JC-3s MICRO
AUTO ANTENNA COUPLER
1) 1.8 - 50ΜΗz , 200W SSB FOR ANTENAS 5 M OR LONGER!
2) BETTER PERFORMANCE DUE TO SMALLER CAPACITOR STEP ( 9pF )
3) DIRECT FUNCTIONING WITH ICOM , ALINCO , KENWOOD
4) 50 "EEPROM" MEMORIES – NO BATTERY !!!
NEVER USE THE COUPLER UNTUNED OR "THROUGH" AND CORRECT THE
SWR USING AN INDOOR ANTENNA TUNER NEAR THE TRANSCEIVER !!!
1. +12 V
(BROWN)
2. START
(GREY)
3. KEY
(YELLOW)
4. MEMORY (BLACK)
GROUND
WATCH OUT : -12 V RETURN TO POWER SUPPLY VIA THE COAXIAL SHIELD !!!
MANUAL TUNING PROCEDURE
Press the BUTTON on the control box until the led is lit.
Transmit sending a carrier of approximately 10 to 20 Watts to the coupler until the led goes off.
Adjust power to the final level and transmit!
MEMORY USE
To enable memories we set the switch on the control box to the Y position. All frequencies we tune, up to 50,
are recorded. When we go to the same frequencies again and perform the tuning procedure ,the coupler is
almost instantly ready to be used. All it has to do is count the incoming signal frequency and use the tuning
JC-3 manual version 8.1 page 1
+12 VDC POWER SUPPLY
•
TUNE COMMAND FROM TRANSCEIVER OR CONTROL BOX TO COUPLER
•
TX COMMAND FROM COUPLER TO TRANSCEIVER OR CONTROL BOX
•
MEMORY CONTROL : +12V
•
( Up to 200 W pep SSB )
NEW EDITION
(-12 V RETURN VIA COAXIAL SHIELD !!!)
NO , 0V
YES
Advertisement
Table of Contents
Summary of Contents for Stockcorner JC-3s
- Page 1 JC-3s MICRO AUTO ANTENNA COUPLER NEW EDITION 1) 1.8 - 50ΜΗz , 200W SSB FOR ANTENAS 5 M OR LONGER! 2) BETTER PERFORMANCE DUE TO SMALLER CAPACITOR STEP ( 9pF ) 3) DIRECT FUNCTIONING WITH ICOM , ALINCO , KENWOOD 4) 50 "EEPROM"...
- Page 2 combination it has done before! ( If it fails because the antenna system has changed, it repeats the tuning procedure and saves the new combination in the same memory position.) ERASING MEMORIES To erase the memories we set the switch on the control box to the N position and without transmitting we press the button till the led is lit.
- Page 3 TRANSCEIVER – COUPLER COMMUNICATION CABLE 2-20 m. 0.50 mm DISTANCE DIAMETER 20-35 m. 0.75 mm 35-50 m. 1.00 mm DIRECT CONNECTION BETWEEN COUPLER AND TRANSCEIVER YAESU ALINCO ICOM KENWOOD YAESU DOES NOT HAVE Ο Ο Ο ΟΟΟΟΟ Ο Ο Ο Ο START - KEY LOGIC.
- Page 4 Mobile HF radio connected with tuner and 1 power supply Mobile HF radio & tuner connected with 2 separately power supplies JC-3 manual version 8.1 page 4...
- Page 5 HF Base radio connected with tuner and separately power supply Tuner connected directly to a radio. READ manual (so control box not needed in this setup) JC-3 manual version 8.1 page 5...
- Page 6 Some antenna examples. There is no “best” solution. It all depends on your interest, length of wires and space around the antenna. JC-3 manual version 8.1 page 6...
- Page 7 JC-3 manual version 8.1 page 7...
