Summary of Contents for Rassbach Communications FreedomLINK
- Page 1 Mobile Radio Installation Instructions...
- Page 2 Tools needed: Drill, 5/16”-screw bit, Phillips screw bit, crescent wrench, 3/4” hole saw, socket set, trim removal tools, wire puller Mount radio bracket on a solid, steady surface Use suppled screws or bolts and nuts Mount the mic clip on a solid, steady surface that is easily accessible for the user Secure with supplied screws...
- Page 3 Attach positive (red) and negative (black) wires to a constant 12 volts and properly cleaned ground If an ignition kit is used, attach it to a known 12-volt ignition point Drill a ¾” hole in the center of the roof Clean paint off the edge of the hole for proper grounding November 8, 2018...
- Page 4 Install coax though the ¾” hole. Leave some slack for future service. Assemble O-ring and brass ring onto the large antenna base. Tighten with a crescent wrench. Attach antenna to the roof mount and snug with a crescent wrench November 8, 2018...
- Page 5 Notes: - If using a gain antenna make sure it is cut to your frequency. - Coax connectors require the proper install tools for the correct installation. If you would like to purchase the tools please contact us. - There is also a tool to cut and remove the antenna hole and paint.
