UDACT-2200
Dual Line Dialer
Installation Manual
Advanced Life Safety Solutions
LT-2021MIR Rev.1
March 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDACT-2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mircom UDACT-2200

  • Page 1 Advanced Life Safety Solutions UDACT-2200 Dual Line Dialer LT-2021MIR Rev.1 Installation Manual March 2008...
  • Page 3: Table Of Contents

    UDACT-2200 Dual Line DIaler Installation Manual Table of Contents 1.0 Introduction ............................1 1.1 General Features of the UDACT-2200 ..................... 1 1.2 Codes, Standards and Installation Requirements ................1 1.3 Technical Support and General Information ..................1 1.4 System Verification ........................... 1 1.5 Standby Power ..........................
  • Page 5: Introduction

    General Installation Requirements Manufacturer’s Documents When installing the UDACT-2200, refer to this manual and the manual for the control panel into which this module is being installed. This dialer requires programming. Programming is done using the FX_V21 or greater programming.
  • Page 6: Standby Power

    UDACT-2200 Dual Line DIaler Installation Manual 1.5 Standby Power The FX-2200 Fire Panel provides standby battery support for lead-acid rechargeable batteries. The required capacity of the standby batteries must be calculated using the charts and tables within the FX-2200 Installation Manual (LT-2000MIR) for the period as required by national or local codes and standards.
  • Page 7: Installing And Wiring The Udact-2200

    65 mA alarm current (when dialing) Mounting & Wiring the UDACT-2200 The UDACT-2200 is mounted in the upper right corner of the back box, in the main panel. Route the wiring harness under the plastic shield before mounting the DACT. Attach the harness to the connector labeled DACT/CITY on the main board.
  • Page 8: Udact-2200Operation

    UDACT-2200 Dual Line DIaler Installation Manual UDACT-2200Operation 3.1 LED Indicators The dialer’s operating status is visible from its five LED indicators. These indicators are located on the dialer. Each indicator is described in the following table: Indicator LED Color Activates when...
  • Page 9: Programming The Udact-2200

    UDACT-2200 Dual Line DIaler Installation Manual 4.0 Programming the UDACT-2200 4.1 Accessing the Dialer Settings 1. At the initial programming screen (Figure 2), do the following: a. Check the Enforce Group Associations Checking box. b. Click on the Alarm List Mode list box and select the Local option.
  • Page 10: Dialer Settings

    UDACT-2200 Dual Line DIaler Installation Manual 2. In the Panels screen (Figure 3), click on the IDs button to access the IDs dialog (Figure4). In the IDs dialog (Figure 4), check the UDACT-2200 check box and click on the Dialer Button Figure 3: Panels Screen Settings button.
  • Page 11: Figure 5: Initial Dialer Screen

    UDACT-2200 Dual Line DIaler Installation Manual The 1st and 2nd Format setting affects type communication that the dialer sends to the central station. The formats available include Contact ID, SIA and a pager format. The Dialer Settings window has the following push buttons along the right side: •...
  • Page 12 UDACT-2200 Dual Line DIaler Installation Manual The Dialing option has three different options for pulse or DTMF dialing. If All attempts Pulse is selected, the dialer will always use pulse (rotary) dialing. If All attempts DTMF Dialing is selected, the dialer will always use DTMF dialing.
  • Page 13: Figure 7: Dialer Configuration 2

    UDACT-2200 Dual Line DIaler Installation Manual The ID Tone can be set to 1300Hz or 2100 Hz. The panel will emit a tone at the selected frequency for 500 ms every 2 seconds when it places a call to indicate that it is a digital equipment call, not voice.
  • Page 14: Figure 9: Zone Data

    UDACT-2200 Dual Line DIaler Installation Manual The Zone Data dialog (Figure 9) contains zone definitions and reporting codes that the dialer will use to communicate events. The Groups List is a list of all currently defined groups. Each line entry includes the Group ID and its message/description.
  • Page 15: Appendix A: Table Of Reporting Codes

    UDACT-2200 Dual Line DIaler Installation Manual 5.0 Appendix A: Table of Reporting Codes The following tables contain automatic Contact ID and SIA format reporting codes. For more information on reporting formats. 5.1 Contact ID The first digit (in parentheses) will automatically be sent by the control. The second two digits are programmed to indicate specific information about the signal.
  • Page 16 UDACT-2200 Dual Line DIaler Installation Manual Table 1: Automatic Contact ID/SIA Reporting Codes Contact Reporting Dialer ID Auto Sia Auto Code Sent When… Code Direction* Rep Codes Codes Zone Supv./ zone goes into supervisory/ restore (2) AA See Table 3 Rest.
  • Page 17 UDACT-2200 Dual Line DIaler Installation Manual Table 2: Contact ID Zone Alarm/Restoral Event Codes Program any of these codes for zone alarms/restorals when using the standard (i.e. not automatic) Contact ID reporting format: Medical Alarms (1)18 Near Alarm 24 Hour Non-Fire...
  • Page 18: Appendix B: Table Of Compatible Receivers

    UDACT-2200 Dual Line DIaler Installation Manual 6.0 Appendix B: Table of Compatible Receivers Osbourne Sur-Gard Bell Format/ Sur-Gard Sur-Gard Hoffman Silent Ademco Radionics MLR200 Mobility Receiver Quick Knight 6500 Pager Alert II SIA (level 2) Contact ID Pager Version V1.00 V1.83...
  • Page 19: Warranty & Warning Information

    •Software Most Mircom products contain software. With respect to those products, Mircom does not warranty that the operation of the software will be uninterrupted or error-free or that the software will meet any other standard of performance, or that the functions or performance of the software will meet the user’s requirements.
  • Page 20 UDACT-2200 Dual Line DIaler Installation Manual the software. Every fire is different in the amount and rate at which smoke and heat are generated. Smoke detectors cannot sense all types of fires equally well. Smoke detectors may not provide timely warning of fires caused by carelessness or safety hazards such as smoking in bed, violent explosions, escaping gas, improper storage of flammable materials, overloaded electrical circuits, children playing with matches or arson.
  • Page 21 NOTE: Unless specific pre-authorization in writing is obtained from Mircom management, no credits will be issued for custom fabricated products or parts or for complete fire alarm system. Mircom will at its sole option, repair or replace parts under warranty. Advance replacements for such items must be purchased.
  • Page 22 UDACT-2200 Dual Line DIaler Installation Manual Out of Warranty Repairs Mircom Technologies Ltd. will at its option repair or replace out-of-warranty products which are returned to its factory according to the following conditions. Anyone returning goods to Mircom Technologies Ltd.Mircom Technologies Ltd. must first obtain an authorization number.
  • Page 23: Fcc Compliance Statement

    UDACT-2200 Dual Line DIaler Installation Manual 8.0 FCC Compliance Statement CAUTION: Changes or modifications not expressly approved by the manufacturer could void your authority to use this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 24 UDACT-2200 Dual Line DIaler Installation Manual ADDITIONAL TELEPHONE COMPANY INFORMATION The security control panel must be properly connected to the telephone line with a USOC RJ-31X telephone jack. The FCC prohibits customer-provided terminal equipment be connected to party lines or to be used in conjunction with coin telephone service.
  • Page 28 Advanced Life Safety Solutions Canada U.S.A. © Mircom 2007 Printed in Canada 25 Interchange Way 60 Industrial Parkway PMB 278 Subject to change without prior notice Vaughan, ON L4K 5W3 Cheektowaga, NY 14227 Tel: 1-888-660-4655 Fax: 1-888-660-4113 www.mircom.com Tel: 905-660-4655 Fax: 905-660-4113...
