHOCK persons. -
Page 4: Do / Don't Do
Always power this product from an outlet with the same rating (voltage and frequency) as Indicated on the rating label in the back of the product. If this product has been damaged (including cord or plug) take it to an accredited service technician for inspection, and if necessary, repair. -
Page 5: Lcd Tv Panel
LCD TV Panel 1.Volume adjusting(+VOL-) 2.Channel selecting( 3.Main menu display and confirm for TV(MENU) 4.Selecting exterior signal input(SOURCE) 5.On/off button( ) 6.Remote sensor / Power indicator... -
Page 6: Lcd Tv Panel(Continued)
LCD TV Panel(continued) Y1 PB1 PR1 POWER ON/OFF AV OUT RF(75 S-VIDEO HDMI3 HDMI2 HDMI1 PC AUDIO VIDEO VIDEO VIDEO AV2 IN AV1 IN 1.High definition multi-media interface plug (HDMI1/HDMI2/HDMI3) 2.Input socket of simulation signal of PC (VGA) 3.PC Audio and DVI Audio input socket (PC AUDIO) 4.Component video signal input sockets ( Y 2/ PB2 / PR2) 5.Component video signal input sockets ( Y 1/ PB1 / PR1) 6.Audio and composite video signal input sockets (AV2 IN, R /L/VIDEO ) -
Page 7: Remote Control
Remote control Power button P.MODE S.MODE SLEEP Picture mode button Sleep button Sound mode button MTS/SAP function button Numeric button Return channel button Channel setup button Signal source selection button Main menu SOURCE MENU Selection confirm button RIGHT LEFT DOWN Aspect button Mute button INFO... -
Page 8: Application Instruction Of Remote Control
Application instruction of remote control POWER: Power on/off button; press once to turn the TV on and press again to turn the TV off. MTS: Multi-sound mode button. SLEEP: Scheduled power off time button, which allows the customer to set the TV power off time according to the preset times displayed. -
Page 9: Connecting To Antenna Or Tv Radio Network
Connecting to antenna or TV radio network In order to receive TV programs, signal should be received from one of the following signal sources: Outdoor antenna. Cable TV network. Satellite broadcast network 1.In these three cases, the input cable of antenna or The rear of the LCD TV TV network should be plugged in the 75 Ohm coaxial RF(75... -
Page 10: Picture
Picture 1.Press the MENU button to enter the Picture menu screen. (Fig.1-1) 2.Press the button to select Picture mode . Press the button to set the picture mode ( Normal, Soft, Vivid or User). MENU Fig.1-1) 3.Press the button to select Brightness . Press the button to adjust the value of brightness on the control bar.(Fig.1-2) -
Page 11: Sound
Sound 1.Press the MENU then the / button to enter the Sound menu screen.(Fig.2-1) 2.Press the button to select Sound mode . Press the button to set the sound mode ( Normal, News, Movie or User). MENU Fig.2-1) 3.Press the button to select Volume . -
Page 12: Function
Function 1.Press the MENU then the button to enter the Function menu screen. (Fig.3-1) 2.Press the button to select Language . Press the button to set the desired OSD language. 3.Press the button to select Blue Back(ground) . Press the button to set to On or Off on:blue screen... - Page 13 7.Press the button to select Hotel Lock . Switch Hotel mode "on", then the below items run. Change the setting by 8.Press the button to select Reset Press the button. All the settings resume to factory default value and it exit the setting screen automatically.
-
Page 14: Advance
Advance 1.Press the MENU then the button to enter the Advance menu screen. Fig. 5-1) 2.Press the button to select Scale . Press the button to set the proper display scale (16:9, 4:3). OSD Transparence OSD Transparence 3.Press the / button to select 3D NR . OSD Duration OSD Duration Press the... -
Page 15: Source
Note: This menu is available only when the SOURCE menu is set to PC . 1.Press the MENU button then the to enter PC menu screen. 2.Press the button to select H Position . Press the button to set the proper screen position in horizontal. -
Page 16: Connection To Exterior Devices
Y1 PB1 PR1 S-VIDEO VIDEO VIDEO AV2 IN AV1 IN Y1 PB1 PR1 POWER ON/OFF AV OUT RF(75 S-VIDEO HDMI3 HDMI2 HDMI1 PC AUDIO VIDEO VIDEO VIDEO AV2 IN AV1 IN Notes: 1. Y-Pb-Pr / AV/ S-Video use a common Audio (R1, L1). 2. -
Page 17: Trouble Shooting
sure you have set the AC power switch on and pressed power on/off button on the front panel. Check the TV/sound system setting.
