Page 3
Ethernet port Main supply port Supply optional port Multifunction connection port, Contact GPIO 1 GPIO 2 GPIO 3 GPIO 4 GPIO 5 GPIO 6 GPIO 7 GPIO 8 GPIO 9 GPIO 10 3 / 21...
Page 4
Power LED indicator Main supply port Option supply port Activity LED indicator Ethernet port Connection LED indicator Multifunction connection 4 / 21...
Page 7
Getting information about LM GPIO in WorkCAD To get information about any device, place the mouse pointer over “i” icon of each device Updating the LM GPIO in WorkCAD Before to install the LM devices is recommended to update all of them to a recent software version, they include bugs corrections and new functionalities.
Page 8
LM GPIO 3. Click on ^ icon ( in case of it is showed ) to update the device. GPIO If an error mistake appears pressing “Yes”, please, check the IP range in the PC with WorkCAD, it must be the same as the LM device. 8 / 21...
Page 9
4.Click on “YES” and the updating process will start. 5.During the updating process the progress bar will stop some seconds during the auto-reset, please, keep some seconds and do not disconnect the device until the process finishes 6.Once finished the updating process, WorkCAD will show a window indicating that the process must be finished successfully.
Page 10
Changing the LM GPIO name in WorkCAD 1-In order to change the name of the device, it is necessary to add it to a project, therefore, press “+” icon in a device will be showed in “Network” tab. The device will be inside “Project inspector”...
Page 11
Changing the IP address LM GPIO using WorkCAD 1- Over the device name, press “left click” and a dropdown menu will be showed, then, select “Change static IP” option. 2-Assign a new IP address Ones modified the name and IP address, it is advisable to reset the device in order to store the data correctly.
Restart a LM GPIO using WorkCAD 1- Over the device name, press “left click” and a dropdown menu will be showed, then, select “RebootDevice” option 2-WorkCAD will require to us confirmation to restart the device. 12 / 21...
Page 13
GPIO ports configuration The10 ports GPIO can be configuread as much as input as output. Using the dropdown menu, we can select the behaviour (input or output). In the downside is located a state indicator, if the contact is being used, it will lit in Green color.
Page 14
Closing / opening a GPIO port through OSC 1º-In the control device adjust the IP target according to the IP of the LM GPIO. 2º-In the control device adjust the port as 9000 3º-From the control device we send the command: /gpio1/mode With a value “1”...
Page 15
Closing a GPIO port once another GPIO port is closed 1º-Connect the LM-GPIO to the network and using WorkCAD we add it to a project. 2º-Configure GPIO1 as input 3º- Configure GPIO2 as output 4º-In “Commands” section select “Bank” GPIO1 5º-In “Event”...
Page 16
Close several GPIO ports once another port is closed 1º-Connect the LM-GPIO to the network and using WorkCAD we add it to a project. 2º-Configure GPIO1 as input 3º- Configure GPIO2, GPIO3, GPIO4 as outputs 4º-In “Commands” section select “Bank” GPIO1 5º-In “Event”...
Page 17
Close several GPIO ports once one port is opened 1º-Connect the LM-GPIO to the network and using WorkCAD we add it to a project. 2º-Configure GPIO1 as input 3º- Configure GPIO2, GPIO3, GPIO4 as outputs 4º-In “Commands” section select “Bank” GPIO1 5º-In “Event”...
Page 18
Close several GPIO ports of a remote LM GPIO 1º-Connect both LM-GPIO´s to the network and using WorkCAD we add them to a project. 2º-Configure GPIO1 as input local device 3º- Configure GPIO2, GPIO3, GPIO4 as output remote device 4º-In “Commands” section select “Bank” GPIO1 5º-In “Event”...
Page 19
Activate several ports when the device starts 1º-Connect the LM-GPIO to the network and using WorkCAD we add it to a project. 2º-Configure GPIO1 as output 3º- Configure GPIO2 as output 4º-In “Commands” section select the “On Start” Bank 5º-In IP enter: 127.0.0.1 6º-In Port enter: 9000 7º-In Command enter the command: //gpio2/value;,i;1;...
Page 20
COMMANDS CHART //memory3/exec;,; Execute a memory //gpio1/value;,i;1; Activate GPIO //gpio1/value;,i;0; Deactivate GPIO //gpio1/mode;,i;0; Adjust one port as input //gpio1/mode;,i;1; Adjust one port as output 20 / 21...
