Simple ISMGM509E Instruction Manual

Instruction Manual

Product Features

• Bluetooth hands-free functionality
• A2DP music streaming
Dual USB inputs and USB-C input for device
•
charging
USB and Micro SD input for music playback
•
Voice Assistant Support
•
LED display
•
Bass boost feature
•
Rainbow LED ring
•
Diagram
ISMGM509E
~
1. USB-C input
2. USB1: 2.4A charging / Media input
3. LED display
4. Back (Short press) Source (Long press)
5. Play, pause, pick-up / call back (Short press) / Voice
assistant (Long press) / Volume +/- (Rotate)
6. Track + (Short press) / Enter FM mode (Long press)
7. Microphone
8. USB2: 2.4A charging
9. Rainbow LED ring
10. Micro SD Card slot
11. Change LED ring mode
12. Bass boost
13. 12V power
User Guide
Plug the product into the car's 12V socket. It will
automatically power on and the LED display will flash.
Turn on your car's FM radio and adjust the frequency
of the product to the same as the radio
To adjust the FM frequency of the device, long press
to enter frequency change mode.Then press
to adjust the frequency between FM 87.5 and
108.0Mhz. Wait three seconds without pressing a
button to exit frequency change mode.
Bluetooth Pairing
To pair your smartphone with the ISMGM509E, turn
on the Bluetooth function of your smartphone and
connect to 'Carkit'. Once connected, the smartphone
can be used to stream music via A2DP or for hands-
free calling.
Hands-free Calling
During a call, sound will be output through the
vehicle's speakers.
To answer an incoming call, press
press again to hang up.
To reject an incoming call, press and hold
To redial the last dialed number, double press
A2DP Streaming / Micro SD / USB Mode
Long press button to switch the mode: BT -- USB
– Micro SD.
After connecting the device via Bluetooth, select the
and
to answer and
