Nano Backpack P5 (Nano-BP-P5)
Deployment Guide
Document Number:
009-1778-00
Document Date:
March 2019
Document Supports:
da Vinci 8.7 and higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nano Backpack P5 and is the answer not in the manual?

Questions and answers

Related Manuals for Artison Nano Backpack P5

Summary of Contents for Artison Nano Backpack P5

  • Page 1 Nano Backpack P5 (Nano-BP-P5) Deployment Guide Document Number: 009-1778-00 Document Date: March 2019 Document Supports: da Vinci 8.7 and higher...

  • Page 2: Table Of Contents

    Enable CEC ............................................26 ARC (Audio Return Channel) ....................................27 Bluetooth Pairing ..........................................30 Configure a Static IP Address ....................................31 DLNA ..............................................34 On Screen Display Pop-Up Info Banner ................................35 Appendix B: Network Requirements ....................................36 Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 3 WEIGHT INJURY! Installing some of the Savant equipment requires two 16. For any hardwired or fixed in-wall apparatus, carefully follow all wiring installers to ensure safe handling during installation. Failure to use two diagrams and instructions. All electrical wiring and servicing should be installers may result in injury. performed by a properly licensed electrician. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 4: Introduction

    1. Introduction This document will guide the installer/integrator through the process of installing, configuring, and adding the Nano Backpack P5 surround sound processor / amplifier. Before You Begin Read through this document in its entirety. Because the Backpack P5 can be installed into an existing Savant system or installed without adding to a Savant Control system, the devices are listed as such: Savant Control System running da Vinci release version 8.7 or higher (needed only if being installed into a Savant System) ........Artison Nano Backpack P5 (Nano-BP-P5) with remote ....................................Peripheral devices (TV, speakers, subwoofer, HDMI Source such as an Apple TV or BD Player) ....................(OPTIONAL) CMP-XL mounting bracket ..........................................Savant Development Environment (SDE/MacBook®) (needed only if being installed into a Savant System) ............... RacePoint Blueprint da Vinci 8.7 or higher Ethernet network meeting Savant requirements ......................................Appendix B: Network Requirements 2.

  • Page 5: Remote Basics

    CR2032 IMPORTANT! Dispose of the old battery into a proper recycling, hazardous waste, or designated battery drop off facility. Never 3 Volts discard the battery into the household trash. Pry out battery Install with Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 6: Button Descriptions - Remote

    Sets the surround mode for the input source selected. Each time the S MODE button is pressed, the mode is displayed in the Info Pop-Up Banner on the TV. (Available Modes: 2.1 Stereo, 5.1 Stereo, Dolby PLII Movie, Dolby PLII Music, DTS Neo: 6 Cinema, DTS Neo: 6 Music). Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 7: Install Backpack

    Mount Points Follow procedure on the next few pages to mount the Backpack to the breadboard and then mount the assembly to the rear of the TV. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 8: Mount Breadboard To Mounting Bracket

    M4 x 10 mm, washer and star lock nut VOLUME SOURCE DLNA HDMI 1 HDMI 2 HDMI 3 TV(ARC) OPTICAL CMP-XL mounting bracket CMP-XL 15 inch breadboard Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 9: Mount Backpack/Bracket Combo To Tv

    4.4. Mount Backpack/Bracket Combo to TV Mount the Backpack / CMP-XL combination to the rear of the flat panel TV. Insert screws through the slots in the CMP-XL mounting plate and into the VESA mounting points on rear of TV. Use one of the various sized screws supplied with the CMP-XL to mount to the TV. Do not tighten screws yet. The breadboard needs to be flexible for the next step. VESA Support Mount Points Post Rear View of Flat Panel TV Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 10: Install Breadboard Support Post

    These screws were installed in section 4.4 above. With Backpack secured to the rear of the TV, use the Connections section as a reference to make connections. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 11: Connections

    #14 AWG is recommended if wire length is longer than 50 feet but less than 100 feet. – #12 AWG is recommended if wire length is longer than 100 feet but less than 300 feet. – The HDMI output cable that connects to the TV should be kept as short as possible to reduce any radio wave interference. – Polarity (+/-) must be observed when making speaker connections. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 12: Adding Backpack To A Local Network

    Ethernet cable. Config Network With the IP Address set and the Backpack communicating on the local Reset All network, the next step is to update the firmware. For instructions on how BT Rename BackpackC502B9 to update firmware, go to the Update Firmware section. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 13: Add Backpack To Wi-Fi

    Backpack_C502B8 and log into Config Network IP Address 192.168.43.1 in a web browser Now Connect to SSID: Backpack_C502B8 and log into IP Address 192.168.43.1 in a web browser. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 14 Configure Manually will help to configure with a Hidden Network saving, enable the Static IP ON/OFF field. In the additional fields that open, SAVE enter the proper data. Once entered, SAVE the credentials. <Enter New IP ADDRESS of BACKPACK> Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 15: Update Firmware

    Web UI can be accessed. Continue to next page for MAC Address 005043721EFE information on uploading firmware using the Web UI. Module Status Connected Config Network Reset All BT Rename BackpackC502B9 Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 16: Upload Firmware To Backpack

    Add Backpack to Wi-Fi process will need to be re-run. FACTORY RESET IMPORTANT! The FACTORY RESET button in the Web UI has nothing to do with UPDATE the firmware upgrade, although the positioning of the button suggests it does. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 17: Blueprint Configuration

    Control Ports Assigned Inputs When complete, the connections in Blueprint will look somewhat like Outputs SpeakerInput HDMI (HDMI) the image to the right. 5.1 StandardWire (5.1 Sur Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 18: Add To A Zone And Make Connections (Ir Control)

    Since not all commands are supported, Savant recommends setting the system up to utilize IP Control as described in the Add a Zone and Make Connections (IP Control) section above. 3.5 mm stereo – IR receiver is included in the package contents. mini-jack Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 19: Blueprint - Upload Configuration

    Device Type IP Address OS Version Savant Unique ID Redundancy Sync themes Smith Residence Smith Residence Host 10.10.229.134 Edit UIDs 8.9.1 10DDB1C60190020 Standalone Pre-extract UIs 1 result Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 20: On Screen Display Descriptions

    LEFT/RIGHT arrow buttons on remote to increase or decrease (Default = 100) the level (Range: 0 - 100). Power On Settings - Sets default values for the input, volume level and audio mode. Once set, the Backpack will power on to the settings chosen. Main Menu General Input Power On Settings Volume Audio Mode Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 21 HDMI output port. This function is helpful when the speakers on the TV can’t be disabled. Main Menu • On (Default) - The audio of an A/V signal received on the input is transmitted out the HDMI output General port to a display.. HDMI Audio Out • Off - The audio of an A/V signal received on the input is NOT transmitted out the HDMI output port to a display... Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 22 Slope Subwoofer the speakers. Refer to the manual for the speakers installed for guidelines on where to set this. • Slope (Default = 12dB/Oct) - As a general rule, set most speakers to 12 dB/octave. The frequency vs gain curve drop is more gradual than when set to 24 dB/octave. Some subwoofers can be switched between 12 and 24 db/octave. In this scenario it is best to match the setting. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 23 (0 - 10 meters in .10 meter increments) Speaker Distance Front L Front R Adjust distance to Center each speaker. (feet / meters) Surround L Surround R Subwoofer Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 24 Use the UP/DOWN arrow buttons on the remote to change the character and use the LEFT/RIGHT arrows to move to the next character. Press OK on remote to save the changes HELPFUL! The last six digits which are the last six digits of the Mac Address of the wireless module cannot be modified. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 25 This however excludes the network settings. The network settings fields in- cludes a reset all function that resets the network modules. To reset, highlight the Factory Reset field and select the OK on the remote. The Backpack will reboot and the factory settings will be restored. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 26: Appendix A: Additional Functionality

    CEC is now supported on the Backpack. CEC Setting CEC Enable Enable TIP! If Device Discovery is not a function of the TV Menu, hot plugging CEC Power On Enable the HDMI cable may be required to rediscover the CEC connection CEC Power O Enable on the TV. Enable CEC Volume Enable CEC Source Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 27: Arc (Audio Return Channel)

    Enable process and locate all the CEC supported devices and add them to its list. Enable CEC Volume With the process complete, the video from the blu ray player will play on the Enable CEC Source TV and the audio from the blu ray player will play to the speakers (through the Backpack). Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 28 Backpack_<Last Six Digits of Mac Address to the Wireless Module>. Refer to the image to the right. Wi-Fi: Looking for Networks Turn Wi-Fi O Backpack_C502B8 Smith WiFi Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 29 14. Verify through the on-screen display that the correct firmware version was loaded. (Main menu > Preferences > Firmware Version). UPGRADE DEVICE SETUP FIRMWARE UPGRADE Please select the file for upgrade CHOOSE FILE 83_IMAGE_NETWORK_LS98204_11_1051051_110_100 FACTORY RESET UPDATE Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 30: Bluetooth Pairing

    Locate and select the Backpack from the list. At this point, Backpack will MY DEVICES connect to your device. Note that the connection process can sometimes take Charge 2 Not Connected up to 20 seconds to negotiate. Anker Soundcore Not Connected UE Roll Not Connected OTHER DEVICES BackpackC502B9 Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 31: Configure A Static Ip Address

    Setup your Backpack to join your network of choice. Static IP ON will help to configure with a Static IP address. Configure Manually will help to configure with Hidden Network SAVE Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 32 HELPFUL! The Backpack will display in wireless utility like below: Backpack_<Last Six Digits of Mac Address to the Wireless Module>. Backpack_C502B8 Refer to the image to the right. Smith WiFi Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 33 Setup your Backpack to join your network of choice. Static IP ON will help to configure with Static IP address. Configure Manually will help to configure with a Hidden Network SAVE Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 34: Dlna

    The name will apppear as the product name in the DLNA Player. the DLNA Player. APPLY APPLY The Backpack broadcasts the DLNA as: Backpack<last six characters of Bluetooth wireless module Mac Address>. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 35: On Screen Display Pop-Up Info Banner

    When the incoming signal is Multichannel PCM, Dolby Digital, or DTS, the surround mode is disabled and will be passed through the Backpack. – When the incoming audio is 2 channel audio, the surround mode can be modified. If incoming audio is anything else (Dolby Digital, DTS, or Multi-Channel pcm audio), the surround mode can’t be modified. Supported surround modes: 2.1 Stereo, 5.1 Stereo, Dolby PLII Movie, Dolby PLII Music, DTS Neo: 6 Cinema, DTS Neo: 6 Music – Brackets ( ..) indicate the input signal is 2 channel/stereo pcm. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...

  • Page 36: Appendix B: Network Requirements

    Using the Backpack remote, scroll to and select Network Setup field. Scroll down and highlight the Reset All field. Select OK. Backpack will reboot and network settings will be restored to defaults. IMPORTANT! To ensure the IP Address does not change due to a power outage or similar, a static IP Address or DHCP reservation should be configured. Savant recommends using DHCP reservation within the router. Setting DHCP reservation varies from router to router. Refer to the documentation for the router when configuring DHCP reservation. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
  • Page 37 AirPlay, Apple, AirPort Express, AirPort Extreme, Apple TV, Apple Remote Desktop, FireWire, iMac, iTunes, iPad, iPad mini, iPad Air, iPhone, MacBook, Mac and OS X are trademarks or trade names of Apple Inc. iOS is a trademark of Cisco®. Android, Google, Google Play, and other Google marks are trademarks of Google, Inc. Wi-Fi is a registered trademark of the Wi-Fi Alliance®. HDMI® is a trademark of HDMI Licensing, LLC. MOTU® is a registered trademark of Mark of the Unicorn, Inc. Luxul is a registered trademark of Luxul Wireless. NETGEAR®, the NETGEAR Logo and ProSAFE are trademarks of NETGEAR, Inc. Extreme™ is a trademark of Extreme Networks, Inc. All other brand names, product names, and trademarks are the property of their respective owners. Technical and Sales Support Savant Systems, LLC is dedicated to providing prompt and effective support in a timely and efficient manner. – To contact Savant Support, access the Savant Customer Community and enter a support Case ticket. – To contact Savant Sales, visit Savant.com and select Contact Us to locate a local sales representative in your area. Nano Backpack P5 Deployment Guide Copyright © 2019 Savant Systems, LLC 009-1778-00 | 190327...
