CONTROL/BLUETOOTH RECEIVER/STEREO FM TUNER – PCP1273
1 – Volume increase pushbutton. 2 – Volume decrease
pushbutton 3 – SCAN pushbutton. 4 - Tuner/Music/
BLUETOOTH channel change pushbutton. 5 - Tuner/
Music/BLUETOOTH
6 – ON / SLEEP luminous indicator.
SLEEP pushbutton. 8 – Jumper for selection of mono
output.

DESCRIPTION

FM stereo control / tuner, with 1 stereo channel and message receipt.
Infrared receiver, controlled by P4803 or P4804 remote control (optional).
Permits storing up to 30 stations with functions: message receipt, super-
bass, sleep, adjustment of bass, treble, balance and ideal sound.

GENERAL CHARACTERISTICS

-
Electronic ON / OFF switch.
-
ON /Sleep/ Sb luminous indicator, bicolour LED type.
-
Key depression luminous indication (Vol+, Vol- and SCAN)
-
52-step digital volume control with selected position memory.
Integrated audio processor.
-
Superbass.
-
SCAN function (change radio station of tuner or external device)
-
Selection of external music channel, internal tuner or BLUETOOTH
receiver, with light indicating selected audio source.
-
Voltage telecontrol.
-
External channel input (walkman).
-
Direct access to stations via control P4804.
-
Jumper for selection of mono output. For this type of installations
place the jumper M/S (10).

DIRECT ACCESS FUNCTIONS ON CONTROL PCP1273

With control on, we press key (4) to change channel (Main Unit/Tuner/
BLUETOOTH) until the LED indicator (5) lights up in Red, (FM).

STATION STORING AND DELETING:

1 - AUTOSEARCH AND AUTOMATIC STATIONS STORING M1 TO
M30:
If you wish to store all the available mamories automatically, then
(IN OFF MODE):
Keep Scan key (9) pressed for several seconds
(with max. Sensibility preset)
The number of stored stations will depend on the reception
level of the installation
2 - SEARCH AND STORE OF STATIONS MANUALLY
If you wish to stere stations one by one, then
Keep channel key (8) until the LED ON is switched off, then
press key (1) Vol+ to store in the following free memory.
channel
luminous
indicator.
7 – ON / OFF /
(IN ON MODE):

3 MEMORY ERASING:

(IN ON AND TUNER MODE)
Long press of channel/tuner key (8) until led on (6) turns off,
secondly press key Vol+ (1) to store in the following
free memory.

WORKING IN ON AND TUNER MODE:

1 - MEMORY SCAN:
With a short press on scan key (9), only the memories previously stored
will be selected. The led (6) will flash once.
2 - AUTOMATIC STATION SEARCH BY FREQUENCY SCAN:
With a long press of scan key (9), the tuner will continue on the dial until
a station is detected. The led ON (6) will turn off until the scan is finished.

BLUETOOTH FUNCTIONS

When the control is switched on, LED (6) will light up in red and LED (5)
in blue; a noise will be heard in the speakers telling us that the control
has been activated and the BLUETOOTH visible. The control will then
go to the same position it was in when last turned off: Main Unit, Tuner
or Bluetooth.
Activate the BLUETOOTH on the device (telephone, tablet, laptop, etc.),
and search for new devices. The name, SONELCO, must appear. If the
device asks us for a password, enter code 1234.
Once the connection has been established, we can send all the audio
from our device to control PCP1273.
Every time we switch off the unit, the Bluetooth will disconnect.
SONELCO has an APP for mobile devices (Telephone, Tablet, iPad,...)
from which we can control all the parameters of control PCP1273. Change
channel, increase and decrease volume, memorise stations, frequency
and memory scan, access our music and even music on the Internet (You-
tube, Spotify,...).
When you quit the app, the control will be decoupled.
