Summary of Contents for JTZ Zacuto Kameleon EVF
-
Page 2: Packing List
Packing List Zacuto Viewfinder Kameleon EVF x1 Eyecup x1 16GB USB Drive Zacuto Patented Manual x1 Anti-Fog Discs x1... - Page 3 Physical Specs 70mm 125mm Dimension: 125mm x 70mm x 72 mm Weight: 440g Power input: 7-20v Power consumption: 5w Power input port: LEMO -0B 4pin Input connector: HDMIx1, SDIx1, USB-Cx1 HDMI input: 4K CDI, 4K, 1080P, 1080i, 720P, 720i, etc. SDI input: 3G SDI, 1080P, 1080i, 720P, 720i, etc.
- Page 4 Physical Specs Joystick Menu Power Indicator Diopter Ring 5/8 Screw Teeth Bits Removable 1/4 Screw Eyecup...
- Page 5 Physical Specs HDMI Input USB-C Input SDI Input DC Input Air Vents...
-
Page 6: Menu Function
Menu Function Function 1 Activate / Exit menu Function 4 Function 2 Function 3 Press the joystick to activate the menu. Press the joystick again to exit the menu. With the menu active, press the right direction to advance the menu to the 2nd level and to select a menu feature. - Page 7 Menu Resolution Second-level menu First-level menu Preview icon Firmware version number...
- Page 8 Menu Most cameras and EVFs only provide a single screen size in which to display the image. The Kameleon provides multiple magnification sizes which the user can choose from. Menu size and position will not scale or change.
-
Page 9: Connecting To A Power Source
Connecting to a power source Connect your Four Pin Lemo to the jack on the bottom of the Kameleon. Align the red dot of the EVF, making sure it’s securely in place. Four Pin Power & Video Cable Lemo (Sold seperately) P-Tap Connect the P-Tap on the opposite end of the power... - Page 10 Opening The Eyecup Lens Door, Hands Free Position your head next to the lens door tab. Apply pressure with your head to the lens door tab, slide your head from left to right opening the door. Opening Eyecup to keep Lens Door open The Eyecup can be folded over on itself so that the lens door remains open.
- Page 11 Removing & Installing Level 1 Fog Protection Level 1 Fog Protection Anti-Fog Coated Diopter. Offers a mild fog protection good for average conditions; Level 2 Fog comes pre-installed. Protection Installing Level 2 Fog Level 1 Fog Protection Protection Level 2 Fog Protection Anti-Fog Shield.
