Dynalink X2810 Installation Instructions

X2810
Electronic OPEN / CLOSED Sign
with Remote Control
Installation Instructions

IN THE BOX

• Sign panel
• Remote control
• 5V Power adaptor
• Chain for hanging sign

STEPS

1. Install chain on both sides of two top rings first.
2. Hang on a 10kg minimum weight suction-cup hook or similar fixing method to hold the OPEN/CLOSED sign at the entrance to your premises.
3. Plug in 5V power plug and switch power on.
4. Follow the guidelines as below.

GUIDELINES FOR OPERATION:

There are four modes of operation:
1. OPEN STATIC
2. OPEN FLASHING
3. CLOSED STATIC
4. CLOSED FLASHING.
If you want to...
Switch on the panel
Switch off the panel
Flash the word
Static the word
Display OPEN
Display CLOSED
Note: The operation of the remote control takes precedence and overrides the operation of the panel switches. With the FLASH switch to ON position,
the remote control can be used to change to static operation by pressing the STATIC button. With the MODE switch to ON position, the sign will display
OPEN, but the remote control can be used to change the sign to read CLOSED. However, if the main POWER switch on the rear panel is off, then the
unit will not function and the remote control cannot switch it on.
Program the operating mode by switches on
rear of the panel, press:
POWER to ON position
POWER to OFF position
FLASH to ON position
FLASH to OFF position
MODE to ON position
MODE to OFF position
Program the operating mode by remote
control, press:
ON/OFF
ON/OFF
FLASH
STATIC
OPEN
CLOSED
