A.N.T. Audio Amber 3T User Manual

A.N.T. Audio "Amber 3T" headphone amplifier
Building upon the success of the award-winning A.N.T. Audio Kora 3T phono stage,
new Amber 3T headphone amplifier uses the same FET-only, class A, single-ended
philosophy. Suitable to use with headphones from 25 to 300 Ohm impedance and a
variety of line-level sources, the Amber 3T provides an excellent sound quality in a
small package. Two versions of the headphone amplifier are available:
The Classic
(Green
FM series for output and power supply capacitors and comes with a switch-mode
univoltage power supply.
The Special Edition
Velvet volume potentiometer, user adjustable FET biasing, upgraded ELNA Starget
output capacitors and comes with a switch-mode univoltage power supply.
The Special Edition Plus
comes with a high quality linear power supply.

Specifications:

Input Impedance
Maximum Gain
Frequency Range (100 Ohm load, -1 dB)
THD @ 1 kHz , 1V RMS output into 100
Ohm load (10 mW)
Max. output @ 3% THD (sinewave 20
Hz- 20 kHz), each channel
Output impedance @ 1 kHz
S/N ratio, A-wtd, at 1V RMS output
Supply current
Supply voltage
Case
Printed Circuit Board (PCB)
Environmental
LED) employs high quality components, including Panasonic
(Amber LED) , on the other hand, sports 27 mm Alps Blue
(Amber LED) is the same as the Special Edition, but
20 kOhm
20 dB
Better than 20 Hz – 20 kHz
Less than 0.5%, mostly second harmonic
More than 2.5 V RMS into 100 Ohm load
(more than 62.5 mW each channel)
Less than 10 Ohm
Better than 90 dB
Less than 250 mA
24 V DC ±10%
Anodised Aluminium Alloy
Double-Sided Silver-Plated
Lead-Free Technology
