ABITRON CS TRT-1-1 Series Technical Documentation Manual

Rf transceiver transmitter with feedback function
Hide thumbs
Table of Contents

Advertisement

Quick Links

Documentation
RF Transceiver Transmitter
Version
Datum
1.00
25.03.2015
1.00
15.04.2015
1.00
05.05.2015
1.00
22.06.2015
1.00
06.10.2015
1.00
16.11.2015
1.00
17.11.2015
1.00
21.01.2016
1.00
19.05.2016
1.00
04.11.2016
1.00
15.03.2017
1.00
11.04.2017
1.00
25.07.2019
1.00
03.12.2019
Technical
CSxxxTRT-1-1
with Feedback Function
KH62400061.A, K500267 &
KH66983xxx61.A, K750172
Name
Kommentar
ORD
CS447 hinzugefügt; 04.5 und 09 nachgearbeitet
ORD
10 Fertigung aktualisiert; CS335 hinzugefügt
FRM
9:Firmwareversionen STD302N-R & 04.5.2 geändert
FRM
9:Firmwareversionen STD302N-R (335, 429 &447)
geändert
FRM
04.5.x: FCC & IC Zulassungsnummern hinzugefügt
09.1: SW1 geändert
FRM
04.5.3: Frequenz Kanal 20&21 getauscht.
FRM
04.5.3: Frequenz & Kanäle 20 & 21 angepasst.
04.5.10: Gruppe 5-8 geändert.
FRM
04.5.1: Frequenzliste geändert
KÖM
Generelle Überarbeitung
KÖM
Überarbeitung im Zug der Umstellung auf STD-302-S
KÖM
10.1.1: Zusatzinfo für Verguss ergänzt
KÖM
04.5 und 05.4: Zulassungen aktualisiert
MK
04.5.11 CS456 hinzugefügt;
KL
Integration Instructions
ABITRON Control Systems GmbH
© by ABITRON Control Systems GmbH
Wiesnerstraße 20
A-4950 Altheim

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS TRT-1-1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ABITRON CS TRT-1-1 Series

  • Page 1 Überarbeitung im Zug der Umstellung auf STD-302-S 1.00 15.03.2017 KÖM 10.1.1: Zusatzinfo für Verguss ergänzt 1.00 11.04.2017 KÖM 04.5 und 05.4: Zulassungen aktualisiert 1.00 25.07.2019 04.5.11 CS456 hinzugefügt; 1.00 03.12.2019 Integration Instructions ABITRON Control Systems GmbH Wiesnerstraße 20 A-4950 Altheim © by ABITRON Control Systems GmbH...
  • Page 2 01 Description The CSxxxTRT-1-1 RF part is a transceiver with multiple functions: 1. Transmitting or Receiving (simplex or halfduplex) 2. “Feedback Master” or “-Slave” for 3 LED-Feedback (halfduplex). The functions are selectable by SIP-Switch for frequency allocations and solder jumper to select Transmitter/Receiver, FB-Master or FB-Slave.

  • Page 3: Block Diagram

    02 Block Diagram HF Transceiver Sender CSxxxTRT-1-1 erstellt: geändert: mit Rückmelde-Funktion Name: 02.02.2015 25.07.2019 Art.-Nr.: KH66983xxx61.A Seite 3 von 9 Datum:...

  • Page 4: Technical Data

    03 Technical Data Supply voltage: 3,4-12 VDC (recommended 3.4-5VDC) Current consumption: <50 mA TTL Data (Open drain with 4.7K pull up) DK-Sync (Open drain with 4.7K pull up) Outputs: Telegram-Off (Open drain with 10K pull up) 3xIO, LEDs can be connected directly Antenna (use 50 Ohm antenna) 3xIO can be used as Inputs, Level 0 / 5V (higher values possible with additional series resistor).
  • Page 5 04 Connection 04.1 Standard Connection 04.2 Modes 04.2.1 Connection as Transmitter or Receiver 0V/GND offen/open/High J1, J2 & J3 = open J1, J2 & J3 = open CSxxxTRT-1 as transmitter CSxxxTRT-1 as Receiver To change the frequency via a button connected to the decrement input of the TRT module, press this button for at least 2 seconds! HF Transceiver Sender CSxxxTRT-1-1 erstellt:...
  • Page 6 04.2.2 Connection as Feedback Master (Control Side) Set the coder Baudrate to 4800 if the TRT is used as feedback master or slave! = closed J2 & J3 = open 04.2.3 Connection as Feedback Slave (Machine Side) J1 & J2 = closed = open HF Transceiver Sender CSxxxTRT-1-1 erstellt:...

  • Page 7: Jumper Setting

    04.3 Jumper Setting Function Open Open Open Normal Closed Open Open FB-Master Closed Closed Open FB-Slave Standard Setting = grey background J3 = reserved Close J1, J2 & J3 for Test mode. 04.4 Application Note 04.4.1 FCC/IC If the used RF part has a FCC/IC certification the certification number has to be written on the outside of the device.

  • Page 8: Manual Setting

    04.5.11 CS456TRT-1 Firmware-Version: CS456TRT-1K2_190723 Manual Setting Automatic Setting S1=0 S1=1 Mode Freq. (MHz) -No. Invalid – don´t use 456,300 TX: AUTX („Auto Channel Change“) 456,325 RX: Scan-Mode TX: FCS („Free Channel Search“) 456,350 RX: Scan-Mode 456,400 Invalid – don´t use ** 456,450 456,500 456,725...
  • Page 9 05 Integration instructions for host product manufacturers according to KDB 996369 D03 OEM Manual v01 2.2 List of applicable FCC rules Part 90 2.3 Specific operational use conditions This module is approved for use in portable and mobile applications. Integrators must supply operating instructions for end users and installers to satisfy RF exposure compliance requirements are met.
  • Page 10 2.8 Label and compliance information The 456TR1 module is labelled with its own FCC ID. If the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a physical label or eLabel referring to the enclosed module.
