Replacement Battery Pack
BNB75R/BNB150R/BNB300R
Instruction Manual
This product is a replacement battery pack for BN75R, BN150R, and BN300R.
Safety precautions ....................................................................................... 1
1. Checking the contents ............................................................................. 2
2. Replacing the battery ............................................................................... 3
3. Notes of Chinese ..................................................................................... 7
Safety precautions
● The safety symbols and their meaning used in this manual are as follows:
Warning
Caution
: Indicates prohibition. For example,
: Indicates obligation. For example,
Note that events categorized as a caution required matter also may cause more serious results under cer-
tain conditions.
Table of Contents
Important information for safe operation is described.
Be sure to read it before installation and start of use.
Misuse may cause death or serious injury.
Misuse may cause injury or property damage.
* Property damage means damage to houses/household effects, livestock, and pets.
使用说明书
indicates that disassembly is prohibited.
indicates that grounding is necessary.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Omron BNB75R
Summary of Contents for Omron BNB75R
- Page 1 Replacement Battery Pack BNB75R/BNB150R/BNB300R Instruction Manual 使用说明书 This product is a replacement battery pack for BN75R, BN150R, and BN300R. Table of Contents Safety precautions ..................1 1. Checking the contents ................2 2. Replacing the battery ................3 3. Notes of Chinese ..................7 Safety precautions Important information for safe operation is described.
- Page 2 1. Checking the contents Check whether all the package contents are included and there is no damage found on their ap- pearance. If you should notice defects or anything wrong, contact us; OMRON Electronic Systems & Equipments Customer Support Center.
- Page 3 2. Replacing the battery The battery can be replaced while the UPS is stopped (power supply output stopped). Caution When the UPS is used in compliance with UL standards, battery replacement should be performed or supervised by personnel familiar with the danger of batteries and the required precautions.
- Page 4 <BN75R> Pull the battery connectors apart. ① Remove (turn counter-clockwise) the 2 screws that hold the battery cover in place. ② Slide the battery cover to the left and pull it towards your right side to remove it. ③ ③ ②...
- Page 5 Insert the new battery upright into the UPS as far as it will go. ● Replacement battery pack For BN75R: Model BNB75R For BN150R: Model BNB150R For BN300R: Model BNB300R BN75R...
- Page 6 Attach the battery cover. <BN75R> Insert the battery cover from the right side, slide it to the left to align the screw holes, and then fix the battery cover with the 2 removed screws. <BN150R and BN300R> Insert the battery cover from the top side, and slide it to the right to fit into the tabs on the side of the UPS. Fix the battery cover with the 2 removed screws. Be careful not to tighten the screws too much;...
- Page 7 3. Notes of Chinese 扩展电池模块使用说明书 本文是更换不间断电源 ( 以下简称 UPS) 内置电池模块时的使用说明书。 详细内容请参照英文版使用说明书 ( 以下简称“Instruction Manual”)。 更换电池 无论 UPS 处于停止运转 ( 停止输出电源 ) 状态、还是正在运转状态 ( 正在输出 电源 ) 均可执行电池更换。 ※ 在停止运转状态下更换时， 请停止连接设备的运转、 关闭 UPS 的“电源输出” 开关、并从电源插座上拔掉“AC 输入”插头。 ※ 在运转状态下的电池更换中发生停电等输入电源异常时，会导致无法进入后 备式运转而停止电源输出。 ※ 请勿在后备式运转中更换电池。否则会导致输出停止。 1.
- Page 8 ( 保管温度在 25℃以下时。40℃以下时为 2 个月左右。) ● 电池即使不使用也会在内部自然放电，长时间放置后会呈现过放电状态， 由此导致后备时间缩短、以致无法使用。 ● 电池在保管期间也会出现老化而导致使用寿命缩短的现象。 请尽快开始使用。 ● 请在购买电池后 6 个月以内开始使用。 安装于 UPS 进行保管时，请在保管前充电 8 小时以上，并在保管期间将 电源开关切换为“关”状态。保管时间超过 6 个月时，请在超时前重 新对 电池进行充电。 电池的充电时间请查看“Instruction Manual” 。 ● 若需要继续保管，则请在保管温度为 25℃以下和 40℃以下时分别以每 6 个 月和每 2 个月的间隔对电池重新进行充电。 欧姆龙自动化（中国）有限公司 URL ： http://www.fa.omron.com.cn K1L-D-13038B...
