Sunex Tools 6808C Owner's Manual

Capacity: 2 ton under hoist support stand
Table of Contents
  • Manual del Propietario
  • Especificaciones
  • Información de Advertencia
  • Garantía Limitada
  • Manuel du Propriétaire
  • Spécifications
  • Garantie Limitée

Advertisement

Available languages

Available languages

Quick Links

OWNER'S MANUAL
CONTENTS:
Page
1
Specifications
2
Warning Information
3
Setup Instructions, Operating Instructions, Preventative Maintenance
4
Troubleshooting, Inspection, Proper Storage, Owner/User Responsibility, Warranty Information
5
Exploded View Drawing and Replacement Parts
Complies with ASME PASE-2014 Safety Standard
6808C
SPECIFICATIONS
Capacity ................................................................... 2 Ton
Min Height ................................................................55.5"
Max Height ...............................................................82.3"
Base Dimensions ......................................................24.2"
Product Weight ................................................... 35.3 lbs.
Shipping Weight ................................................. 37.5 lbs.
UNDER HOIST SUPPORT STAND
1
MODEL 6808C
CAPACITY: 2 TON
© Copyright 2019, Sunex Tools ®
rev. 04/11/19
